VONETS——WiFi Bridge/Repeater/Router
WiFi Bridge/Repeater/Router/ Serial port
VAP11S-232/VAP11S-5232/VAP11S-D232
Declaration
Copyright ©2022Shenzhen HouTian Network Communication Technology CoLtd
All rights reserved, with retained ownership Without Shenzhen HouTian Network
communication Technology CoLtd written authorization, any company or personal can't
copy, writer or translation part or all contents. Can't do commodity distribution for any
commercial or profitable purposes by any ways(electricity, mechanical, photoprint, record or
other methods).
VONETS is the registered trademark of Shenzhen HouTian Network Communication
Technology CoLtd. The other all trademarks or registered trademarks mentioned in this
documents are belong to the individual owners. The product specifications and information
technology mentioned in this manual are just for reference, if any updates, without other not
ice. Except for special agreements, this manual is just for user guidance, any statements, in
formation and so on in this manual can't constitute the warranty of any forms.
Note
The parameters used in the screenshots shown in this manual are only used as reference
examples for setting examples. They may not be exactly the same as the actual situation.
Please set the parameters according to your actual needs.
transparent transmission
Quick Setting Guide
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vonets VAP11S-232
Summary of Contents for Vonets VAP11S-232
- Page 1 VONETS is the registered trademark of Shenzhen HouTian Network Communication Technology CoLtd. The other all trademarks or registered trademarks mentioned in this documents are belong to the individual owners. The product specifications and information technology mentioned in this manual are just for reference, if any updates, without other not ice.
- Page 2 VONETS——WiFi Bridge/Repeater/Router Due to the different software versions, the screenshots shown in this manual may not be exactly the same as the web interface of the product you purchased. Please configure your product according to the actual web interface. The adapter power supply in all the schematic diagrams shown in the following figures are externally connected to the power supply.
-
Page 3: Table Of Contents
VONETS——WiFi Bridge/Repeater/Router Contents Chapter 1 Application Mode ......................1 1.1 Bridge + Repeater Mode ....................... 1 1.2 Router Mode .......................... 2 1.3 Serial port forwarding mode ....................2 Chapter 2 Bridge+Repeater Mode Configuration Instruction ............3 2.1 Device connect ........................3 2.2 Bridge+Repeater Application Configuration ............... -
Page 4: Chapter 1 Application Mode
VONETS——WiFi Bridge/Repeater/Router Chapter 1 Application Mode 1.1 Bridge + Repeater Mode There are three application modes for the bridge mode of VONETS device: WiFi repeater, WiFi bridge and WiFi AP. ⚫ WiFi Repeater: VONETS device as WiFi Repeater, it must be configured to source WiFi hostpot parameters, can be used to extend the wireless signal coverage of existing APs or wifi router . -
Page 5: Router Mode
LAN port by default, and the WAN and LAN are interchangeable; ⚫ The VONETS device is used as a wireless router. It can set up a WiFi hotspot of the WAN port and use it as a secondary router. Its Ethernet cable is a LAN port. -
Page 6: Chapter 2 Bridge+Repeater Mode Configuration Instruction
VONETS——WiFi Bridge/Repeater/Router Chapter 2 Bridge+Repeater Mode Configuration Instruction 2.1 Device connect Power on VONETS device by 12V/1A power supply, then connect to PC, there are two connection ways as below: A. Computer is wired connected to LAN port of VONETS device;... -
Page 7: Bridge+Repeater Application Configuration
VONETS——WiFi Bridge/Repeater/Router （Recommend Method） B. The computer wirelessly connects to the WiFi signal of VONETS device, its default hotspot parameters are as follows: WiFi SSID: VONETS_****** (corresponding to VONETS device MAC address) WiFi password: 12345678 （After the WiFi parameters are configured, the WiFi will be disconnected, that is normal.）... - Page 8 ⚫ The option “The configuration parameters of WiFi repeater security is synchronized with source hotspot” is default ticked, it means the SSID of VONETS repeater is associated with the SSID of the source hotspot, and the WiFi password is the same as the password of the source hotspot;...
- Page 9 VONETS——WiFi Bridge/Repeater/Router 5. Click “Reboot”, VONETS device will connect to the configured WiFi hotspot automatically, if connection is successful, the WiFi LED light will flash quickly; Remark 1: LED Light Form Model Blue Light Green Light Yellow Light 2.4G connection...
-
Page 10: Ap Application Configuration
2.3 AP Application Configuration VONETS device can be configured as an AP application, the wireless terminal device can connect to VONETS device hotspot to connect to the network; however, it is best to change its WiFi name and password for network security. - Page 11 VONETS——WiFi Bridge/Repeater/Router 4. “WiFi Tx Power” of VONETS device can be changed, jump to “System Settings”---- “Advance Settings”, choose suitable transmit power, then click “Apply”; Reboot device, jump to “System Settings”---- “Reboot Device”, click “Reboot”, when it is finished, all revised options will take effort.
-
Page 12: Chapter 3 Router Mode Configuration Instruction
VONETS——WiFi Bridge/Repeater/Router name: http://vonets.cfg. Or in Windows command window, enter the command: ping vonets.cfg, to get the IP address of the device, then log in configuration page by this IP address. Chapter 3 Router Mode Configuration Instruction 3.1 Change device mode 1. -
Page 13: Wan Port Settings
VONETS——WiFi Bridge/Repeater/Router 2. After computer is connected to VONETS device, open browser, input configured page domain name: http://vonets.cfg (or IP: 192.168.254.254), then press Enter; 3. Enter User name and Password in login page (both are “admin”), click “Login” button to enter configured page;... -
Page 14: Wan/Lan Exchange
LAN port, and the WAN/LAN can be interchanged; The WiFi of the VONETS device is the WAN port by default, and the Ethernet cable is the LAN port by default. If the interface mode is changed to "WAN/LAN interchange", the Ethernet cable is the WAN port, and the WiFi is the LAN port (no modification required);... -
Page 15: Pppoe Wan Port Wired Connect Network--Pppoe
VONETS——WiFi Bridge/Repeater/Router The default WAN port connection method of VONETS device is DHCP. WAN port can automatically obtain an IP address after connecting to the source network. 3.2.4 PPPoE WAN port wired connect network——PPPoE In “WAN settings”, select “Basic settings”, change the connection type to “PPPoE (ADSL)”, then enter the Internet account and password provided by the ISP (Internet Service Provider), click the “Apply”... - Page 16 ⚫ The option “The configuration parameters of WiFi repeater security is synchronized with source hotspot” is default ticked, it means the SSID of VONETS repeater is associated with the SSID of the source hotspot, and the WiFi password is the same as the password of the source hotspot;...
-
Page 17: Set Wifi Hotspot Parameters
LED light.) Remark 3: After VONETS device sets the WAN port to access the WiFi hotspot in the routing mode, its LAN port IP is still 192.168.254.254, and the terminal device also obtains the IP address of the same network segment, can login configuration page by 192.168.254.254 or... - Page 18 VONETS——WiFi Bridge/Repeater/Router 2. Revise WiFi password, in “WiFi Repeater”----“WiFi Security”, enter new WiFi password in “Pass Phrase”, click “Apply”; 3. Reboot device, jump to “System Settings”---- “Reboot Device”, click “Reboot”, when it is finished, all revised options will take effort.
-
Page 19: Chapter 4 Serial Port Forwarding Mode Configuration Instruction
Chapter 4 Serial port forwarding mode Configuration Instruction 4.1 Data forwarding type setting Note: Please refer to the document "VONETS-UART_UDP Data Forwarding Instructions (3.0)_20210901.pdf" for the description of data forwarding types. 4.2 Serial port settings Note: The data forwarding service is enabled and effective. -
Page 20: Default Serial Port Configuration For Different Devices
VONETS——WiFi Bridge/Repeater/Router Note: The data forwarding service is enabled and effective. 4.4 Default serial port configuration for different devices... -
Page 21: Chapter 5 Other Components And Installation Method
VONETS——WiFi Bridge/Repeater/Router Chapter 5 Other components and installation method 5.1 Other components 1.Industrial power DC 2. Industrial Chassis Rail 3. Antenna extension connector Hook Kit cable(optional) (standard accessories) (standard accessories) 4. VDB9-232 (optional) 5. VDB9-232-X2 (optional) 6. VRJ45-5P (optional) 7. VRJ45-422-1 (optional) - Page 22 VONETS——WiFi Bridge/Repeater/Router Accessories Instruction Sheet model category Specification Description Function description RJ45 crystal head + DB9 The UART (TTL3.3V level) of the DB9 female VDB9-232 interface (built-in RS232 RJ45 female socket is converted seat chip) into RS232 RJ45 crystal head + The 2*UART (TTL3.3V level) of...
- Page 23 VONETS——WiFi Bridge/Repeater/Router Schematic diagram of accessories VDB9-232-X2 function...
- Page 24 VONETS——WiFi Bridge/Repeater/Router VRJ45-5P VRJ45-422-1...
-
Page 25: Industrial Chassis Rail Hook Kit Installation
VONETS——WiFi Bridge/Repeater/Router 5.3 Industrial chassis rail hook kit installation 1. Install the hook kit onto the chassis rail and fasten the buckle 2. Install VONETS device onto the hook kit 3. Fixed VONETS device on the hook kit;... -
Page 26: Installation Diagram Of Optional Accessories For Each Model
VONETS——WiFi Bridge/Repeater/Router 5.4 Installation diagram of optional accessories for each model ⚫ VDB9-232: The TTL3.3V level of the UART port of the RJ45 female socket is converted into a RS232-DB9 female socket ⚫ VDB9-232-X2: The TTL3.3V level of the UART port of the RJ45 female socket is converted into a dual RS232-DB9 socket ⚫... -
Page 27: Appendix Frequently Asked Questions
3. Do VONETS device support firmware upgrade, how to upgrade? 4. VONETS devices support firmware upgrade, and support online upgrade, please visit website: www.vonets.com to refer to the related documents 5. The device WiFi hot spot can be found, but the smart phone or PC can’t connect to this device hotspot? ⚫... - Page 28 7. The smart phone or PC has been connected the device by WiFi or Ethernet cable, but user can’t log in the device WEB page, or after log in the WEB it shows error? ⚫ Reason 1. The users don’t use the browser recommended by VONETS(IE,Google Chrome, Safari, the mobile phone browser);...
- Page 29 VONETS——WiFi Bridge/Repeater/Router 2）Selecting a suitable power supply is the key to good and stable wireless transmission and stable operation of the product. Improper power supply will cause damage to the product or poor wireless performance. The selected power supply must meet the voltage range and input power requirements of the power supply input, and the ripple must be less than the required maximum power supply ripple (100mV);...
