Summary of Contents for Vonets VGA1000
- Page 1 VONETS 450M 5G+300M 2.4G High Power WiFi bridge, repeater Professional 2.4G/5G High WiFi Repeater PM2.4G/PM5G VGA1000/VGA2000 Quick Setting Guide...
- Page 2 Can’t do commodity distribution for any commercial or profitable purposes by any ways(electricity, mechanical, photoprint, record or other methods). VONETS is the registered trademark of Shenzhen HouTian Network Communication Technology Co.Ltd. The other all trademarks or registered trademarks mentioned in this documents are belong to the individual owners.
- Page 3 Support compensation VONETS High power series WiFi product Features PM5G/VGA1000 is dual band WiFi Repeater product, support both 2.4G and 5G Band. 2.4G band is normal power, barrier-free transmission distance is up to meters; 5G band is high power, barrier-free transmission distance is up to 1000 meters, in the unmanned aerial vehicle on the measured distance of 800 meters;...
- Page 4 1) VGA1000 connects to PM5G in pairs; 2) VGA1000 is for ground station, PM5G is air module or remote module; 3) VGA1000/PM5G support hot name name imitate function 4) Multiple VGA1000 or PM5G can form star network;...
- Page 5 VONETS 450M 5G+300M 2.4G High Power WiFi bridge, repeater VGA1000/VGA2000 Appearance PM5G/PM2.4G Module Quick Setting Guide Step1. Connect --When configuration, the connection method is as below diagram:...
- Page 6 VONETS 450M 5G+300M 2.4G High Power WiFi bridge, repeater Step 2. The module is powered on (For module supply voltage, current, please check <Product Selection Form>, PIN definition, please see Diagram 1) Step 3. Connect the WiFi hot spot of module by smart phone or PC (There are two hot spot 2.4G and 5G hot spot, you can choose any one to...
- Page 7 At this time, when log in configured page, we suggest you enter configured domain name: http://vonets.cfg. Or in Windows command window, enter the command: ping vonets.cfg, to get the IP address of the device, then log in configuration page with this IP.
- Page 8 450M 5G+300M 2.4G High Power WiFi bridge, repeater VGA1000/VGA2000 Series Product Introduction VGA1000/VGA2000 is high power WiFi Repeater, bridge, is also can be used for remote camera connection, the performance of wireless transmission is consistent with PM5G/PM2.4G, but it is built-in battery, suitable for mobile portable applications, to facilitate rapid long-distance emergency network;...
- Page 9 VONETS 450M 5G+300M 2.4G High Power WiFi bridge, repeater VGA Quick Setting Guide Step1. Connect --When configuration, the connection method is as below diagram: Step 2. VGA is powered on--Operate the device according to <VGA normal operation form> Step 3. Connect the WiFi hot spot of VGA by smart phone or PC (There are two hot spot 2.4G and 5G hot spot, you can choose any one to...
- Page 10 VONETS 450M 5G+300M 2.4G High Power WiFi bridge, repeater...
- Page 11 3. Does the VONETS series product support firmware upgrade, how to upgrade? All VONETS series products support firmware upgrade, and support online upgrade, please visit website: www.vonets.com...
- Page 12 6. The smart phone or PC has been connected the device by WiFi or Ethernet cable, but user can’t log in the device WEB page, or after log in the WEB it shows error? Reason 1. The users don’t use the browser recommended by VONETS(IE, Google ...
