- Page 1 TG-80 Tire Grooving Station buyTSI.com - 800.223.4540 Read this manual before operating Tire Service International, LLC Contact us for any assistance 3451 S. 40TH ST. 800.223.4540 PHOENIX, AZ 85040 Office: 602.437.5020 Email: sales@buytsi.com Fax: 602.437.5025 Revised: March 2022...
- Page 2 Safety Requirements Thoroughly read all of this manual before using this machine. Only personnel trained should operate this machine. Personal Protective Equipment must be used including safety glasses. Never wet the motor, electric switch, or components. Cover these items if machine is to be washed.
- Page 3 Operating Instruction To begin grooving, first tire must be put on holding arms. To activate hydraulic system, push start button to Power Hydraulic System (to stop machine push or rotate knob to stop position). Place tire over holding arms. Hold tire in position and activate expanding holding arms by stepping on left hand foot pedal marked “Spread Tire”.
- Page 4 Repair Parts List (110v or 220v) buyTSI.com 800.223.4540...
- Page 5 Repair Parts List (110v or 220v) Item Description Each 10395 Bushing, Oilite or Bronze 10298-60 Electric Hyd Power Unit 1HP -60 hertz 10298-50 Electric Hyd Power Unit 1HP -50 hertz 706B Valve, 2 spool with handles inlet & outlet 706B-Kit Spool Seal Retainer for the 2 Spool Valve 3019-4000 Gauge 2.5 Dia x 1/4 NPT...
- Page 6 Notes buyTSI.com 800.223.4540...
- Page 7 Warranty and Return Policy Warranty & Workmanship you can depend on. With over 30 years of manufacturing experience we maintain the ability to provide competitive prices while employing and manufacturing the majority of our products in the USA. Pride in our workmanship and standing behind each and every product is not just our claim but our uncompromising responsibility.
- Page 8 Register your product online! www.buytsi.com/registration Visit www.buyTSI.com for any additional information. Also be sure to follow us on all the Socials, and subscribe to our YouTube channel for all our product videos. Copyright © 2022 Tire Service International, LLC No part of this manual may be reproduced without specific approval from Tire Service International, LLC.
