YOKOGAWA 96001 User Manual

User's
Model 96001
Manual
Clamp on probe
Thank you for purchasing our Clamp-on Probe.
This manual describes the specifications and handling
precautions for a Clamp-on Probe.
The following manuals, including this one, are provided as manuals
for the 96001. Read them along with this manual.
RG 108-E: User's Manual (this manual)
IM 00C01C01-01Z1: Safety manual (European languages)
IM WEEE001E: Waste Electrical and Electronic Equipment
IM CROHS-96001: Document for China
Contact information of Yokogawa offices worldwide is
provided on the following sheet.
PIM 113-01Z2: Inquiries
Store this manual in an easily accessible
place for quick reference.
All Rights Reserved, Copyright ©
2015, Yokogawa Meters & Instruments Corporation
2017, Yokogawa Test & Measurement Corporation
Printed in Japan
Regulations and Sales in Various Countries and Regions
Authorized Representative in the EEA
Yokogawa Europe B.V. is the authorized representative of
Yokogawa Test & Measurement Corporation for this product in
the EEA.
To contact Yokogawa Europe B.V., see the separate list of
worldwide contacts, PIM 113-01Z2.

Regarding Safe Use of This Product

This product is designed to be used by a person with specialized
knowledge. The general safety precautions described herein must
be observed during all phases of operation.
If the instrument is used in a manner not specified in this manual,
the protection provided by the instrument may be impaired.
This manual is part of the product and contains important information.
Store this manual in a safe place close to the instrument so that
you can refer to it immediately.
Keep this manual until you dispose of the instrument.
YOKOGAWA assumes no liability for the customer's failure to
comply with these requirements.
The following safety symbols are used on the instrument
and in this manual.
WARNING
Indicates a hazard that may result in the loss of life or serious
injury of the user unless the described instruction is abided by.
CAUTION
Indicates a hazard that may result in an injury to the user and/or
physical damage to the product or other equipment unless
the described instruction is abided by.
List of worldwide contacts
November 2021 (YMI)
(EEA: European Economic Area)
Danger! Handle with Care.
This mark indicates that operator must refer to an explanation
in the instruction manual in order to avoid risk of injury
or death of personnel or damage to the instrument.
This symbol indicates that this instrument designed to be
applied around or removed from HAZARDOUS LIVE
conductors provided if the RATED circuit-to-earth voltage
does not exceed the value indicated in the measurement
category.
This symbol indicates AC voltage/current.
This symbol indicates double insulation.
Strictly observe the following cautionary notes in order to
avoid the risk of injury or death of personnel or damage
to the instrument due to hazards such as electrical shock.
WARNING
• This instrument is for measuring AC current (clamping sensor).
Do not use this instrument for other purpose.
• Do not use the instrument if there is a problem with its physical
appearance.
• To avoid a short-circuit or an accident to personnel,
use this product within the RATED circuit-to-earth voltage of

measurement category.

• Do not use the product when there are raindrops or droplets of
condensed water on its surface, or if your hands are wet.
• Barrier is for to avoid touching the HAZARDOUS LIVE
conductor.
Be careful not to across the Barrier when using the instrument.
RG 108-E
• Safety protectors such as rubber-insulated gloves should be
11th Edition:
worn to prevent electrical shock when using the instrument.
• Do not use this product in a place where an explosive gas or
vapor is present.
• Do not use the instrument if there is any damage to the casing or
when the casing is removed. Do not attempt to repair/modify
the product yourself, as doing so is extremely dangerous.
Should an abnormality or failure in the product be found,
contact the vendor from which you purchased the product.
CAUTION
• The use of this instrument is limited to residential, commercial,
and light-industrial environments. This instrument may not be
able to measure accurately if it is near other equipment
generating strong electromagnetic interference or a strong
magnetic field caused by large current.
• Do not use the instrument in areas subject to rapid temperature
fluctuations.
• The clamping JAWS are precision assembled to ensure high
performance. When using the clamp, do not apply intense
mechanical shock, vibration, or force to the clamping JAWS.
• If dust or any other foreign matter gets in the clamping JAWS,
do not close the clamping cores tight. First remove the dust
and then make sure the clamping cores on both sides close
smoothly.

Cleaning

To remove dirt, disconnect the lead plugs and gently wipe the outer
surface with a clean and soft cloth.
Do not use a chemical agent such as benzine or paint thinner.
