QUICK START GUIDE
neo:Pro HDMI Extender Set (P8-HDBT2-P-EXSET)
This installation guide helps you to install and use your Pulse-Eight neo:Pro
HDMI Extender for the first time.
Go to
important technical information not provided in this document and warranty
terms & conditions.
SCAN FOR HELP
CHECK WHAT'S INSIDE THE BOX
• 1 x neo:Pro PoH Receiver
• 1 x neo:Pro Transmitter
IMPORTANT!
!
• Please read the instructions before attempting to install or operate this equipment.
• Visit the
help.pulse-eight.com
configuration tools.
help.pulse-eight.com
for additional information on this product including
• 1 x IR Blaster Cable Pack
• 1 x Quick Start Guide
to download the latest product manual, additional documentation, and
• 1 x Power Supply Adapter
Advertisement
Related Manuals for PULSEEIGHT P8-HDBT2-P-EXSET
Summary of Contents for PULSEEIGHT P8-HDBT2-P-EXSET
- Page 1 QUICK START GUIDE neo:Pro HDMI Extender Set (P8-HDBT2-P-EXSET) This installation guide helps you to install and use your Pulse-Eight neo:Pro HDMI Extender for the first time. Go to help.pulse-eight.com for additional information on this product including important technical information not provided in this document and warranty terms &...
- Page 2 INSTALLATION PANEL DESCRIPTIONS neo:Pro Transmitter IR Activity Indicator - The LED will flash green when an IR signal is being received and red when an IR signal is being transmitted. IR Flasher (TX) - The IR Flasher port is used to control the connected HDMI Source device (eg: Blu-ray) using the IR transmitter.
- Page 3 SAFETY PRECAUTION Please read the full manual instructions before attempting to install or operate this equipment. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock, and injury. •...
