Summary of Contents for Comedes Lavaero 1000
- Page 1 Lavaero 1000...
-
Page 2: Table Of Contents
table of contents foreword....................safety instructions ................Intended Use............. Technical data ..................device description ................Before commissioning................commissioning ..................Front cover handling............filter change ................air humidification Cleaning the device................Malfunctions and remedies................Further information................ - Page 3 Dear customer, Thank you for choosing the Lavaero 1000 from Comedes GmbH. You have purchased a powerful air purifier designed to the latest technical standards. To ensure that the device will remain your faithful servant over a long period of time, we ask you to study the operating instructions, in particular the safety instructions, in detail.
-
Page 4: Safety Instructions
Read the instructions carefully before commissioning. Failure to follow the safety instructions and instructions may result in electric shock, fire and/or serious injury. Keep all safety instructions and instructions for the future. Watch your step! Do not open the device until the mains plug has been disconnected from the mains socket. - Page 5 Do not insert any objects (especially metallic objects) or your fingers into the air inlets and outlets of the device. This could result in electric shock and injury. Never use hairsprays, thinners or flammable gases in the vicinity of the device, as there is a risk of fire and explosion.
-
Page 6: Intended Use
If any of the following occur, immediately disconnect and disconnect the air purifier and contact the manufacturer. ◦ The device makes unusual noises or vibrates strongly during operation. ◦ The equipment, power plug or cord may become abnormally hot. ◦... -
Page 7: Technical Data
Technical data Product name: Comedes Lavaero 1000 Tension: 220-240V / 50/60 Hz Nominal power: Air flow rate: 488m³/h Timer (hours): 1-12 Weight: 11,3 kg Dimensions (W*H*T): 401*662*232 mm Noise emission: max 69dB(A) device description front cover air inlet (on both... -
Page 8: Before Commissioning
Control panel/display display control panel remote control A button cell Lithium Cell CR2032, 3V is required for the remote control. (Not included in delivery.) AUTO power unlock timer Speed + Speed lure UV Light Filter Reset /Sterilize sleep Before commissioning Remove the filter elements from the unit, remove the protective films and reinsert them into the unit. - Page 9 POWER The power switch is used to turn the unit on and off. (The symbol lights up red in standby mode and orange when switched on). The device always starts in automatic mode. AUTO Press the "AUTO" button to start the automatic mode. In this mode, the fan level is automatically selected depending on the air quality.
-
Page 10: Front Cover Handling
"UNLOCK" button. Filter change indicator and filter reset The Comedes Lavaero 1000 has a modern filter change indicator. After 320 hours, the filter change symbol starts flashing. This is to inform you that the prefilter and the HEPA element should be cleaned. After cleaning and reinserting the filters, press and hold the "Reset"... -
Page 11: Filter Change
The front cover can Release the latches in now be removed the upper part of the diagonally upwards. front cover by pulling lightly. 2. Installing the Front Cover Now close the front To lock the front cover, First place the cover by pressing it press it into the locks with front cover on top. - Page 12 Take the Remove the Remove the filters Remove the filter cover. Prefilter. always first from Protective film, before and they use it. 2. The prefilter can be cleaned under running water and does not need to be replaced. 3. Now check the filters. If the HEPA element is not yet too discoloured, vacuum it off with a vacuum cleaner (preferably outdoors).
-
Page 13: Air Humidification
The Comedes Lavaero 1000 is equipped with an air humidification function. Humidification takes place by means of the evaporation principle. As soon as the water tank is filled with water, the air flowing through the unit is automatically moistened. The higher the fan speed, the higher the humidification performance. -
Page 14: Cleaning The Device
Always switch and disconnect the device for this purpose. 1) Pull the 2) Remove the water tank out humidifying filter from of the side of the protective film. the appliance. 3) Insert the 4) Open the humidifying filter rubber cover of into the water the filling opening. - Page 15 • Remove the prefilter from the unit as described in the chapter "Changing the filter". • The prefilter can be vacuumed or washed under cold, clear water. Dry the filter before reinserting it into the unit. Clean the activated carbon/cold catalysis filter combination (every other •...
-
Page 16: Malfunctions And Remedies
Finally, replace the cover of the air quality sensor. • Malfunctions and remedies Current operating instructions can be found at http://www.comedes.com Turn off the unit immediately and contact your dealer if any of the following problems occur: Fuse's blown. •... -
Page 17: Further Information
The device cannot be switched on: Is the plug inserted correctly? • Has the fuse blown or is there no voltage at the socket? • Isn't the device upright or has it been put down? • Is the child lock activated? •... - Page 18 Activated carbon, thanks to its highly porous structure, has a very large surface area, which enables it to adsorb a large amount of different odorants and flavors, as well as various VOCs. HEPA Filter The HEPA (High Efficiency Particulate Airfilter) medium is able to remove even the smallest particles from the room air.
- Page 19 This product must not be disposed of with household waste. This air purifier must be disposed of at a recycling point for electronic and electrical equipment. You can obtain further information about the relevant acceptance points from your local authority or city administration, or from Comedes GmbH.
