Flyer AC801 Instruction Sheet

Front Storage Basket Instruction Sheet
Model #AC801
Compatibility: Flyer TM M880, Flyer TM L885
WARNING!
• Read all safety warnings and instructions before using the
product. Failure to follow warnings and instructions may result
in serious injury or death.
• You must also reference the owner's manual that was shipped
with your Flyer™ eBike before using this accessory:
• Incorrect assembly, maintenance, or use of your Flyer™
accessory can cause component failure, loss of control,
serious injury, or death. Please note, the assembly of Flyer™
accessories require special tools and mechanical skills. It is
highly recommended that the assembly and adjustment are
completed by a reputable bicycle mechanic when possible.
• Only for use with the Flyer™ eBike.
• Adding load to accessories may lessen the stability or alter the
riding characteristics of the bicycle.
• Maximum Load Capacity: 25 lbs
• Step off of the bike and put the bike on its kickstand before
assembling, adjusting or interacting with accessories.
Disconnect the Headlight
A. Turn off the bike.
B. Remove the battery.
C. Unplug and remove the front headlight from the bike frame.
A B
HARDWARE
A
1X – Headlight Extension Wire
B
3X – Zip Tie
B 5X - M5 Lock C D
4X - M5X15 Pan 4X – M5 Washer
Washer
Head Screw
Hardware below can be found installed on the eBike
E F G 1X – Headlight
1X - M5X15 Pan 1X – M5 Washer
Assembly
Head Screw
assembled to headlight assembled to headlight
TOOLS
M4 Allen Key
C
1
