MP-000091 - A
Serial Number:
Model
INSTRUCTION MANUAL
FOR BARBECUE MACHINE
MODEL SUPER 800
Scheer Churrasqueiras e Acessórios Ltda
Phone: +55 54 3224 3066 or USA Office Cell: +1 954 415 2161
Roque Callege Street, 133. Universitário. Zip Code 95041-440
Caxias do Sul – RS – Brazil
scheer@scheer.com.br
scheer.com.br
A MAJOR CAUSE OF OVEN-RELATED FIRES IS FAILURE TO MAINTAIN REQUIRED
CLEARANCES (AIR SPACES) TO COMBUSTIBLE MATERIALS. IT IS OF UTMOST
IMPORTANCE THAT THIS BARBECUE GRILL BE INSTALLED ONLY IN ACCORDANCE
WITH THESE INSTRUCTIONS
1
Advertisement
Table of Contents
Related Manuals for Scheer SUPER 800
Summary of Contents for Scheer SUPER 800
- Page 1 INSTRUCTION MANUAL FOR BARBECUE MACHINE MODEL SUPER 800 Scheer Churrasqueiras e Acessórios Ltda Phone: +55 54 3224 3066 or USA Office Cell: +1 954 415 2161 Roque Callege Street, 133. Universitário. Zip Code 95041-440 Caxias do Sul – RS – Brazil scheer@scheer.com.br...
- Page 2 MP-000091 - A WARNING Never use gasoline, gasoline-type lantern fuel, kerosene, charcoal lighter fluid, or Similar liquids to start or refresh up’ a fire in this oven. Keep all such liquids far from the oven when in use. Never store flammable products near a barbecue grill. A minimum clearance of 300mm (12 ") should be maintained on each side of the barbecue grill.
- Page 3 MP-000091 - A UTILITY INFORMATION Follow all instructions described on this instruction manual; This equipment is for commercial and / or industrial use only; Use only accessories supplied with the equipment or original spare parts, as the use of other accessories may cause accidents and loss of manufacturing warranty;...
- Page 4 CONGRATULATIONS! You have just purchased a product with the latest technology, performance and design. Now, it will be much easier and faster for you to prepare your roasts. SCHEER CHURRASQUEIRAS E ACESSÓRIOS LTDA thank you for your choice. So that your Roasting Equipment may reach its best performance, Please read this entire manual before you install the oven.
-
Page 5: Table Of Contents
3. SAFETY REGULATIONS ....................7 4. TRANSPORT ........................7 5. REMOVING THE PACKAGE ................... 9 6. DESCRIPTION OF THE BARBECUE ................10 7. SUPER 800 ........................11 8. MODULES ASSEMBLING PROCEDURES ..............12 9. INSTALLATION ......................17 10. LUBRICATION ....................... 18 11. -
Page 6: Important Information
MP-000091 - A 1. IMPORTANT INFORMATION Keep this manual easily accessible for future on-site information. The product installation is a responsibility of the Purchaser. The training should be done according to the manufacturer's instructions and made by qualified and competent people. -
Page 7: Safety Regulations
Read and understand all instructions on this Manual before operating your Professional Barbecue machine SUPER 800; The Professional barbecue machine SUPER 800 is not intended for people (including children) with reduced physical aspects such as: sensory or mental capabilities, or by people with a lack of experience and knowledge, unless instructed to use the appliance with supervision of a person responsible for their safety;... - Page 8 MP-000091 - A The risks of transportation are the customer's responsibility. Any claim for damages during transportation must be made at the time you receive the product, it must be communicated to the carrier and also to the manufacturer of the product. ...
-
Page 9: Removing The Package
After removing the top, side, front and rear cover, remove the machine from the base pallet. We recommend using a forklift. Scheer thanks your preference and describes in detail all procedures for proper installation, operation and use of the features available on your grill, including solving small problems... -
Page 10: Description Of The Barbecue
MP-000091 - A 6. DESCRIPTION OF THE BARBECUE Accessories and Parts: 1 Professional Charcoal barbecue 1 operation manual. Skewers (Quantity according to your order). PS: Normally the skewers are shipped in an extra package. Características (According to Order): ... -
Page 11: Super 800
MP-000091 - A 7. SUPER 800 “A” Rotative system (on/off switcher). “B” Removable Bar “C”. Fire Lighter (Specific area to start the fire on firewood/charcoal “D” Grill (manually operated). -
Page 12: Modules Assembling Procedures
Use Charcoal Fuel Only “C” Fire Lighter (Specific area to start the fire on firewood/charcoal (SUPER 800 model). In order to start the fire we recommend you to place into the fire lighter area 11 lbs (5 kg) of charcoal and light it properly with an appropriate tool. - Page 13 MP-000091 - A 2.Remove the frontal panel 3.Remove the back panels...
- Page 14 MP-000091 - A 4.Grill Handle mounting 5.Grill handle alignment “A” Align the Grill handle with the Grill structure “B” Fix the Grill handle with the screw and nut on “B”...
- Page 15 MP-000091 - A 6.Assembling procedure After removing the front and back panels, align the modules on a flat surface to hold the modules together. If necessary, use a Strong hand Clamp for holding the modules tight. When the back and front are aligned and pressed tight, screw it with screw and nuts. Screw/Place the rear and front panels back.
- Page 16 MP-000091 - A 7.Final Module assembling...
-
Page 17: Installation
MP-000091 - A 9. INSTALLATION After removing the Barbecue from the crate as showed before on this manual; Barbecue should be installed in a place with air circulation; The Barbecue should be installed under a forced exhaust hood with low air suction (a very strong suction may affect the barbecue heating performance). -
Page 18: Lubrication
MP-000091 - A 10. LUBRICATION The Rotisserie System bushes of this Barbecue machine Super 800 is free of lubrication. 11. SKEWER POSITION... -
Page 19: Grills
MP-000091 - A 12. GRILLS The Grill section works in 3 heights adjustment. 13. CLEANING Before starting cleaning procedures, make sure the equipment is already cooled down. The machine cannot be cleaned using a Water Jet, or hosing water ... - Page 20 MP-000091 - A Do not use sharp objects as knives, spatulas or any metal tools to clean the barbecue. Use only a wet cloth with degreasing agent Do not Hose water or jet water (cold or hot) on the equipment, do never hose or jet water on the fire pit, it will damage the equipment using water when the equipment is cold or hot.
-
Page 21: After Sales Information
Check the machine voltage Burned fuse Change the fuse The first option is to find the nearest authorized SCHEER Service Station. If necessary, contact the Plant using one of the following ways: Scheer USA Distribuition +1 954 415 2161 E-mail: scheer@scheer.com.br... -
Page 22: Electrical Diagram
Rotisserie System motor 16. WARRANTY TERMS The SUPER 800 model has 24 months against any manufacturing defects from the date of purchase invoice, which becomes part of this warranty certificate. Before buying this product, make sure it is in perfect condition, free of visible defects and with all accessories available and working. - Page 23 Scheer grills will analyze the product and it will be repaired or replaced at the discretion of the company within 30 days from the arrival of the product to our factory and return it to the dealer.
-
Page 24: Limited Warranty
Scheer grills the right to return it to the merchant with freight to pay, without repair. Scheer grills does not authorize the exchange of products in the store for a new unit without, without the process provided in this guarantee is followed.
