- Page 1 QUICKSTART GUIDE - CARBON XL...
- Page 2 Polyga Accounts Page ( h ttps://www.polyga.com/my-account/downloads/ ) or by contacting your distributor. To create a download account, please contact us at h ttps://www.polyga.com/contact/ Instructions for installing and activating FlexScan3D using an installation ID or dongle can be ...
- Page 3 When you receive your HDI CarbonXL 3D Scanner, check that all components are included: Number Item Mount with Projector 2 x USB 5.0 Cameras 10mm Calibration Board 15mm Calibration Board HDMI cable 2 x USB 3.0 cable 2 x Camera Mount 2 x Camera Brackets FlexScan3D Dongle Calibration Stand...
- Page 4 2.Connect the Scanner to the Tripod Carefully lift your scanner and locate the mount adapter. Gently place the scanner onto the tripod head. Snap the tripod head lock into place to secure the scanner. 3.Attach Cameras to the Mounts Attach the cameras onto the camera brackets using the screws.
- Page 5 4.Attach the Camera Mount onto the Bracket Attach each of the assembled camera mount onto the bracket using Hex Keys. Ensure that the metal pin is in place between the bracket and mount, allowing the camera to rotate. Tighten the screws until they are firm, but do not overtighten...
- Page 6 5.Attach Brackets to the Scanner Rail Attach the mounts onto both sides of the scanner. Tighten the screws until they are firm, but do not overtighten. Adjust the distance between the cameras by loosening the bracket screws as needed. 6.Attach the Lenses to the Cameras ...
- Page 7 8.Connect all the necessary cables onto the 3D scanner Your Carbon XL consists of a Trigger Box and a Projector. The Trigger Box is positioned below the projector and the both the units seperate power input. First plug in the 5V adapter cable into the Trigger Box power jack as shown below.
- Page 8 PC on which you intend to use the 3D Scanner. Once all the necessary connections are made you should be able to Power ON the Projector and add the scanner on FlexScan3D. Visit h ttp://www.polyga.com/FS3DHelp/Manual/ for next steps in adding your scanner and taking scans on FlexScan3D.
