LOW BATTERY PROTECTION SETTINGS

The fridge is equipped with three battery protection settings; high, medium and low. The below
settings should be set for the specific battery type being used.
Note: With the compressor running, due to voltage drop, it is likely the voltage used for these
protections is 0.3-0.5 volts below the voltage of the battery, this will depend on the wiring used to
connect the battery to the fridge. On some battery types, voltage may drop when a load is
applied. This can affect the reading and cutout voltage of the fridge.
DC SOURCE
12V
24V

USING THE CONTROL PANEL

TURN FRIDGE
ON OR OFF
TURNING ONE
COMPARTMENT
ON OR OFF
(DUAL ZONE ONLY)
SETTING THE
TEMPERATURE
UNITS
SETTING
COMPRESSOR
SPEED
SETTING THE VOLTAGE
PROTECTION LEVEL
VIEWING THE
BATTERIES VOLTAGE
VIEWING THE FRIDGES
BLUETOOTH CODE
LOW BATTERY
PROTECTION
10.1V +/-0.3V
Cut Out Voltage
Cut In Voltage 11.4V +/-0.3V
Cut Out Voltage 21.5V +/-0.3V
Cut In Voltage 23.0V +/-0.3V
When fridge is off, hold
When fridge is on, hold
If only one compartment is required, each bin can be individually isolated.
To turn the small compartment of the fridge on/off, Press
for 3 seconds or until the small bin display shows OFF.
To turn the large compartment of the fridge on/off, Press
for 3 seconds or until the large bin display shows OFF.
Both bins follow the above step.
To change the temperature display between Fahrenheit and Celsius, press the
3 times simultaneously until only the unit (C or F) is flashing. Select Fahrenheit or
Celsius using the and
the setting will be saved.
To change the compressor speed between quick, normal and eco, press the
times simultaneously until both displays are flashing with the current selection. Navigate
through the options using the
flashing and the setting will be saved.
To set the voltage protection level, press and hold the
or until the light indicator moves to the next setting.
To display the voltage of the battery connected, press the
compressor is running, indicated by the run light illuminating green, the voltage
displayed may be misrepresented by up to 0.5V due to voltage drop between the
battery and the control board.
To view the fridges Bluetooth code, press the
number.
MEDIUM BATTERY
PROTECTION
11.4V +/-0.3V
12.2V +/-0.3V
24.1V +/-0.3V
25.3V +/-0.3V
power button for 3 seconds to turn off.
power button for 3 seconds to turn off.
buttons. Wait until the LCD screen stops flashing and
and buttons. Wait until the LCD screen stops
