- Page 1 CH-60 Cheetah Bead Seater with 60 Gallon Tank buyTSI.com - 800.223.4540 Read this manual before operating Tire Service International, LLC Contact us for any assistance 3451 S. 40TH ST. PHOENIX, AZ 85040 800.223.4540 Office: 602.437.5020 Email: sales@buytsi.com Fax: 602.437.5025 Revised: July 2022...
-
Page 2: Safety Requirements
While securely holding handles with both hands, press the red button on the Jet Pak with thumb or heel of hand. WARNING: The discharge of the CH-60 releases a tremendous amount of stored air pressure in a very short time. This process is loud and ear plugs and safety goggles are required. - Page 3 ASSEMBLY - DISCHARGE SYSTEM Locate discharge Secure the opposite barrel and the end to the manifold adjustable discharge opening on the barrel. Position the discharge barrel barrels about 3½ to 4 tighten the clamps feet apart so that all to FULLY SECURE four angled rim rests the 2"...
- Page 4 PREPARATION - HORIZONTAL DISCHARGE Gently tilt Position the tank to the assembly a close proximity of downward toward the tire and wheel. the wheel rim Locate and connect allowing the one end of the 2 ½" discharge barrel to hose with cam-lock rest on the wheel to the large 2 ½"...
- Page 5 PREPARATION - HORIZONTAL DISCHARGE Physically pull up on the assembly to verify the strength of your connections. If any weakness or instability is observed re-secure and repeat until the assembly is securely in place. PREPARATION - VERTICAL DISCHARGE NOTE: Loosening all T-handle bolts on the Carefully rotate the discharge assembly is recommended for assembly so that the...
- Page 6 Spare Parts List (110v - 220v) Item Description 11628 Wheel & Tire Assembly 15.190 Regulator - Air PSI 125 MAX 16039 30 gallon tank 239.175 Pressure Relief Valve Set at 175 PSI 6450 Foot Pad 7.023A Air Pressure Gauge 2” dia x 1/8 npt 0-160 psi CH-2.0 JP 2.0 Jet Pack External Quick Release Beadseater VP 3.103 Jet...
-
Page 7: Warranty And Return Policy
Warranty and Return Policy Warranty & Workmanship you can depend on. With over 30 years of manufacturing experience we maintain the ability to provide competitive prices while employing and manufacturing the majority of our products in the USA. Pride in our workmanship and standing behind each and every product is not just our claim but our uncompromising responsibility. -
Page 8: Register Your Product Online
Register your product online! www.buytsi.com/registration Visit www.buyTSI.com for any additional information. Also be sure to follow us on all the Socials, and subscribe to our YouTube channel for all our product videos. Copyright © 2022 Tire Service International, LLC No part of this manual may be reproduced without specific approval from Tire Service International, LLC.
