TC-300
Wheel Crusher
buyTSI.com - 800.223.4540
Read this manual before operating
Tire Service International, LLC
Contact us for any assistance
3451 S. 40TH ST.
Phoenix, AZ 85040
800.223.4540
Office: 602.437.5020
Email: sales@buytsi.com
Fax: 602.437.5025
Revised: April 2022

Advertisement

loading
Need help?

Need help?

Do you have a question about the TC-300 and is the answer not in the manual?

Questions and answers

Related Manuals for TSI Instruments TC-300

Summary of Contents for TSI Instruments TC-300

  • Page 1 TC-300 Wheel Crusher buyTSI.com - 800.223.4540 Read this manual before operating Tire Service International, LLC Contact us for any assistance 3451 S. 40TH ST. Phoenix, AZ 85040 800.223.4540 Office: 602.437.5020 Email: sales@buytsi.com Fax: 602.437.5025 Revised: April 2022...
  • Page 2 Installation Requirements Electrical Installation: The TC-300 Electric requires a minimum of 50 AMP, 230 volt, 60 cycle at the machine. The TC-300 Electric is equipped with a 10 HP, 230/460 volt, 60 cycle standard.

  • Page 3: Set-Up Instruction

    Set-Up Instruction Position TC-300 near tire and wheel supply to be Check to be sure breather is installed in top of crushed. Place front support jack in position. hydraulic reservoir. Crank jack to bring TC-300 main beam to approximate level position.
  • Page 4 Operate hydraulic valve handles to return crush- crushed. ing wedge to the starting position. Slide the wheel and tire out of the TC-300 This photo illustrates the wheel crushed and sep- chamber. NOTE: The wheel and tire can be taken arated from the tire.
  • Page 5 Operate hydraulic valve handles to return crushed. crushing wedge to the starting position. Slide the wheel and tire out of the TC-300 This photo illustrates the wheel crushed and sep- chamber. NOTE: The wheel & tire can be taken arated from the tire.

  • Page 6: Maintenance

    Maintenance The Hour Meter indicates elapsed hours for Periodically insert grease at the cylinder pivot. proper engine maintenance service intervals. Before daily operation check all bolts for tight- This adjustment controls low to high pressure ness on the movable wedge. shift point.
  • Page 7 Maintenance This photo illustrates the adjustment location of Replace oil filer every 6 months. Use TSI P/N the hydraulic pump pressure to the valve. The 10130E for the replacement element gauge should read 2800-3000 PSI when the ram is fully extended. To increase pressure, first remove large Hex nut.
  • Page 8 Maintenance The crushing wedge has space wear bars on both the upper and lower slides. These wear bars may need adjusting. Loosen 6 upper and 6 lower cap screws and slide wear bars up to beam flange. Leave 1/32 clearance between beam and wear bar.
  • Page 9 Optional - Roller Table Kit #6114 buyTSI.com 800.223.4540...
  • Page 10 Drawing buyTSI.com 800.223.4540...

  • Page 11: Parts List

    Parts List PARTS LIST PARTS LIST ITEM PART N. DESCRIPTION ITEM PART NO. DESCRIPTION 5519 FENDER WELDMENT RH & LH 3081 SAFETY CHAIN W/HOOK 5534 HANDLE WELD 3084 TIRE, 185 X 13 2 PLY 5535-01 PIVOT WELD 3162 BATTERY CABLE 16" (POS) 5578 VALVE MOUNT WELD 3163...

  • Page 12: Warranty And Return Policy

    Warranty and Return Policy Warranty & Workmanship you can depend on. With over 30 years of manufacturing experience we maintain the ability to provide competitive prices while employing and manufacturing the majority of our products in the USA. Pride in our workmanship and standing behind each and every product is not just our claim but our uncompromising responsibility.
