QUICK REFERENCE GUIDE - AUDIO EXTENDER (P8-AE-CAT-EXSET)
AUDIO EXTENDER
INTRODUCTION
Digital audio over extreme distances can be tricky in isolation; our audio extender uses a standard Cat5e or
better cable to seamlessly transmit S/PDIF (Toslink) audio over 200m.
The Pulse-Eight Digital Audio over Cat5e/6 Extender is ideal for extending audio signals up to 200m over a single
CAT5e or CAT6 cable.
FEATURES
• Compact design
• Supports coaxial or S/PDIF digital audio signals
• Supports Stereo and Multichannel digital audio
• Extends audio signals over a single CAT5e/CAT6 cable
• Supports 2ch PCM audio inputs
• 5.1 Compressed audio supported
• Extension length up to 200m
INSIDE THE BOX (KIT)
• 1 x Audio Extender
• 1 x Audio Receiver
• 1 x Power Cable
• 1 x USB to DC Adapter
• 1 x Installation Guide
