Owner's Manual
Thank you, and congratulations on your choice of the Roland SA-1000 Stage Amplifier.
Before using this unit, carefully read the sections entitled: "IMPORTANT
SAFETY INSTRUCTIONS" (p. 2), "USING THE UNIT SAFELY" (p. 3), and
"IMPORTANT NOTES" (p. 5). These sections provide important information
concerning the proper operation of the unit.
Additionally, in order to feel assured that you have gained a good grasp of every
feature provided by your new unit, Owner's manual should be read in its entirety.
The manual should be saved and kept on hand as a convenient reference.
Contents
IMPORTANT SAFETY INSTRUCTIONS ............................ 2
USING THE UNIT SAFELY ................................................ 3
IMPORTANT NOTES.......................................................... 5
Main Features .................................................................... 7
Names of Things and What They Do ............................... 8
Control Panel............................................................................................. 8
Jack Panel ................................................................................................. 10
Making the Connections ................................................. 12
Switching the Power On and Off ......................................................... 13
About Setting the Volume ..................................................................... 14
About Stereo Link................................................................................... 14
About the Anti-Feedback Function................................ 15
Features of SA-1000 ANTI-FEEDBACK .............................................. 15
How to Use Anti-Feedback ................................................................... 16
About the Use of Stacks ................................................. 18
About the Protection Circuit........................................... 18
Block Diagram ................................................................. 19
Main Specifications ......................................................... 20
Copyright © 2007 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the written
permission of ROLAND CORPORATION.
Advertisement
Table of Contents
Related Manuals for Roland SA-1000
Summary of Contents for Roland SA-1000
-
Page 1: Table Of Contents
Owner’s Manual Thank you, and congratulations on your choice of the Roland SA-1000 Stage Amplifier. Before using this unit, carefully read the sections entitled: “IMPORTANT SAFETY INSTRUCTIONS” (p. 2), “USING THE UNIT SAFELY” (p. 3), and “IMPORTANT NOTES” (p. 5). These sections provide important information concerning the proper operation of the unit. -
Page 2: Important Safety Instructions
WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN ATTENTION : RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). -
Page 3: Using The Unit Safely
• Do not attempt to repair the unit, or replace parts within it (except when this manual provides specific instructions directing you to do so). Refer all servicing to your retailer, the nearest Roland Service Center, or an authorized Roland distributor, as listed on the “Information” page. - Page 4 Excessive loads can cause the insulation on the cord to heat up and eventually melt through. • Before using the unit in a foreign country, consult with your retailer, the nearest Roland Service Center, or an authorized Roland distributor, as listed on the “Information” page.
-
Page 5: Important Notes
IMPORTANT NOTES In addition to the items listed under “IMPORTANT SAFETY INSTRUCTIONS” and “USING THE UNIT SAFELY” on pages 2 and 3, please read and observe the following: Power Supply • Do not connect this unit to same electrical outlet that is being used by an electrical appliance that is controlled by an inverter (such as a refrigerator, washing machine, microwave oven, or air conditioner), or that contains a... -
Page 6: Maintenance
The use of such cables can cause the sound level to be extremely low, or impossible to hear. For information on cable specifications, contact the manufacturer of the cable. • Wrap the power cord around the cord hook when trans- porting or storing the unit. SA-1000... -
Page 7: Main Features
Fully reproduces the powerful, low-frequency sounds of an organ Designed for high power, the SA-1000 outputs 350 watts (stereo: 75 W + 75 W, subwoofer: 200 W). This amp faithfully reproduces piano, organ, and other keyboard sounds. The SA-1000 also comes equipped with an "Organ Enhance" function. -
Page 8: Names Of Things And What They Do
The microphone picks up the sound and the SA-1000 analyzes the characteristics of the microphone and the surroundings. Based on the results of this analysis, the microphone and... -
Page 9: Power Indicator
Connect headphones here. * Be sure to turn the PHONES knob setting to 0 before connecting or disconnecting headphones. * Sounds from the SA-1000's speakers and LINE OUT are not muted even when headphones are connected. 13.VOLUME Knob This adjusts the overall volume output from the SA- 1000’s speakers. -
Page 10: Jack Panel
Names of Things and What They Do Jack Panel fig.01-02 MIC INPUT 1. MIC IN Jack Connect a microphone here. For balanced input, you can connect to the TRS 1/4-inch phone jacks and XLR type connector. • This instrument is equipped with balanced (XLR/TRS) type jacks. -
Page 11: Line Out
Use the special connection cable included with the unit to connect to the SA-1000W’s INPUT jack. This provides powerful low end to the sound. * Turn off the power on the SA-1000 before connecting or disconnecting cable. • Connect only the SA-1000W. Never connect any other equipment. -
Page 12: Making The Connections
Making the Connections Refer to the figure shown below to connect the SA-1000 and the other equipment. fig.02-01 Organ Special connection cable INPUT CD Player Portable Audio Player SA-1000W * To prevent malfunction and/or damage to speakers or other devices, always turn down the volume, and turn off the power on all devices before making any connections. -
Page 13: Switching The Power On And Off
1. Make sure that all volume controls on the SA-1000 and connected devices are set to 0. 2. Turn on all the devices connected to the SA-1000’s input jacks. -
Page 14: About Setting The Volume
Making the Connections About Setting the Volume To obtain the best sound from the SA-1000, set the volume level using the following procedure. fig.02-04 1. When using the MIC IN input, press the MIC button. 2. Adjust the MIC REVERB knob to achieve the desired sound. -
Page 15: About The Anti-Feedback Function
On the other hand, the SA-1000 employs a newly developed method that does not require generation of feedback, but instead uses a microphone to capture a calibration signal output from the SA-1000’s own speakers, then performs a feedback analysis to estimate the feedback point. -
Page 16: How To Use Anti-Feedback
1. Set up and connect the SA-1000 and the mic. • Set up the SA-1000 and the mic in the positions they will be used. • Adjust the height of the mic stand and the angle of the mic. - Page 17 However, turning off the power clears the results of the correction. • SA-1000 does not respond to panel operations while in ANALYSIS calibration. It responds after the calibration is completed.
-
Page 18: About The Use Of Stacks
About the Use of Stacks When stacking, be sure to follow the instructions below. • Be sure to set up and use these units in stable, level locations. • Be careful not to get your fingers pinched. ● Stack so that the speaker side of both the top cabinet and the bottom cabinet face the same direction. -
Page 19: Block Diagram
Block Diagram ON/OFF VOLUME KEYBOARD 1 L (MONO) KEYBOARD 1 VOLUME KEYBOARD 2 L (MONO) KEYBOARD 2 VOLUME AUDIO AUDIO VOLUME STEREO LINK REVERB ANTI-FEEDBACK volume control STEREO LINK control EQUALIZER ORGAN ENHANCE MASTER AMBIENCE VOLUME PHONES VOLUME LINE OUT STEREO LINK SPEAKER SA-1000W... -
Page 20: Main Specifications
Main Specifications SA-1000 ● Rated Power Output 350 W (75 W x 2 + SUBWOOFER 200 W) ● Nominal Input Level (1 kHz) INPUT (MIC): -50 dBu INPUT (PHONE): -20 dBu INPUT (RCA): -20 dBu STEREO LINK INPUT: 0 dBu ●... - Page 21 SA-1000W (SUBWOOFER) ● Speaker 30 cm / 12 inches ● Nominal Impedance 4 ohms ● Connection INPUT Jack (1/4" phone type) ● Dimensions 456 (W) x 325 (D) x 560 (H) mm 18 (W) x 12-13/16 (D) x 22-1/16 (H) inches ●...
- Page 22 For EU Countries For China...
-
Page 23: Federal Communications Commission Radio Frequency Interference Statement
This product complies with the requirements of European Directives EMC 89/336/EEC and LVD 73/23/EEC. FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 24 SD001049...
