- Page 1 Installation Instructions CompactFlash Cards Catalog Numbers 2711P-RC2, 2711P-RC3, 2711P-RC4, 2711P-RCH Language Page English Français Deutsch Español Italiano Português Publication 2711P-IN008C-MU-P - March 2007...
-
Page 2: Important User Information
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the use or application of this equipment. -
Page 3: Installation Instructions
Installation Instructions Compact Flash Cards Catalog Numbers 2711P-RC2, 2711P-RC2, 2711P-RC3, 2711P-RCH English Application CompactFlash Cards are a storage medium for 2711P PanelView Plus or PanelView Plus CE terminals. The card slides into the CompactFlash slot of the terminal, or into a PCMCIA slot of a personal computer using an adapter, 2711P-RCH. -
Page 4: Remove A Memory Card
Compact Flash Cards 2. Insert the card in the card slot and push until the card is firmly seated. • For the PanelView Plus 400 and 600 terminal, insert the card with Allen-Bradley logo facing toward the display. • For the 2711P PanelView Plus 700 - 1500 or PanelView Plus CE terminals, insert the card with the logo facing away from the display. -
Page 5: Notice D'installation
Notice d‘installation Cartes CompactFlash Référence 2711P-RC2, 2711P-RC2, 2711P-RC3, 2711P-RCH Français Application Les cartes CompactFlash sont des supports de stockage pour les fichiers des PanelView Plus 2711P et des PanelView Plus CE 2711P. La carte s’insère dans le logement pour carte CompactFlash d’un terminal PanelView Plus 2711P ou d’un pupitre opérateur ouvert PanelView Plus CE 2711P,... - Page 6 Cartes CompactFlash Pour installer la carte dans un PanelView Plus ou dans un PanelView Plus CE 1. Repérez le logement destiné à la carte sur le côté du terminal. Bouton d’éjection Logement de la carte CF 2. Introduisez la carte dans son logement puis poussez-la jusqu’à ce qu’elle soit bien insérée.
- Page 7 Installationsanleitung CompactFlash-Karten Bestellnummer 2711P-RC2, 2711P-RC2, 2711P-RC3, 2711P-RCH Deutsch Anwendung CompactFlash-Karten sind ein Speichermedium für 2711P PanelView Plus- oder PanelView Plus CE- Dateien. Die Karte wird in den CompactFlash-Steckplatz eines 2711P PanelView Plus- oder PanelView Plus CE- Terminals oder unter Verwendung eines Adapters (2711P-RCH) in den PCMCIA-Steckplatz eines PCs eingeschoben.
- Page 8 CompactFlash-Karten Vorgehensweise zur Installation der Speicherkarte in einem PanelView Plus- oder PanelView Plus CE-Terminal: 1. Den Kartensteckplatz seitlich am Terminal prüfen. Auswurftaste Steckplatz für CompactFlash-Karte 2. Schieben Sie die Karte bis zur festen Arretierung in den Kartensteckplatz. • Setzen Sie die Karte bei PanelView Plus 400- und 600-Terminals so ein, dass das Allen-Bradley-Logo zur Anzeige zeigt.
-
Page 9: Instrucciones De Instalación
Instrucciones de instalación Tarjetas CompactFlash Número de catálogo 2711P-RC2, 2711P-RC2, 2711P-RC3, 2711P-RCH Español Las tarjetas CompactFlash constituyen un medio de almacenamiento para archivos 2711P PanelView Plus o PanelView Plus CE. La tarjeta se desliza en la ranura CompactFlash de un terminal 2711P PanelView Plus o PanelView Plus CE, o en la ranura PCMCIA de una computadora personal usando un adaptador (2711P-RCH). - Page 10 Tarjetas CompactFlash Para instalar la tarjeta de memoria en un terminal PanelView Plus o PanelView Plus CE: 1. Ubique la ranura para tarjeta situada en el lateral del terminal. Botón de expulsión Ranura para tarjeta CF 2. Inserte la tarjeta en la ranura para tarjeta y presione hasta que la tarjeta quede firmemente asentada.
-
Page 11: Istruzioni Per L'installazione
Istruzioni per l'installazione Schede CompactFlash Numero di catalogo 2711P-RC2, 2711P-RC2, 2711P-RC3, 2711P-RCH Italiano Applicazione Le schede CompactFlash sono supporti di memorizzazione per file 2711P PanelView Plus o PanelView Plus CE. La scheda si inserisce in uno slot CompactFlash dei terminali 2711P PanelView Plus e PanelView Plus CE, oppure in uno slot PCMCIA di un personal computer tramite un adattatore (2711P-RCH). - Page 12 Schede CompactFlash Per installare la scheda di memoria in un PanelView Plus o PanelView Plus CE: 3. Localizzare lo slot della scheda posto sul fianco del terminale. Pulsante di espulsione Slot scheda CF 4. Inserire la scheda nell'apposito slot e premere per bloccarla in posizione. •...
-
Page 13: Instruções De Instalação
Instruções de Instalação Cartões CompactFlash Código de Catálogo 2711P-RC2, 2711P-RC2, 2711P-RC3, 2711P-RCH Português Aplicação Os Cartões CompactFlash são um meio de armazenamento médio arquivos 2711P PanelView Plus ou PanelView Plus CE. O cartão desliza no slot do CompactFlash de um terminal 2711P PanelView Plus e PanelView Plus CE ou em um slot PCMCIA de um PC utilizando um adaptador (2711P-RCH). - Page 14 Cartões CompactFlash Para instalar o cartão de memória em um PanelView Plus ou PanelView Plus CE: 1. Localize o slot do cartão na lateral do terminal. Botão Eject Slot do cartão CF 2. Insira o cartão no slot e empurre até que se encaixe devidamente. •...
-
Page 16: Rockwell Automation Support
Outside United Please contact your local Rockwell Automation representative for return States procedure. Publication 2711P-IN008C-MU-P - March 2007 PN 41061-303-01(3) Supersedes Publication 2711P-IN008B-MU-P - August 2003 Copyright © 2007 Rockwell Automation, Inc. All rights reserved. Printed in the U.S.A.
