When connecting the SA-1000 with other equipment, be sure to read
1
the owner's manuals for the SA-1000 and each device being connected.
Turn O the Power to All Devices
Turn down the VOLUME knobs on all devices being connected to lower the
volume completely, then turn o their power.
SA-1000's Control Panel
Turn all VOLUME knobs to MIN
Keyboard to
be connected
Copyright © 2007 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in
any form without the written permission of ROLAND CORPORATION.

Connection Guide

Also lower the VOLUME on the keyboard you're connecting
to the minimum level, then turn o the power. Be sure to
refer to the owner's manual for the keyboard you're
connecting before carrying out this procedure.
Turn o the power

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SA-1000 and is the answer not in the manual?

Questions and answers

Related Manuals for Roland SA-1000

Summary of Contents for Roland SA-1000

  • Page 1: Connection Guide

    When connecting the SA-1000 with other equipment, be sure to read the owner's manuals for the SA-1000 and each device being connected. Turn O the Power to All Devices Turn down the VOLUME knobs on all devices being connected to lower the volume completely, then turn o their power.
  • Page 2 ２ Connect the Keyboard Use a connecting cable (optional) with 1/4" phone plugs to connect the keyboard's output jacks to the SA-1000's KEYBOARD IN jacks. To KEYBOARD IN jacks on rear panel Connect the Subwoofer (SA-1000W) Use the dedicated cable included with...
  • Page 3 SA-1000 and each device being connected. Next, turn on the power to the SA-1000. When Connecting a Second SA-1000 with Stereo Link To STEREO LINK OUT TO SIDE R jack on rear panel The SA-1000 is connected to the SA-1000 on the left, as seen from the audience.
  • Page 4 Adjust the Volume First, raise the keyboard's volume, then increase the SA-1000's INPUT VOLUME settings. Raise the keyboard's volume to 60-70% of the maximum level. However, if speakers are connected, set the volume to a listenable level. If using Stereo Link, the settings for the MASTER section of both SA-1000s need to be set so they match.
