Summary of Contents for PULSEEIGHT neo LITE HDMI EXTENDER
-
Page 2: Table Of Contents
CONTENTS Introduction 3 Features 3 Inside The Box (Kit) 3 Specifications 4... -
Page 3: Introduction
INTRODUCTION The neo:Lite HDMI Extender set offers an ideal plug-and-play solution for custom A/V installers and Home Theatre enthusiasts to project content over long distances without compromising audio or video quality using HDBaseT™ technology The Pulse-Eight neo:Lite with fully HDCP Compliant transmission means source video content can be stored in a dedicated rack away from the viewing location;... -
Page 4: Specifications
SPECIFICATIONS Video Resolution - 3840x2160p @50/60Hz 8bit 4:2:0 - 3840x2160p @24/25/30Hz 8bit 4:4:4 - 3840x2160p @24/25/30Hz 10bit 4:2:0 HDR - All formats 1080p, 1080i, 720p, 576p, 480p @24/25/30/50/60Hz Video Input (Receiver) 1 × HDBaseT Class B (Lite) Video Output (Receiver) 1 ×... -
Page 5: Safety Precaution
SAFETY PRECAUTION Please read the instructions before attempting to install or operate this equipment. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock, and injury. •... -
Page 6: Panel Descriptions
PANEL DESCRIPTIONS neo:Lite Transmitter 48 V Power Input - is used with the supplied 48V power adapter HDBaseT Output - Connect the appropriate category cable (Cat5e or higher recommended) to the output of the transmitter; this cable should then be connected to the HDBaseT input on the neo:Lite receiver The LEDs will illuminate to indicate a link is established (amber LED) and video (green LED) is being sent IR Receiver (RX) - The IR Receiver port can be used to distribute IR signals to the attached neo:Lite receiver, when connecting an IR Receiver... -
Page 7: Infrared Blaster Cable Pack
INFRARED BLASTER CABLE PACK 1. IR Transmitter 3.5mm Stereo Jack - An IR flasher (emitter) is required when wanting to output (blast) an IR command to an attached device. Please use compliant Pulse-Eight IR emitters (5V) as failure to do so might result in damage to the product 2. -
Page 8: Hdbaset Cabling
HDBASET CABLING What Is The Best Type Of Cable To Use? Pulse-Eight products use the HDBaseT standard, which makes use of standard Category (Cat) cables. The minimum cable used on a neo system is Cat5e, but it is recommended to use a higher tier cable such as Cat6, Cat6A, or Cat7 where possible because they have stricter twisted pair and shielding requirements that reduce data loss between data pairs Patch cabling is strongly discouraged because it can degrade the signal. -
Page 9: Ir Pin Assignments
IR PIN ASSIGNMENTS Pulse-Eight strongly recommends the use of the IR accessories provided. We do not support 3rd party IR component as it could damage the matrix The standard range of Pulse-Eight matrices utilise a 3.5mm stereo jack, both for IR flashers and receivers buds. We strongly recommend purchasing a Pulse-Eight Mono-Stereo Optocable when necessary in your installation. -
Page 10: Installation
INSTALLATION 1 Connect HDMI cable from your video source (e.g. Blu-Ray player) to the HDMI input of the neo:Lite transmitter. 2. Connect the appropriate category cable (Cat5e or higher recommended) to the neo:Lite Transmitter’s ‘HDBaseT Out’ ports 3 Complete the connection by attaching the other end of the Cat cable to the neo:Lite Receiver’s ‘HDBaseT In’ port 4 Connect HDMI Out on the neo:Lite Receiver to the sink device (i.e. -
Page 11: Troubleshooting
TROUBLESHOOTING Should you encounter installation difficulties or issues with device communication, the following checklist of common issues and causes should help resolve your issues. If you still continue to experience issues, please contact your local representative for further assistance No or Poor Picture Quality •... - Page 12 LED Status There are several debug LEDs next to the input and output ports that can help with any further troubleshooting HDBT RJ45 Left: OFF - No HDBT Link. AMBER - HDBT Link established. HDBT RJ45 Right: OFF - No Video GREEN (Blink) - Video Present (No HDCP).
-
Page 13: Warranty Procedure
WARRANTY PROCEDURE The following policies covers all Pulse-Eight products. Unless otherwise instructed, please do not open any of our products. Doing so will invalidate your warranty. As part of the troubleshooting procedure, you may be instructed to open the device, but you can only proceed with this once consent has been given To open a support ticket, please visit: www.pulse-eight.com/support. -
Page 14: Warranty Terms & Conditions
WARRANTY TERMS & CONDITIONS IMPORTANT INFORMATION ABOUT YOUR RIGHTS AND OBLIGATIONS, AS WELL AS LIMITATIONS AND EXCLUSIONS THAT MAY APPLY TO YOU. YOUR RIGHTS AND THIS LIMITED WARRANTY This Limited Warranty gives you specific legal rights. You may also have other legal rights that vary by state, province, or jurisdiction. The disclaimers, exclusions, and limitations of liability under this Limited Warranty will not apply to the extent prohibited by applicable law. - Page 15 5. DISCLAIMER OF WARRANTIES Except as stated above in this limited warranty, and to the maximum extent permitted by applicable law, Pulse-Eight disclaims all express, implied, and statutory warranties and conditions with respect to the product, including the implied warranties of merchantability, fitness for a particular purpose.
-
Page 16: Notes
NOTES...
