Flyer AC804 Instruction Sheet

Kid & Cargo Carrier Instruction Sheet
Model #AC804
Compatibility: Flyer L885
TM
WARNING!
• Read all safety warnings and instructions before using the
product. Failure to follow warnings and instructions may result
in serious injury or death.
• You must also reference the owner's manual that was shipped
with your Flyer™ eBike before using this accessory:
• Incorrect assembly, maintenance, or use of your Flyer™
accessory can cause component failure, loss of control,
serious injury, or death. Please note, the assembly of Flyer™
accessories require special tools and mechanical skills. It is
highly recommended that the assembly and adjustment are
completed by a reputable bicycle mechanic when possible.
• Only for use with the Flyer™ eBike.
• Adding load to accessories may lessen the stability or alter the
riding characteristics of the bicycle.
• Maximum Load Capacity: 130lbs
• Rider and children should always wear helmets that have been
approved to nationally recognized standards.
• Only carry children ages 5–10 years
• Step off of the bike and put the bike on its kickstand before
assembling, adjusting or interacting with accessories.
HARDWARE
A
4X – M5 22mm Pan Head Screw
C
8X - M5 35mm Pan Head Screw
8X - M5 Lock
D E
Washers
4X - M5 27mm Pan Head Screw
B
F
24X – M5 Washer 8X – M5 Lock Nut
TOOLS
M4 Allen Key
Hex Wrench
PARTS
2X – Padded Seat Assembly
A
1X – A Frame, Rear
B
2X – Hoop
D
1X – Steel Ring, Left
E
1X – Steel Ring, Right
F
1X – Fabric
G
M3 Allen Key
1X – A Frame, Front
C
