Triple S Scepter PE120 Operating & Maintenance Instructions

12 gallon box extractor

Advertisement

Quick Links

INTRODUCTION
This operator's book has important information for the use
and safe operation of this machine. Read this book care-
fully before starting the machine. Keep this book and tell all
operators to read the book. If you do not follow the instruc-
tions, you can cause an injury or damage equipment, furni-
ture or buildings.
For new books write to:
Triple S
2 Executive Park Drive
Billerica, MA 01862
Carefully inspect all components to ensure that there is no
concealed freight damage. If such damage is discovered,
file a "CONCEALED DAMAGE REPORT" immediately with
the delivering carrier.
Scepter PE120
12 Gallon
Box Extractor
OPERATING & MAINTENANCE
INSTRUCTIONS
READ THIS BOOK
The contents of this manual are based on the latest product
information available at the time of publication. Triple S
reserves the right to make changes or improvements to its
machines without notice.
FOR YOUR CONVENIENCE, RECORD THE
FOLLOWING IMPORTANT INFORMATION:
MODEL
SERIAL NUMBER
PART NUMBER
DATE PURCHASED

Advertisement

loading
Need help?

Need help?

Do you have a question about the Scepter PE120 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Triple S Scepter PE120

  • Page 1 The contents of this manual are based on the latest product This operator’s book has important information for the use information available at the time of publication. Triple S and safe operation of this machine. Read this book care- reserves the right to make changes or improvements to its fully before starting the machine.
  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS READ AND UNDERSTAND ALL WARNINGS AND INSTRUCTIONS BEFORE USING THIS APPLIANCE! WARNING! To reduce the risk of fire, electric shock, or injury: Unplug from outlet when not in use and before servicing. Do not use outdoors. Protect the machine from rain. 3.
  • Page 3: Assembly And Operation

    OPERATING INSTRUCTIONS WARNING! For the safe operation of this machine follow of the carpet and pulling dirt embedded in the carpet up the instructions given in this booklet and the training given while the suction created by the vacuum motor picks up by your supervisor.
  • Page 4 SSS SCEPTER PE120 12-GALLON BOX EXTRACTOR FINAL ASSEMBLY...
  • Page 5 SSS SCEPTER PE120 12-GALLON BOX EXTRACTOR FINAL ASSEMBLY PARTS LIST ITEM PART NO. DESCRIPTION QTY. 920665 Nut-Hex 1/4 SS Nyloc 254554 Hinge 911552 Cable-Steel Lanyard 962358 Screw-1/4-20x1-1/2 Hex SS W104D Washer-Flat 252004 Clamp-Hose 5/8 Plastic 251804 Base-Black 255121 Lid Assembly...
  • Page 6 SSS SCEPTER PE120 12-GALLON BOX EXTRACTOR RECOVERY TANK...
  • Page 7 SSS SCEPTER PE120 12-GALLON BOX EXTRACTOR RECOVERY TANK PARTS LIST ITEM PART NO. DESCRIPTION QTY. 920666 Nut-Hex 10-32 SS Nyloc S400P5 Locknut 1-1/2 962453 Screw 10-32x1 SS Phillips W104D Washer-1/4 Flat S216P Clamp-Hose 253306 Fitting-Pipe 1-1/2 MPT 252807 Elbow 1-1/2 FIPT x 1-1/2...
  • Page 8 SSS SCEPTER PE120 12-GALLON BOX EXTRACTOR SOLUTION TANK...
  • Page 9 SSS SCEPTER PE120 12-GALLON BOX EXTRACTOR SOLUTION TANK PARTS LIST ITEM PART NO. DESCRIPTION QTY. 920666 Nut-Hex 10-32 SS Nyloc 962453 Screw 10-32 x 1 SS Phillips W104D Washer 1/4 Flat SAE SS 211310 Body-90 Jet w/Lock Nut 253302 Filter Screen...
  • Page 10 SSS SCEPTER PE120 12-GALLON BOX EXTRACTOR BASE ASSEMBLY...
  • Page 11 SSS SCEPTER PE120 12-GALLON BOX EXTRACTOR BASE ASSEMBLY PARTS LIST ITEM PART NO. DESCRIPTION QTY. 257405 Rod-Axle 1/2 x 19" 251804 Base-Black-12 Gal 908059 Cord Asm 25' 16-3 SJT 920011 Nut 1/4-20 Elastic Stop 920619 Nut 1/2 Pipe Lock 920004...
  • Page 12 SSS SCEPTER PE120 12-GALLON BOX EXTRACTOR HOSE ASSEMBLY...
  • Page 13 SSS SCEPTER PE120 12-GALLON BOX EXTRACTOR HOSE ASSEMBLY PARTS LIST ITEM PART NO. DESCRIPTION QTY. 252403 Cuff-Hose 1.5 x 1.5" 254105 Hose-Vacuum 1.5" (Per Foot, No Cuffs) 15 ft 254113 Hose-Vacuum Assm 15' w/Cuffs S250P Hose-Solution 3/8" (Per Foot) 15 ft 203359 Fitting-Hose Barb 3/8"...
  • Page 14 SSS SCEPTER PE120 12-GALLON BOX EXTRACTOR WAND ASSEMBLY...
  • Page 15 SSS SCEPTER PE120 12-GALLON BOX EXTRACTOR WAND ASSEMBLY PARTS LIST ITEM PART NO. DESCRIPTION QTY. 219201 Trigger-Wand 203308 Quick Connect 1/4" Female S906A Nipple-Brass T4055 Elbow-45 Degree Brass 219402 Valve 215007 Kit-Valve Repair (O-ring/Spring/Disk) S223P Barb-1/4 to 1/4" Brass 214116...
  • Page 16 SSS SCEPTER PE120 12-GALLON BOX EXTRACTOR WIRING DIAGRAM - NO HEATER INSTALLED...
  • Page 17 SSS SCEPTER PE120 12-GALLON BOX EXTRACTOR WIRING DIAGRAM - WITH HEATER INSTALLED...
  • Page 18 NOTES...
  • Page 19 The inoperative machine or warranted parts must be delivered to the authorized dealer with shipping and delivery charges prepaid. If unable to locate the Dealer, you may contact Triple S at the address listed herein for the location of the nearest Triple S repair center or agent or for other instructions pertaining to your warranty difficulty.
