Roland SI-AES4 Installation Manual

SI-AES4 / SO-AES4 Installation Manual
This guide describes how to install SI-AES4 (digital input) and SO-AES4 (digital output) modules in your S-4000S.
Before you attempt installation, please read this document carefully.
© 2006 Roland Corporation
All rights reserved. No part of this publication may be reproduced in any form without the written permission of
ROLAND CORPORATION.
For the Purchaser — Please Read
SI-AES4 and SO-AES4 are not user installable. Installation must be carried out by an authorized Roland Service
Technician.
For the Installer (Service Technician) — Please Read
• After installing the SI-AES4 or SO-AES4, please be sure to return this document to the
purchaser.
• To use the SI-AES4 or SO-AES4, the firmware for every S-4000S or S-4000H device in the
system must be at version 1.500 or later. For information on how to update the firmware,
refer to the Service Notes issued by Roland.
Cautions When Installing the SI-AES4 or SO-AES4
002a
• Do not open or perform any internal modifications on the unit.
022c
• Before installing the SI-AES4 or SO-AES4, you must first always turn off the S-4000S and
unplug its power cord.
115b
• Install the circuit board only into the specified S-4000S. Remove only the specified screws
during the installation.
118b
• Keep the included ferrite cores in a safe place out of children's reach, so there is no chance of
them being swallowed accidentally.
901
• To avoid the risk of damage to internal components that can be caused by static electricity,
please carefully observe the following whenever you handle the board.
❍
Before you touch the board, always first grasp a metal object (such as a water pipe), so
you are sure that any static electricity you might have been carrying has been
discharged.
❍
When handling the board, grasp it only by its edges. Avoid touching any of the
electronic components.
912
• Never use excessive force when installing a circuit board. If it doesn't fit properly on the
first attempt, remove the board and try again.
913
• When the SI-AES4 or SO-AES4 installation is complete, double-check your work Please refer
to the Service Notes
• Use a Philips screwdriver of the appropriate size to avoid damaging the screw heads (use a
number 2 screwdriver).
• Never leave a slot open. Cover any unused slots with optional S-BP blank panels.
• Be careful not to cut your hand on the edge of the circuit board or the opening edge.
issued by Roland
.
1
