30L 12V DRAWER FRIDGE
OWNER'S MANUAL
KAF-30DR
V1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KAF-30DR and is the answer not in the manual?

Questions and answers

Summary of Contents for KickAss KAF-30DR

  • Page 1 30L 12V DRAWER FRIDGE OWNER’S MANUAL KAF-30DR V1.1...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS -------------------------------------- WARNING AND SAFETY INFORMATION --------------------------------------------------- PRODUCT SPECIFICATIONS --------------------------------------------------------- PRODUCT OVERVIEW ----------------------------------------------------- INCLUDED COMPONENTS ---------------------------------------------- USING YOUR FRIDGE/FREEZER ------------------------------------- - CONNECTING THE FRIDGE TO POWER -------------------------------------------------- - CONTROL PANEL DISPLAY ------------------------------------------------ CONTROL PANEL OPERATION ------------------------------------------------- - TURN FRIDGE ON AND OFF ------------------------------------------- - SETTING UP THE TEMPERATURE --------------------------------------...
  • Page 3: Warning And Safety Information

    WARNING AND SAFETY INFORMATION • Children must not operate or play with the fridge to avoid injury or accidents. • Avoid pinching, folding, knotting, or damaging the power cord. • Always unplug the power plug before repairing or cleaning the fridge. Do not pull the power cord directly when unplugging to avoid damage.
  • Page 4: Product Specifications

    PRODUCT SPECIFICATIONS Capacity Power Rating Power consumption 1.38Ah (over 24 hours) Average hourly draw over 24 hours at 32º, the fridge is set at -2º Product Dimensions 734W x 490D x 295H mm Weight 22.9KG Input Voltage 12/24V Compressor SECOP PBC 2.0 Refrigerant Charge R134A Temperature Range...
  • Page 5: Product Overview

    PRODUCT OVERVIEW 1. Compressor compartment 2. Fridge unit 3. LCD control panel 4. Protective barrier 5. Drawer 6. Fridge door 7. Mounting base 8. Drawer rail...
  • Page 6: Included Components

    INCLUDED COMPONENTS KickAss 30L 12V Drawer Fridge 12V DC Anderson Power Cable Bottle Opener...
  • Page 7: Using Your Fridge/Freezer

    USING YOUR FRIDGE/FREEZER CONNECTING THE FRIDGE TO POWER • Connecting to DC: To connect to DC power, use the supplied Anderson to Anderson style cable, ensuring the end with fuse is furthest away from the fridge. If using the Cigarette socket extension cable, ensure the wiring between the battery and socket is capable of handling up to 10A.
  • Page 8: Control Panel Operation

    CONTROL PANEL OPERATION TURN FRIDGE ON AND OFF • When the fridge is off, hold for 3 seconds to turn it on. • When the fridge is on, hold for 3 seconds to turn it off. SETTING UP THE TEMPERATURE •...
  • Page 9: Troubleshooting

    • This is normal, due to the flow of the refrigerant. The fridge is making an unusual noise • Ensure the refrigerator is on a level surface. • There may be loose components inside the fridge - if this happens, contact KickAss.
  • Page 10: Cleaning Instructions

    • Do not clean the fridge under running water or with a high-pressure washer. WARRANTY & SUPPORT INFORMATION Need help? For product support or to make a warranty claim, reach out to the KickAss Customer Service team on: warranty@kickassproducts.com.au Alternatively, visit our Customer Support Portal at: https://supportportal.kickassproducts.com.au/...
  • Page 11 KickAss is a registered trademark of KickAss Products Pty Ltd Designed & imported by KickAss Products Pty Ltd 39 Iris Place, Acacia Ridge, QLD 4110 Australia Made in China...
