Racal Instruments 1260 VXI Manual

Hide thumbs Also See for 1260 VXI:
Table of Contents

Advertisement

Quick Links

Download this manual
Unit 5, 25F., Mega Trade Center, No 1, Mei Wan Road, Tsuen Wan, Hong Kong, PRC
Copyright 1997 by Racal Instruments, Inc. Printed in the United States of America. All rights reserved.
This book or parts thereof may not be reproduced in any form without written permission of the publisher.
SWITCHING CARD
1260-16
POWER SWITCHING
MODULE
PUBLICATION NO. 980673-023
RACAL INSTRUMENTS
4 Goodyear St., Irvine, CA 92618-2002
Tel: (800) 722-3262, FAX: (949) 859-7309
480 Bath Road, Slough, Berkshire, SL1 6BE, United Kingdom
Tel: +44 (0) 8706 080134; FAX: +44 (0) 1753 791290
Racal Systems Electronique S.A.
18 Avenue Dutartre, 78150 LeChesnay, France
Tel: +33 (1) 3923 2222; FAX: +33 (1) 3923 2225
Racal Systems Elettronica s.r.l.
Strada 2-Palazzo C4, 20090 Milanofiori Assago, Milan, Italy
Tel: +39 (02) 5750 1796; FAX +39 (02) 5750 1828
Racal Elektronik System GmbH.
Frankenforster Strasse 21, 51427 Bergisch Gladbach, Germany
Tel:+49 2204 92220; FAX: +49 2204 21491
3 Powells Road, Brookvale, NSW 2100, Australia
Tel: +61 (2) 9936 7000, FAX: +61 (2) 9936 7036
Racal Electronics Pte. Ltd.
26 Ayer Rajah Crescent, 04-06/07 Ayer Rajah Industrial Estate, Singapore 0513.
Tel: +65 7792200, FAX: +65 7785400
Tel: +852 2405 5500, FAX: +852 2416 4335
http://www.racalinst.com
PUBLICATION DATE: June 27,1998
1260 VXI
Racal Instruments, Inc.
Racal Instruments, Ltd.
Racal Australia Pty. Ltd.
Racal Instruments, Ltd.

Advertisement

Table of Contents
loading

Related Manuals for Racal Instruments 1260 VXI

Summary of Contents for Racal Instruments 1260 VXI

  • Page 1 Tel: +852 2405 5500, FAX: +852 2416 4335 http://www.racalinst.com PUBLICATION DATE: June 27,1998 Copyright 1997 by Racal Instruments, Inc. Printed in the United States of America. All rights reserved. This book or parts thereof may not be reproduced in any form without written permission of the publisher.
  • Page 2 Authorization is required from Racal Instruments before you send us your product for service or calibration. Call your nearest Racal Instruments support facility. A list is located on the last page of this manual. If you are unsure where to call, contact Racal Instruments, Inc. Customer Support Department in Irvine, California, USA at...
  • Page 3 FOR YOUR SAFETY Before undertaking any troubleshooting, maintenance or exploratory procedure, read carefully the WARNINGS and CAUTION notices. This equipment contains voltage hazardous to human life and safety, and is capable of inflicting personal injury. If this instrument is to be powered from the AC line (mains) through an autotransformer, ensure the common connector is connected to the neutral (earth pole) of the power supply.
  • Page 4 This page was left intentionally blank.
  • Page 5 NOTE FOR SYSTEMS WITH 1260-OPT 01T The “Module-Specific Syntax” section of this manual shows the command syntax for the 1260-01S Smart Card. If you are using the newer 1260-01T Smart Card, the commands will NOT work as shown. Consult the 1260-01T Manual for a description of the commands that may be used with the 1260-01T Smart Card.
  • Page 6 Control Information for the 1260-16 The following information describes the control-register-to-relay-channel mapping for a 1260-16 Relay Module. This information may be used to control a 1260-16 when using a 1260-01T in the register-based mode of operation. Each relay on this module is controlled by setting or clearing a single bit within a Control Register. Control Registers on the module operate 8 channels simultaneously.

  • Page 7: Table Of Contents

    User Manual 1260-16 Table Of Contents Chapter 1 MODULE SPECIFICATION ......................1-1 Module Specification ......................... 1-1 Specifications..........................1-2 Ordering Information......................1-3 Safety ............................ 1-3 Product Support........................1-3 Pin Configuration ........................1-3 Chapter 2 INSTALLATION INSTRUCTIONS ....................2-1 Unpacking and Inspection ......................2-1 Reshipment Instructions......................
  • Page 8 User Manual 1260-16 Chapter 5 DRAWINGS ..........................5-1 Chapter 6 PARTS LIST..........................6-1 Chapter 7 OPTIONAL HARNESS ASSEMBLIES...................7-1 Chapter 8 Product Support.........................8-1 Reshipment Instructions ......................8-1...
  • Page 9 User Manual 1260-16 List Of Figures Figure 1-1, 1260-16 ........................1-1 Figure 1-2, 1260-16 Pin Configuration ..................1-4 Figure 4-1, 1260-16 Relay Diagram....................4-1 Figure 4-2, 1260-16 J200-J202 Pin Configuration ................ 4-3 Figure 4-3, 1260-16 Channel ......................4-4 Figure 4-4, 1260-16 Components Per Channel ................4-5 Figure 4-5, 1260-16 Jumper Locations ..................
  • Page 10 User Manual 1260-16 This page was left intentionally blank.

  • Page 11: Module Specification

    User Manual 1260-16 Chapter 1 MODULE SPECIFICATION The 1260-16 Power Switching module provides 40 independent Module channels SPDT switching. Each channel functions Specification independently with all paths accessible through the front panel connectors. Every channel features mounting holes on the printed circuit board to allow for the addition of one series and two shunt elements.

  • Page 12: Specifications

    User Manual 1260-16 Switch Configuration 40 SPDT Relays Specifications User Connector Positronics SMPL 4 FOTO LB Maximum Switchable Voltage 125 V DC, 250 VAC RMS Maximum Switchable Current Per Channel 5 A DC or AC RMS Maximum Switchable Power Per Channel 150 W or 1250 VA Maximum Switchable Power Per Module...

  • Page 13: Ordering Information

    Contents. Follow all NOTES, CAUTIONS and WARNINGS to ensure personal safety and prevent damage to the instrument. Authorization is required from Racal Instruments before you send Product Support us your product for service or calibration. Call your nearest Racal Instruments support facility. A list is located on the last page of this manual.

  • Page 14: Figure 1-2, 1260-16 Pin Configuration

    User Manual 1260-16 Figure 1-2, 1260-16 Pin Configuration Module Specifications 1-4...

  • Page 15: Installation Instructions

    Series cards. Failure to do so may cause damage to the unit. 1. Use the original packaging when returning the switching Reshipment module to Racal Instruments for calibration or servicing. The Instructions original shipping carton and the module's foam will provide the necessary support for safe reshipment.

  • Page 16: Option 01 Installation

    User Manual 1260-16 Installation of the Option 01 into the 1260-16 is described in the Option 01 Installation section of the 1260 Series VXI Switching Cards Manual Installation (RII P/N 980673-999). Installation of the 1260-16 Switching Module into a VXIbus Module mainframe, including the setting of DIP switches, is described in Installation...

  • Page 17: Module Specific Syntax

    User Manual 1260-16 Chapter 3 MODULE SPECIFIC SYNTAX The module specific syntax for the 1260-16 is required in the use 1260-16 Module of the OPEN and CLOSE commands. It will also appear in the Specific Syntax data output by the Master in response to the PDATAOUT and PSETUP commands.

  • Page 18: Psetup Command

    User Manual 1260-16 The PSETUP command causes the specified module setup to be PSETUP Command displayed as a response. The syntax used is: PSETUP <module address>[;<module address>][;<module address>]..where <module address> is the address. The responses to the PSETUP command for the 1260-16 Power Switching Module are as follows: <module address>.1260-16 40 CHANNEL SPDT 5 AMP RELAY MODULE...

  • Page 19: Module Configuration

    User Manual 1260-16 Chapter 4 MODULE CONFIGURATION The 1260-16 Power Switching module provides 40 independent General channels of SPDT switching. Each channel functions independently, with all paths accessible through the front panel connectors. Every channel features mounting holes on the printed circuit board to allow for the addition of one series and two shunt elements.

  • Page 20: Connector Pin Configuration

    User Manual 1260-16 Refer to Figure 4-2 for pin configurations of the front panel Connector Pin connectors J200 to J202. J200 to J202 are Racal Instruments Configuration Part Number 601856-050. The mating connectors are Racal Instruments Part Number 601855-050, and mating pins are Racal Instruments Part Number 601857.

  • Page 21: Figure 4-2, 1260-16 J200-J202 Pin Configuration

    User Manual 1260-16 Multiplexer Channel Assignments Multiplexer Channel COM0_7 J200-A COM8_15 J200-h COM16_23 J201-x COM24_31 J201-P COM32_39 J202-Y Chassis Ground J200-B J200-HH J201-B J201-HH J202-B J202-HH Figure 4-2, 1260-16 J200-J202 Pin Configuration Module Configuration 4-3...

  • Page 22: Figure 4-3, 1260-16 Channel

    User Manual 1260-16 Figure 4-3 shows a 1260-16 channel with one series and two shunt elements associated with each channel. The series elements are designated F100 to F139, while the shunt elements are designated U100A/B to U139A/B. To allow immediate use of the module, a trace is provided on the printed circuit board (component side) in all positions for F100 to F139.

  • Page 23: Figure 4-4, 1260-16 Components Per Channel

    User Manual 1260-16 U120A and U120B. Note that each channel has two shunt elements: element "A" is connected between the NO channel and COM while element "B" is connected between the NC channel and Figure 4-4, 1260-16 Components Per Channel For the shunt elements, metal oxide varistors (MOVs) may be used to suppress voltage spikes.
  • Page 24 This scenario is typical with all brands of relays rated at this current. Racal Instruments recommends that the customer designate each 1260-16 module purchased as either a low current switch (less than 1 amp) or a high current switch (greater than 1 amp).

  • Page 25: Figure 4-5, 1260-16 Jumper Locations

    User Manual 1260-16 Figure 4-5, 1260-16 Jumper Locations Module Configuration 4-7...
  • Page 26 User Manual 1260-16 This page was left intentionally blank. Module Configuration 4-8...

  • Page 27: Drawings

    User Manual 1260-16 Chapter 5 DRAWINGS 407348 1260-16 Hi Current Switch 405086 PCB Assy, 1260-16 435086 Schematic, 1260-16 Drawings 5-1...
  • Page 28 User Manual 1260-16 This page was left intentionally blank. Drawings 5-2...
  • Page 29 User Manual 1260-16 Drawings 5-3...
  • Page 30 User Manual 1260-16 Drawings 5-4...
  • Page 31 User Manual 1260-16 Drawings 5-5...
  • Page 32 User Manual 1260-16 Drawings 5-6...
  • Page 33 User Manual 1260-16 Drawings 5-7...
  • Page 34 User Manual 1260-16 Drawings 5-8...
  • Page 35 User Manual 1260-16 Drawings 5-9...
  • Page 36 User Manual 1260-16 Drawings 5-10...
  • Page 37 User Manual 1260-16 Drawings 5-11...
  • Page 38 User Manual 1260-16 Drawings 5-12...
  • Page 39 User Manual 1260-16 Drawings 5-13...
  • Page 40 User Manual 1260-16 Drawings 5-14...
  • Page 41 User Manual 1260-16 Drawings 5-15...
  • Page 42 User Manual 1260-16 Drawings 5-16...
  • Page 43 User Manual 1260-16 Drawings 5-17...
  • Page 44 User Manual 1260-16 Drawings 5-18...

  • Page 45: Parts List

    User Manual 1260-16 Chapter 6 PARTS LIST 407340 1260-16 Hi Current Switch ................6-3 407349 Shipping Kit, 1260-16..................6-3 405086 PCB Assy, 1260-16..................6-4 List of Suppliers..................6-6 Parts List 6-1...
  • Page 46 User Manual 1260-16 This page was left intentionally blank. Parts List 6-2...
  • Page 47 User Manual 1260-16 407348-1260-16 , Hi Current Switch MD RACAL INST DESCRIPTION MANUFACTURER'S P/N DESIG (1)1 405086 PCB ASSY, 1260-16 21793 405086 (5)1 407349 SHIP KIT, 1260-16 21793 407349 (9)1 456270-002 PANEAL ASSY, FRONT, 1260-16 21793 456270-002 (11)1 456238-001 PANEL, RIGHT 21793 456238-001 (13)1...
  • Page 48 User Manual 1260-16 405086-PCB ASSY, 1260-16 RACAL INST DESCRIPTION MANUFACTURER'S P/N DESIG C1-C4 110126 CAP, TANTA, 6.8UF, 35V, 20 PERCENT 05397 T355F685M035A5 C100-C102 R-21-1801 CAP, CHIP, 10 NF 95275 VJ12O6Y1O3MF C103 110165 CAP, TANTA, .15 MF, 35V, 1OPCT 05397 T355A154K035A5 C104-C11S R-21-1801 CAP, CHIP, 10 NF...
  • Page 49 User Manual 1260-16 405086-PCB ASSY, 1260-16 RACAL INST DESCRIPTION MANUFACTURER'S P/N DESIG 080119 RES NETWORK, 220K 91637 SOMC-1603-224K 080117 RES NETWORK, 16P8R, 47K 73138 628-AL.-473J 080119 RES NETWORK, 220K 91637 SOMC-1603-224K 080117 RES NETWORK, 16P8R, 47K 73138 628-AL-473J 080119 RES NETWORK, 220K 91637 SOMC-1603-224K 080117...
  • Page 50 SPECTRA-STRIP CORP. GARDEN GROVE, CA 11236 CTS OF BERNE, INC. BEPNE, IN 18324 SIGNETICS, INC. SUNNYVALE, CA 21793 RACAL INSTRUMENTS INC. IRVINE, CA 27014 NATIONAL SEMI-CONDUCTOR CORP. SANTA CLARA, CA 52072 CIRCUIT ASSY. CORP. COSTA MESA, CA 53387 THREE M (3M) CO.

  • Page 51: Optional Harness Assemblies

    User Manual 1260-16 Chapter 7 OPTIONAL HARNESS ASSEMBLIES The following harness assemblies are used to connect Racal Instruments Model 1260-16 to Freedom Series Test Receiver Interfaces. Each harness documentation consists of an assembly drawing, parts list, system wire list and wire list.
  • Page 52 User Manual 1260-16 This page was left intentionally blank. Optional Harness Assemblies 7-2...
  • Page 53 User Manual 1260-16 Optional Harness Assemblies 7-3...
  • Page 54 User Manual 1260-16 ENGINEERING PARTS LIST ITEM REV PART NO. DESCRIPTION REFERENCE 602201-003 CON-RCV-PLG096.---D Jl00,J101 602201-906 CONTACT, SIGNAL, 22AW0, VP90 (J100,J101) 601855-050 CON-CAB-PLG50CP. J200-J202 602092-001 CONT, SGMC MALE CRIMP (J200-J202) 610777 TIE-CA-LKG-.062-.075 523999 WRTEF, STR22G-999 910541 POLYURETHANE CONF. COAT GRP-110-1/2 SLEEVING,BRAIDED POLY,1/2 Instruments, Inc., 4 Goodyear St., Irvine, CA 92718 RACAL...
  • Page 55 User Manual 1260-16 ENGINEERING WIRE LIST WIRE FROM TYPE PART # WIRE LEN REFERENCE BLK AA Uxx-SLOT yy CABLE 407435 SYSTEM WIRE LIST (J100) (J200,J20 1) CABLE 407435 BLK AA Uxx-SLOT yy (J101) (J201,J202) This system wirelist serves as a template for incorporating this harness assembly into the overall system wirelist.
  • Page 56 User Manual 1260-16 ENGINEERING WIRE LIST WIRE FROM TYPE PART # WIRE LEN REFERENCE 3100-1 3200-A 22AW0 WHT 523999 54” COM0_7 602201-906 602092-001 3100-2 J200-Y 22AWG WRT 523999 54” 602201-906 602092-001 J100-3 3200-Z 22AWG WHT 523999 54” 602201-906 602092-001 3100-4 NO CONNECTION 3100-5 3200-S...
  • Page 57 User Manual 1260-16 ENGINEERING WIRE LIST WIRE FROM TYPE PART # WIRE LEN REFERENCE 3100-26 3201-n 22AWG WHT 523999 54" NC16 602201-906 602092-001 3100-27 3201-p 22AW6 WHT 523999 54" NC17 602201-906 602092-001 3100-28 NO CONNECTION 3100-29 3201-c 22AW0 WHT 523999 54"...
  • Page 58 User Manual 1260-16 ENGINEERING WIRE LIST WIRE FROM TYPE PART # WJRE REFERENCE 3100-51 NO CONNECTION 3130-52 3200-v 22AW0 WHT 523999 54" COM12 602201-906 602092-001 3100-53 3200w 22AW0 WHT 523999 54" COMI3 602201-906 602092-001 3100-54 NO CONNECTION 3100-55 3200-n 22AW0 WHT 523999 54"...
  • Page 59 523999 54" CHASSIS GND 602201-906 602092-001 NOT USED NOT USED NOT USED NOT USED RACAL Instruments, Inc., 4 Goodyear St., Irvine, CA 92718 DOCUMENT TITLE SIZE CODE NO DOCUMENT NO HARNESS ASSEMBLY, 1260-16, VP90 21793 407435 SHEET 7 Of 11...
  • Page 60 User Manual 1260-16 ENGINEERING WIRE LIST WIRE FROM TYPE PART # WIRE LEN REFERENCE 3101-1 3201-B 22AWG WHT 523999 54" CHASSIS GND 602201-906 602092-001 3101-2 J201-Y 22AWG WHT 523999 54" NC2O 602201-906 602092-001 3101-3 3201-Z 22AWG WHT 523999 54" NC21 .602201-906 602092-001 3101-4...
  • Page 61 User Manual 1260-16 ENGINEERING WIRE LIST WIRE FROM TYPE PART # WIRE LEN REFERENCE 3101-26 3202-k 22AW0 WHT 523999 54" NC36 602201-906 602092-001 3101-27 3202-rn 22AW0 WHT 523999 54" NC37 602201-906 602092-001 3101-28 NO CONNECTION 3101-29 3202-c 22AW6 WHT 523999 54"...
  • Page 62 User Manual 1260-16 ENGINEERING WIRE LIST WIRE FROM TYPE PART # WIRE LEN REFERENCE 3101-51 3202-Y 22AW0 WHT 523999 54" COM32_39 602201-906 602092-001 3101-52 J202-BB 22AWG WHT 523999 54" COM32 602201-906 602092-001 3101-53 3202-CC 22AWG WHT 523999 54" COM33 602201-906 602092-001 3101-54 NO CONNECTION...
  • Page 63 User Manual 1260-16 ENGINEERING WIRE LIST WIRE FROM TYPE PART # WIRE REFERENCE 3101-76 J202-R 22AW6 WHT 523999 54" NO27 602201-906 602092-001 3101-77 NO CONNECTION 3101-78 3202-H 22AW0 WHT 523999 54" NO28 602201-906 602092-001 3101-89 3202-3 22AW6 WHT 523999 54" NO29 602201-906 602092-001...
  • Page 64 User Manual 1260-16 Optional Harness Assemblies 7-14...
  • Page 65 User Manual 1260-16 ENGINEERING PARTS LIST ITEM REV PART NO. DESCRIPTION REFERENCE 601855-050 CON-CAB-PLG50CP. J200-J202 602092-001 CONT, SGMC, MALE CRIMP W/J200-J202 WRTEF-STR22G-9-9-9 523999 602193-010 CON-CAB-RCP010C.100S J100-J129 602199-001 CONTACT, CRIMP, RECEPT, 28-22GA W/J100-J129 610777 TIE-CA-LKG-.062-.075 910541 POLYURETHANE CONF. COAT Instruments, Inc., 4 Goodyear St., Irvine, CA 92718 RACAL DOCUMENT TITLE SIZE...
  • Page 66 User Manual 1260-16 ENGINEERING WIRE LIST WIRE FROM TYPE PART WIRE REFERENCE BLK AAx RW 0l Uxx-SLOT yy CABLE 407436 SYSTEM WIRE LIST (J100) (J200) BLK AAx RW 02 Uxx-SLOT yy CABLE 407436 (J101) (J200) BLK AAx RW 03 Uxx-SLOT yy CABLE 407436 (J102)
  • Page 67 User Manual 1260-16 ENGINEERING WIRE LIST WIRE FROM TYPE PART WIRE REFERENCE BLK AAx RW 26 Uxx-SLOT yy CABLE 407436 (J125) (J202) BLK AAx RW 27 Uxx-SLOT yy CABLE 407436 (J126) (J201,J202) BLK AAx RW 28 Uxx-SLOT yy CABLE 407436 (J127) (J202) BLK AAx RW 29...
  • Page 68 User Manual 1260-16 ENGINEERING WIRE LIST WIRE FROM TYPE PART WIRE REFERENCE 3100-1 J200-Y 22AWG 523999 40" N.C.0 602199-001 602092-001 3101-1 J100-1 22AWG 523999 4" N.C.0 602199-001 (w/WIRE 1) 3100-2 J200-Z 22AWG 523999 40" N.C.1 602199-001 602092-001 3101-2 J100-2 22AWG 523999 4"...
  • Page 69 User Manual 1260-16 ENGINEERING WIRE LIST FROM TYPE PART WIRE REFERENCE WIRE J102-3 J200-U 22AW6 523999 40" COM.2 602199-001 602092-001 J103-3 J102-3 22AW6 523999 4" COM.2 602199-001 (w/WIRE 25) J102-4 J200-V 22AWG 523999 40" COM.3 602199-001 602092-001 J103-4 J102-4 22AWG 523999 4"...
  • Page 70 User Manual 1260-16 ENGINEERING WIRE LIST WIRE FROM TYPE PART WIRE REFERENCE J104-5 J200-P 22AWG 523999 40" N.O.4 602199-001 602092-001 J105-5 J104-5 22AWG 523999 4" N.O.4 602199-001 (w/WIRE 49) J104-6 J200-R 22AW6 523999 40" N.O.5 602199-001 602092-001 J105-6 J104-6 22AWG 523999 4"...
  • Page 71 User Manual 1260-16 ENGINEERING WIRE LIST WIRE FROM TYPE PART WIRE REFERENCE J106-7 J200-k 22AWG 523999 40" N.C.14 602199-001 602092-001 J107-7 J106-7 22AW6 523999 4" N.C.14 602199-001 (w/WIRE 73) J106-8 J200-m 22AWG 523999 40" N.C.15 602199-001 602092-001 J107-8 J106-8 22AWG 523999 4"...
  • Page 72 User Manual 1260-16 ENGINEERING WIRE LIST WIRE WIRE FROM TYPE PART # REFERENCE J108-9 J200-h 22AWG 532999 40" MUX. CH. 8-15 602199-001 602092-001 J109-9 NO CONNECT 602199-001 J108-10 J201-B 22AWG 532999 40" CHASSIS GND 602199-001 602092-001 J109-10 NOCONNECT 602199-001 J110-1 J201-H 22AWG 523999...
  • Page 73 User Manual 1260-16 ENGINEERING WIRE LIST WIRE WIRE FROM TYPE PART # REFERENCE J112-l J201-n 22AWG 523999 40” N.C.16 60219-901 602092-001 J113-1 J112-1 22AWG 523999 4” N.C.16 602199-001 (w/WIRE l2l) J112-2 J201-p 22AWG 523999 40” N.C.17 602199-001 602092-001 J113-2 J112-2 22AWG 523999 4”...
  • Page 74 User Manual 1260-16 ENGINEERING WIRE LIST WIRE FROM TYPE PART WIRE REFERENCE J115-2 J114-2 22AWG 523999 4" COM.17 602199-001 (w/WIRE 143) J114-3 J201-h 22AWG 523999 40" COM.18 602199-001 602092-001 J115-3 J114-3 22AWG 523999 4" COM.18 602199-001 (w/WIRE 145) J114-4 J201-j 22AWG 523999 40"...
  • Page 75 User Manual 1260-16 ENGINEERING WIRE LIST WIRE REFERENCE WIRE FROM TYPE PART J117-4 J116-4 22AWG 523999 4” N.O.19 602199-001 (w/WIRE 167) J116-5 J201-c 22AWG 523999 40” N.O.20 602199-001 602092-001 J117-5 J116-5 22AWG 523999 4” N.O.20 602199-001 (w/WIRE 169) J116-6 J201-d 22AWG 523999 40”...
  • Page 76 User Manual 1260-16 ENGINEERING WIRE LIST WIRE FROM REFERENCE TYPE PART WIRE J119-6 J118-6 22AWG 523999 4" N.C.29 602199-001 (w/WIRE 191) J118-7 J201-z 22AWG 523999 40" N.C.30 602199-001 602092-001 J119-7 J118-7 22AWG 523999 4" N.C.30 602199-001 (w/WIRE 193) J118-8 J101-AA 22AWG 523999 40"...
  • Page 77 User Manual 1260-16 ENGINEERING WIRE LIST WIRE FROM TYPE PART WIRE REFERENCE J121-8 J120-8 22AWG 523999 4" COM.31 602199-001 (w/WIRE 2l5) J120-9 J201-P 22AWG 532999 40" MUX. CH. 24-31 602199-001 602092-001 J121-9 NO CONNECT 602199-001 J120-10 J200-HH 22AWG 532999 40” CHASSIS GND 602199-001 602092-001...
  • Page 78 User Manual 1260-16 ENGINEERING WIRE LIST WIRE FROM TYPE PART WIRE REFERENCE J123-10 NO CONNECT 602199-001 J124-1 J202-z 22AWG 523999 40” N.C.32 60219-901 602092-001 J125-1 J124-1 22AWG 523999 4” N.C.32 602199-001 (w/WIRE 241) J124-2 J202-AA 22AWG 523999 40” N.C.33 602199-001 602092-001 J125-2 J124-2...
  • Page 79 User Manual 1260-16 ENGINEERING WIRE LIST WIRE FROM REFERENCE TYPE PART WIRE J126-2 J202-CC 22AWG 523999 40" COM.33 602199-001 602092-001 J127-2 J126-2 22AWG 523999 4" COM.33 602199-001 (w/WIRE 263) J126-3 J202-v 22AWG 523999 40" COM.34 602199-001 602092-001 J127-3 J126-3 22AWG 523999 4"...
  • Page 80 User Manual 1260-16 ENGINEERING WIRE LIST WIRE FROM TYPE PART # WIRE REFERENCE J128-4 J202-y 22AWG 523999 40" N.O.35 602199-001 602092-001 J129-4 J128-4 22AWG 523999 4" N.O.35 602199-001 (w/WIRE 287) J128-5 J202-r 22AWG 523999 40" N.O.36 602199-001 602092-001 J129-5 J128-5 22AWG 523999 4"...

  • Page 81: Chapter 8 Product Support

    User Manual 1260-16 Chapter 8 PRODUCT SUPPORT Racal Instruments has a complete Service and Parts Department. Product Support If you need technical assistance or should it be necessary to return your product for repair or calibration, call 1-800-722-3262. If parts are required to repair the product at your facility, call 1-949-859- 8999 and ask for the Parts Department.
  • Page 82 User Manual 1260-16 Racal Instruments, Inc. Support Offices 4 Goodyear St., Irvine, CA 92618-2002 Tel: (800) 722-3262, FAX: (949) 859-7309 Racal Instruments, Ltd. 480 Bath Road, Slough, Berkshire, SL1 6BE, United Kingdom Tel: +44 (0) 8706 080134; FAX: +44 (0) 1753 791290 Racal Systems Electronique S.A.
