MP-000068 - A
Serial Number:
Model:
INSTRUCTION MANUAL FOR LV 660A
Operator/Tech Manual:
Local Sales & Service Agent:
Proline Equipment
Unit T1/25 Narabang Way,
Belrose NSW 2085
Australia
Ph. +612 99862004
Email. info@brazilianstyle.com.au
Scheer Churrasqueiras e Acessórios Ltda
Fone: +55 54 3224 3066 ou +1 954 688 3031
Roque Callege Street, 133 – B: Universitário.
95041-440 – Caxias do Sul – RS – Brazil
scheer@scheer.com.br
scheer.com.br
1
Advertisement
Table of Contents
Related Manuals for Scheer LV 660A
Summary of Contents for Scheer LV 660A
- Page 1 MP-000068 - A Serial Number: Model: INSTRUCTION MANUAL FOR LV 660A Operator/Tech Manual: Local Sales & Service Agent: Proline Equipment Unit T1/25 Narabang Way, Belrose NSW 2085 Australia Ph. +612 99862004 Email. info@brazilianstyle.com.au Scheer Churrasqueiras e Acessórios Ltda Fone: +55 54 3224 3066 ou +1 954 688 3031 Roque Callege Street, 133 –...
- Page 2 CONGRATULATIONS! You have just purchased a product with the latest technology, performance and design. Now, it will be much easier and faster for you to prepare your roasts. SCHEER CHURRASQUEIRAS E ACESSÓRIOS LTDA thank you for your choice. So that your Roasting Equipment may reach its best performance, read this manual carefully and follow the instructions correctly.
-
Page 3: Table Of Contents
REMOVING FROM ITS PACKAGE ................ 7 DESCRIPTION ......................8 INSTALATION ......................9 PLACE OF INSTALATION ..................10 LV 660A: ........................11 PILOTS/BURNERS LIGHTING PROCEDURE ............ 11 WATER AND GAS INSTALATION ..............12 LAVA ROCK INSTALATION ................13 ADJUSTS AND CHECKING .................. 14 PLACING THE GRILLS .................. -
Page 4: Importanat Information
MP-000068 - A SCHEER CHURRASQUEIRAS E ACESSÓRIOS IMPORTANAT INFORMATION • Keep this manual for future information in an easily accessible location; • Installation of the product is the responsibility of the buyer. The installation must be carried out in accordance with the manufacturer's instructions and carried out by qualified and competent persons;... -
Page 5: Safety Rules
TRANSPORT • Check for any signs of knocks, drops or malfunctions check with the persons responsible for the transport and contact the Scheer sales department; • The risks of transportation are the customer's responsibility. Any claim for damages during transportation must be made at the time you receive the product, it must be communicated to the carrier and also to the manufacturer of the product;... - Page 6 MP-000068 - A ilustrative image only...
-
Page 7: Removing From Its Package
MP-000068 - A REMOVING FROM ITS PACKAGE The unit must be unloaded in a flat and firm place can be started the removal of the barbecue from the packaging. After removing the top, side, front and rear cover, remove the machine from the pallet, we recommend the use of a forklift. -
Page 8: Description
MP-000068 - A DESCRIPTION Parts & Accessories: • 1 unit; • 1 manual; Characteristics: • Stainless steel AISI304 brushed or AISI430 brushed (as requested) and carbon steel; • AC input 240V 50Hz; • Water protection: IPX 1 • Motor 24 VCD •... -
Page 9: Instalation
MP-000068 - A INSTALATION • This installation must conform according local codes (AS/NZS 5601). In the absence of local codes, the installation must conform to the National Fuel Gas Code, ANSI Z223.1, Natural Gas Installation Code, CAN/CGA-B149.2, or the Propane Installation Code, CAN/CGA-149.2. -
Page 10: Place Of Instalation
MP-000068 - A • Before turning the machine on, fill the water tank with approximately 10 cm from the bottom of the tray. PLACE OF INSTALATION • The appliance should be installed 50mm clearances from other appliances & combustible materials. Never obstruct the top, especially with furniture or any other material, as the equipment will not function properly and there is a risk of fire;... -
Page 11: Pilots/Burners Lighting Procedure
MP-000068 - A LV 660A: Front pannel: LOTS/BURNERS LIGHTING PROCEDURE 1. Turn the gas control knob of the Pilot to OPEN/ON position; 2. Keep the red button pressed which open the gas flow through the Automatic Shut off gas valve. Hold the red button down and press the Ignition button several times until pilot is on;... -
Page 12: Water And Gas Instalation
MP-000068 - A WATER AND GAS INSTALATION • All components for gas and hydraulic supply must be purchased separately by the customer, the gas valve is attached to the grill and must not be removed or replaced with another model; Water inlet ½... -
Page 13: Lava Rock Instalation
MP-000068 - A LAVA ROCK INSTALATION • Distribute the lava rocks evenly over the grid covering the entire surface; Lava rocks are best changed every 2-4 weeks or washed for 2nd use, when they start to break down & crumble stop use. Length Qty Lava rock (kg) 1000... -
Page 14: Adjusts And Checking
MP-000068 - A ADJUSTS AND CHECKING • To gain access to these set points remove the top front panels; • In figure "A" Thermocouples are a factory fitted part in a fixed position 1cm above the pilot tube & shall not be altered from the design position. •... -
Page 15: Placing The Grills
MP-000068 - A • In figure "C" is the adjustment of the air aeration of the burners considering Natural Gas; this is the regulation provided by the manufacturer when you order this unit for Natural gas. • Observe if the flame is totally blue this is the ideal point of burning and better performance of your barbecue;... - Page 16 MP-000068 - A Rest vegetable grill Main grill • If all installation procedures have been followed & the appliance is not operating correctly please contact the service agent (details on front page of manual).
-
Page 17: Preventive Maintanace
MP-000068 - A PREVENTIVE MAINTANACE Gas System: Check once a week if the burners do not show any irregularities such as: • Not working or working partially; • If there is a problem remove the burner and clean the burner with a needle; •... -
Page 18: Changing Thermocouples
MP-000068 - A CHANGING THERMOCOUPLES CESSING THE BACK SIDE... -
Page 19: Back View
MP-000068 - A BACK VIEW ELETRICAL DIAGRAM... -
Page 20: Cleaning
MP-000068 - A CLEANING Water tank: • Drain (change the water) and clean every day. • Cleaning of Volcanic Stones: • The stones need to be changed every 2-4 weeks or washed for daily use or about when they start to break. •... -
Page 21: Extra Information
MP-000068 - A EXTRA INFORMATION Before any type of maintenance on the machine it must be disconnected from the mains water, electricity and gas. • In the event of possible interruption of light, gas and water, the entire machine is switched off until service is normalized. -
Page 22: Warranty
Warranty does not cover products that have been altered or have been damaged due to normal wear and tear, rust, improper use, disassembly of parts, internal or external hazards, heat damage. Scheer grills does not authorize any concerted attempt by the user without the prior written permission of the manufacturer. -
Page 23: Maintanace
MP-000068 - A MAINTANACE DATE: TEC: DATE: TEC: DATE: TEC: DATE: TEC: PROBLEMS FOUND: DATE: TEC: DATE: TEC: DATE: TEC: DATE: TEC:...
