NOTES

1. • Try a battery pack from a working radio. If the radio in ques-
tion works with that pack, the original battery is suspect.
• Charge the suspect battery as recommended in this man-
ual. If this original battery cannot power the radio, try charg-
ing it again with another charger. If the battery still doesn't
hold a charge, the pack should probably be replaced.
• If the battery appears to be "good" after using the second
charger, the first charger may be faulty. Contact a dealer or
Ritron about an accessory that is not operating properly.
2. • Reception can often be improved if you relocate by a short
distance. This effect is more noticeable inside buildings.
• The range for JMX/ SST radios is about two miles, line-of-sight.
3. If your radio does not detect calls from other radios on the
channel, turn off Quiet Call by pressing and holding both
volume buttons at the same time — a double beep indicates
Quiet Call is off.
4. • Without use of a repeater: To hear a call, select a channel
programmed to receive the caller's transmit frequency. To
call another unit, select a channel programmed to transmit
the other radio's receive frequency.
• Using a repeater: A radio channel can hold two separate
operating frequencies, one for receive and one for transmit.
Your channel must work with the repeater's transmit and
receive frequencies.
5. • Maximum power drain occurs when the radio transmits, so
don't hold down the PTT more than needed to transmit.
• Battery power is used while the handheld is left on to
receive calls. If practical, switch off the unit.
6. Battery capacity is greatly reduced in extreme cold.
• To use the radio in very cold weather, periodically warm it
under your coat if possible.
• An optional remote speaker/ microphone allows keeping the
radio under your coat while transmitting and receiving.
7. • To "talk" with each other, radios must be programmed
identically for Quiet Call code, as well as frequency. Each
code is unique; radios respond only to the code programmed.
• Press and hold both volume buttons at the same time.
A single beep indicates Quiet Call squelch is on.
A double beep indicates Quiet Call squelch is off.
page 3 RITRON, INC. 1-800-USA-1-USA (1-800-872-1872)
page 10

TROUBLESHOOTING

If you have trouble operating the handheld, review the Control & Operation, pages 2 and 3.
If you think the radio is malfunctioning, check the list below.
Problem
The radio does not work at all.
Operating features do not work exactly
as expected.
Reception is poor.
You cannot hear calls from other radios.
Your calls cannot be heard in other radios.
Battery loses charge sooner than expected.
An error tone sounds when the radio is
first switched on.
An error tone occurs while transmitting.
You cannot screen out calls from users
outside of your Quiet Call group.
You cannot hear Quiet Call messages
while in Quiet Call (coded) squelch.
Others in your Quiet Call group cannot hear
your Quiet Call messages.
For assistance, call 800-USA-1-USA 800-USA-1-USA (800-872-1872) 800-USA-1-USA 800-USA-1-USA 800-USA-1-USA

CHART

Possible Solutions
GENERAL
Make sure that the battery is installed correctly, as shown in FIG-5. page 8.
Recharge or replace the battery. (See pages 8 & 9.)
The radio has been dealer programmed for customized operation.
(Consult dealer.)
Move to a different location. (See Note 2.)
Confirm the proper antenna is connected to the radio. (See page 2, "Antenna.")
Turn off Quiet Call (coded) squelch. (See Note 3.)
Ensure radio receives on the same frequency as the caller transmits. (See Note 4.)
Recharge the battery. (See Note 1.)
Make sure that your radio transmits on the receive frequency of the radio(s) you
want to call. (See Note 4.)
Recharge the battery.
BATTERY
Review battery charging instructions, page 9.
Conserve the battery. (See Note 5.)
If the radio is used in extreme cold, warm the radio under your coat. (See Note 6.)
Replace the battery; see FIG-5, page 8. (See Note 1.)
ERROR TONES
See "Error Tones" on page 3.
Refer to "Transmitter Time-Out," page 3.
QUIET CALL
Make sure that the channel is programmed with Quiet Call.
Activate coded squelch. (See Note 7.)
Confirm that the channel is programmed to detect the same code as the calling
radio(s) transmits. (See Note 7.)
Verify that you transmit the same code as the radio(s) you call are programmed
to detect. (See Note 7.)
