FireFlex TOTALPAC X Owner's Operation And Maintenance Manual
Advanced integrated fire protection system
Hide thumbs
Also See for TOTALPAC X:
- Owner's operation and maintenance manual (36 pages) ,
- Owner's operation and maintenance manual (26 pages) ,
- Owner's operation and maintenance manual (24 pages)
Related Manuals for FireFlex TOTALPAC X
Summary of Contents for FireFlex TOTALPAC X
- Page 1 Advanced Integrated Fire Protection System ® OTAL Owner's Operation Maintenance Manual ELUGE YSTEM YDRAULIC RELEASE FM-076G-0-18A...
- Page 2 ® OTAL Page ii Integrated Fire Protection System & M WNER PERATION AINTENANCE ANUAL Copyright © 2021 F Systems Inc. All Rights Reserved Reproduction or use, without express written permission from F Systems Inc, of any portion of this manual is prohibited. While all reasonable efforts have been taken in the preparation of this manual to assure its accuracy, F Systems Inc assumes no liability resulting from any errors or omissions in this manual, or from the use of the information contained herein.
-
Page 3: Table Of Contents
® OTAL Page iii Integrated Fire Protection System & M WNER PERATION AINTENANCE ANUAL Table of Contents Deluge System - Hydraulic Release General Section ......................Section 1- General description 2- Listings and approvals 3- Applicable standards 4- Environment 5- Features 6- Configuration description 7- System release Mechanical Section........................ - Page 4 ® OTAL Page iv Integrated Fire Protection System & M WNER PERATION AINTENANCE ANUAL This page is left intentionally blank. FM-076G-0-18A...
-
Page 5: General Section
® OTAL Page 1 of 2 Integrated Fire Protection System General Section - Deluge System - Hydraulic Release 2- Listings and approvals 1- General description In addition to being fabricated under tight ISO-9001 ® This T X integrated fire protection system by OTAL manufacturing and quality control procedures, your Systems Inc. -
Page 6: 5- Features
® OTAL Page 2 of 2 Integrated Fire Protection System General Section - Deluge System - Hydraulic Release 5- Features 6- Configuration description ® ® The T X unit is superior to many other products X deluge system is built around the Viking trim OTAL OTAL which are actually available on the fire protection market. -
Page 7: Mechanical Section
® OTAL Page 1 of 8 Integrated Fire Protection System Mechanical Section - Deluge System - Hydraulic Release 1- Installation, operation & maintenance instructions 1.2 Preliminary inspection before placing the system in Note: Numbers indicated between brackets refer to figure 1 service DETAILED SYSTEM TRIM SCHEMATICS from this section. -
Page 8: Placing The System In Service
® OTAL Page 2 of 8 Integrated Fire Protection System Mechanical Section - Deluge System - Hydraulic Release 1.4 System Operation 1.3 Placing the system in service 1.4.1 In the SET condition 1. Verify that the main water supply valve (D1) is CLOSED. Verify that the system has been properly drained. -
Page 9: Emergency Instructions
® OTAL Page 3 of 8 Integrated Fire Protection System Mechanical Section - Deluge System - Hydraulic Release 1.6 Placing the system back in service after operation 1.5 Emergency instructions 1. Verify that the system has been properly drained. Verify To take system out of service that all system piping auxiliary drain valves are CLOSED. - Page 10 ® OTAL Page 4 of 8 Integrated Fire Protection System Mechanical Section - Deluge System - Hydraulic Release 1.7 Inspections and tests When trip testing is complete 1. Perform steps 1 through 4 of paragraph 1.5 EMERGENCY NOTICE: The owner is responsible for maintaining the fire INSTRUCTIONS to take the system out of service.
-
Page 11: Maintenance
® OTAL Page 5 of 8 Integrated Fire Protection System Mechanical Section - Deluge System - Hydraulic Release 1.8 Maintenance 1.8.2 Quarterly 1. Check alarm pressure switch (C1) and optional water NOTICE: The owner is responsible for maintaining the fire motor gong (C2) by opening the alarm test valve (B5). -
Page 12: Normal Condition
® OTAL Page 6 of 8 Integrated Fire Protection System Mechanical Section - Deluge System - Hydraulic Release 2- Deluge system with hydraulic release Note: Numbers indicated between brackets refer to figure 1 DETAILED SYSTEM TRIM SCHEMATICS from this section. 2.1 Normal condition 1. - Page 13 ® OTAL Page 7 of 8 Integrated Fire Protection System Mechanical Section - Deluge System - Hydraulic Release Figure 1 - Detailed system trim schematic Typical deluge system with hydraulic release (3" (80 mm) system shown) FIELD CONNECTION TO SPRINKLER PIPING NETWORK CONTRACTOR'S CONTRACTOR'S HYDROSTATIC TEST PORT...
- Page 14 ® OTAL Page 8 of 8 Integrated Fire Protection System Mechanical Section - Deluge System - Hydraulic Release This page is left intentionally blank. FM-076G-0-58A...
-
Page 15: Trim Options
® OTAL Page 1 of 2 Integrated Fire Protection System Trim Options Deluge trim options 1. Shut-off valve & sight glass Figure 1 – Shut-off valve & sight glass (system is shown without cabinet for clarity) The shut-off valve & sight glass option is intended to be used for applications where testing of the system operation Supervised Shut-off Valve (D4) - Page 16 ® OTAL Page 2 of 2 Integrated Fire Protection System Trim Options This page is left intentionally blank. FM-076G-0-62B...
-
Page 17: Control Section
® OTAL Page 1 of 2 Integrated Fire Protection System Control Section 1. Remotely supervised unit without control panel 1.1 Product description 1.2 Technical data CABINET SECTION for ® Steel enclosure: Refer to section The T X deluge unit is provided without control OTAL panel. - Page 18 ® OTAL Page 2 of 2 Integrated Fire Protection System Control Section Figure 2 - Junctions box layout for system without control panel AC POWER 120VAC, 60Hz or POWER LIMITED CIRCUITS 220/240VAC, 50/60Hz All conduits are installed by the Contractor TBB Terminals TBA &...
-
Page 19: 1- Remotely Supervised Configuration
® OTAL Page 1 of 2 Integrated Fire Protection System Electrical Section - Deluge System - Hydraulic Release 1. Remotely supervised configuration ® This T X unit has been provided without an OTAL Note : No connection should be made directly in the trim integrated control panel since all internal supervisory components as this would void warranty and might prevent devices are to be connected and supervised from a remote... - Page 20 ® OTAL Page 2 of 2 Integrated Fire Protection System Electrical Section - Deluge System - Hydraulic Release This page is left intentionally blank. FM-076G-0-99A...
-
Page 21: Dimensional Data & Cabinet
® OTAL Page 1 of 4 Integrated Fire Protection System Dimensional Data & Cabinet ® 1- Cabinet for T X unit OTAL ® The T X unit cabinet is made of sturdy 14 gauge OTAL ® IMPORTANT ! T X unit is designed to be installed OTAL steel. - Page 22 ® OTAL Page 2 of 4 Integrated Fire Protection System Dimensional Data & Cabinet Figure 1 - Cabinet and inlets/outlets dimensions ØB TBA, TBB & TBC DRAIN - SCH.40 GROOVED OUTLET ØC WATER INLET SCH.40 GROOVED OUTLET ØA TBA, TBB & TBC ØC ØA ØB...
- Page 23 ® OTAL Page 3 of 4 Integrated Fire Protection System Dimensional Data & Cabinet Figure 2 - Floor anchoring dimensions Table 3 - Floor anchoring dimensions 4½" (114mm) Unit size 1½" 41" 16" (1041mm) (406mm) 4½" (114mm) (40mm) 2" 41" 16"...
- Page 24 ® OTAL Page 4 of 4 Integrated Fire Protection System Dimensional Data & Cabinet This page is left intentionally blank. FM-076G-0-109A...
-
Page 25: Limited Warranty
Manufacturer with respect to its Tel.: (450) 437-3473 products. This warranty shall not be modified, unless such Fax: (450) 437-1930 modification is made in writing by an executive officer of Toll Free: (866) 347-3353 the Manufacturer. Website: www.fireflex.com FM-076G-0-84B... - Page 26 ® OTAL Page 2 of 2 Integrated Fire Protection System Limited Warranty User Notes FM-076G-0-84B...
