Prevent a Major Fault
During a Load

Read/Write Card Data

CompactFlash Card
Formatting
If the revision of your
project is
x
11.
³ 12.0
Controller Type
GuardLogix 5570
ControlLogix 5580
GuardLogix 5580
If the major and minor revisions of the project on the memory card do not
match the major and minor revision of the controller, a major fault may occur
during a load.
The memory card stores the firmware for projects for revision 12.0 or later.
Depending on the current revision of the controller, you may be able to use
the memory card to update the firmware of the controller and load the project.
Sample ladder logic code for the Logix Designer applications are available for
using your file system on a Logix 5000 controller to read and write data on a
memory card. These are the files you need:
• CF_Read_Write.ACD
• CF_Read_Write_Example.ACD
• Logix-AP007B-EN-P.pdf
To access these files, see
http://samplecode.rockwellautomation.com/idc/groups/public/documents/w
ebassets/sc_home_page.hcst.
The Logix Designer application 1784-CF128 CompactFlash card does not have
to be formatted to store controller information.
Then
The CompactFlash card uses a special format.
• Use only a Logix5000 controller to store a project on a CompactFlash card.
• Store only a single project and no other data on a CompactFlash card.
• When you store a project on a CompactFlash card, you overwrite the entire contents of the card. In other words, you lose everything
that is currently on the card.
The CompactFlash card uses the FAT16 file system.
If the card
Rockwell Automation Publication 1756-PM017J-EN-P - March 2022
Catalog Number Firmware Revision Supports a 1784-SD1 or 1784-SD2
1756-L71S 31.x or later
1756-L72S
1756-L73S
1756-L81E 29.x or later
1756-L82E
1756-L83E
1756-L84E
1756-L85E
1756-L81ES 31.x or later
1756-L82ES
1756-L83ES
1756-L84ES
Then the controller
Chapter 1 Store and Load a Project By Using a
Secure Digital (SD) Card
Yes
Yes
Yes
Memory Card
