- Page 1 MP-000096 - A Serial Number Model INSTRUCTION MANUAL RG300 Scheer Churrasqueiras e Acessórios Ltda Phone: +55 54 3224 3066 Location: Roque Callege, 133 – B: Universitário. 95041-440 – Caxias do Sul – RS – Brazil scheer@scheer.com.br scheer.com.br...
-
Page 2: Scheer Churrasqueiras E Acessórios
Congratulations! You just bought a barbecue grill with the highest technology, design and performance. Now it will be much easier and quick to prepare your Churrasco. SCHEER CHURRASQUEIRAS thanks for your choice. For your barbecue to perform best, read this manual carefully and follow the instructions correctly. For any information, or suggestions please contact us that as well - qualified professional will be happy to assist you. -
Page 3: Table Of Contents
MP-000096 - A CONTENT SCHEER CHURRASQUEIRAS E ACESSÓRIOS ................2 IMPORTANT INFORMATION ......................4 MAINTENCE AND OPERATOR INTRODUCTION ................4 SECURITY NORMS ..........................5 TRANSPORT ............................5 TAKING THE BARBECUE OUT OF THE PACKAGE CRATE ............6 DESCRIPTION OF THE BARBECUE ....................6 FEATURES ............................. -
Page 4: Important Information
MP-000096 - A SCHEER CHURRASQUEIRAS E ACESSÓRIOS IMPORTANT INFORMATION - Keep this manual for future information in an easily accessible location. - Installation of the product is the responsibility of the buyer. The installation must be carried out in accordance with the manufacturer's instructions and carried out by qualified and competent persons. -
Page 5: Security Norms
Receiving the package crate - Check for any signs of knocks, drops or malfunctions check with the persons responsible for the transport and contact the Scheer sales department. - The risks of transportation are the customer's responsibility. Any claim for damages during transportation must be made at the time you receive the product, it must be communicated to the carrier and also to the manufacturer of the product. -
Page 6: Taking The Barbecue Out Of The Package Crate
MP-000096 - A TAKING THE BARBECUE OUT OF THE PACKAGE CRATE Remove the top wood Remove the sides DESCRIPTION OF THE BARBECUE Parts & Accessories 1 residential gas barbecue Skewers (quantity corresponding to the number of skewers corresponding to barbecue) 1 manual NOTE: The skewers and accessories normally are shipped separately from the Barbecue. -
Page 7: Features
MP-000096 - A FEATURES Stainless steel AISI304 brushed or AISI430 brushed (as requested) and carbon steel. AC input with automatic switching 100-240V ~ 50 / 60Hz Degree of Protection: IPX 3 Class Construction: Class 1 Rotating system 24DC motor (electrical supply 12 DC) 03 Infrared gas burners for 5 skewers 04 Infrared gas burners for 7 skewers Skewers with stainless steel blades. -
Page 8: Rg 300 Details
MP-000096 - A RG 300 DETAILS Measure A 5 Skewers 56cm 7 skewers 66cm 1. 1 Water tray 2. – 3. On off switcher 4. Gas valves 5. Infrared burner 6. Gas injector 7. Removal hood... -
Page 9: Installation
CAUTION: - Do not use in open locations. Do not install and use exposed to weather. - On the RG300 model there is no hydraulic installation, only a water tray. -For electrical installation and recommended a separate electric circuit with a 5A circuit breaker exclusive to the barbecue. - Page 10 MP-000096 - A - Gas tube P-13 Provides a maximum of 500 g of LPG gas per hour; For installation, a gas and hose valve certified by INMETRO must be used; Make sure that the gas supply hose is protected from heat and agents that could damage it. - P-45 gas tube The P-45 is used in Buildings (piped gas), it provides a maximum of 1 kg of gas per hour.
-
Page 11: Lubrication
The Scheer Barbecues are free of lubrication. FUNCTIONABILITY - Put 10 to 13 liters of water inside the barbecue. On the RG300 models place water with a hose or container. - Turn the gas valve to release the gas and press the ignition button to turn on the infrared burner. -
Page 12: Grilling Skewer Meat
2. Use the side friezes to support the grill; 3. Insert the grill into the grill and enjoy a delicious grilled. If you do not have a grid, contact Scheer right now and buy yours! scheer.com or +55 54 3224 3066. -
Page 13: Cleaning
MP-000096 - A FLAT GRILL CLEANING 1. Before performing cleaning procedures, make sure that the equipment is turned off. 2. Perform cleaning after use, but allow the machine a few hours rest to cool naturally. 3. Do not use sharp objects such as knives, metal spatulas, etc. to clean the barbecue. 4. -
Page 14: Useful Information
MP-000096 - A USEFUL INFORMATION accidents; equipment may cause accidents and loss of manufacturing warranty; suitable glove. ren and pets away from the grill when it is in use. ecue by wearing clothes made with synthetic fabrics, as in case of an accident they can cause serious burns to the skin;... - Page 15 MP-000096 - A If the problem persists, remove the burner and clean the nozzle (the injector is the gas flow limiter), such as a needle...
- Page 16 Scheer assistance. c - When you light the fire, over time due to strong calorie, power to crack or break the stone, what to do in this case? Replace with a new burner.
-
Page 17: After Sales Information
MP-000096 - A Caution: The malfunction of the gas system may influence the taste of the meat. The meat may become dry and dark in appearance, affecting the taste of the meat. AFTER SALES INFORMATION How to get technical assistance First option is to contact the sales person. -
Page 18: Warranty Terms
Scheer grills will analyze the product and it will be repaired or replaced at the discretion of the company within 30 days from the arrival of the product to our factory and return it to the dealer. -
Page 19: Limited Warranty
The dealer's insistence on shipment of the product without the warranty certificate will give Scheer grills the right to return it to the merchant with freight to pay, without repair. Scheer grills does not authorize the exchange of products in the store for a new unit without, without the process provided in this guarantee is followed.
