polyga Carbon X Quick Start Manual

Getting started with the Carbon X
Assemble and prepare the system. Take out parts from the travel case
and double check the contents with the packing list, making sure
everything is present.
This quick-start guide provides you with the resources to get started
on the Carbon X 3D scanner system.
CARBON X CONTENTS: INSIDE TRAVEL CASE
3D Scanner
Carbon X Scanner ScanBox
Active USB Cable (A to B Cable)
x2 USB 3.0 (A to Micro-B Cable)
x2 Camera Trigger Cable
Hardware
Mounting Rail
x2 Cameras
x5 M6 Allen Key Head Screws
x4 M6 Washers
x2 Allen Keys (M2.5 + M6)
Tripod with Tripod Head
Power Supply
x1 DC Power Supply Cord
x1 Power Extension Cable
Other Accesories
FlexScan 3D License Dongle
x4 Calibration Board: 5mm, 10mm, 15mm, 20+25mm
x2 Calibration Board Holder: Small, Large
SCAN TO DOWNLOAD FLEXSCAN3D
https:/ /www.polyga.com/my-account/downloads/
1

STEP 1: ASSEMBLE SCANNER BOX

Mount Camera Rail onto Scanner Body using x5 M6 screws,
x4 washers, with Allen Key found in Hardware Kit.
Line up threads and mount Scanner Body assembly onto
Tripod Head and Tripod.
Slide x2 Cameras onto Camera Rail and secure by turning
Camera mounting brackets clockwise untill snug making sure
cameras are in symmetrical positions on rail.
Quick Start Manual
Carbon X
DOWNLOAD

WHATS INCLUDED

x 1
Carbon X Scanner
ScanBox
x 1
DC Power Supply
with Extension Cable
x 2
USB 3.0 Cable
(A to Micro B)
x 2
Camera Trigger Cable
(3 Prong Notched)
x 1
USB License Dongle
1
x 1
Mounting Rail with
Scanner Cameras
x 1
Tripod with Tripod Head
x 1
Active USB 3.0 Cable
(A to B Cable)
x 1
Hardware Set
(M2.5, M6)
2
