Connect your various devices such as a laptop computer, wireless microphone,

or other line level devices to Inputs 3 and 4. Remember Channel 4 is MONO,

MX56c

and Channel 3 is STEREO.

Connect a stereo signal source such as a CD player, cassette player, or a video

MiniMix A/V

player's audio output to Channel 1, and a microphone to Channel 2. If the micro-

phone requires phantom power, move the phantom power jumper as described

on the previous page.

4-Channel Mixer

Adjust the levels of each channel for a desired balance of signals. Since the

MX56c has no master level, you will need to be aware of the setting of your am-

plifier. Check each mic/source level individually first for proper level, then adjust

them for a desired mix.

Rolls Corporation

SCHEMATIC

Salt Lake City, UT 10/05

Owners Manual

Table of Contents

Do you have a question about the MX56c and is the answer not in the manual?

Page 1: Channel Mixer
Adjust the levels of each channel for a desired balance of signals. Since the MX56c has no master level, you will need to be aware of the setting of your am- plifier. Check each mic/source level individually first for proper level, then adjust them for a desired mix.
Page 2: Limited Warranty
INTRODUCTION Thank you for your purchase of the MX56c MiniMix A/V. The unit is ideal for A/V presentations where a microphone must be mixed with a variety of sources such as a CD player, MP3 player, laptop computer, etc. INSPECTION 1.
