- Page 1 DFendr Solar Skirt Installation Guide V 1.0 Last Updated - Mar. 2022...
- Page 2 Installation Guide / DFendr Solar Skirt Introduction PV-ezRack® DFendr - Solar Skirt is a universal mounting accessory to keep birds and wind-blown debris and List of contents leaves away from the solar PV system on roofs. Introduction Please review this manual thoroughly before installing Tools &...
- Page 3 Installation Guide / DFendr Solar Skirt Tools and Components Tools Plier Tape Marker Pen Components EZ-SC-PV EZ-SS-PV PV-ezRack® DFendr - PV-ezRack® DFendr - Solar Skirt Clip for Solar Skirt for PV Panels PV Panels - Tools and Components - Installation Guide V 1.0...
- Page 4 Considering the height (130 mm) and flexibility of Solar Skirt, it is recommended to solar skirt only for the gap 100 to 130 mm between underside of the PV panel and roof. Most of PV-ezRack interfaces can provide required gap. Here are the interfaces list below:...
- Page 5 Installation Guide / DFendr Solar Skirt Installation Instructions Clip Installation Attach spring clips to the underside of the PV panel frame with the small lip facing up. Note: minimum frame width (D) is 12 mm For installations up to 10 m building height and at terrain Number of Clip category not less than 2.5, please refer the table on the right...
- Page 6 Installation Guide / DFendr Solar Skirt 2) Insert the upper frame of the Solar Skirt into the clip mounted on the PV panel frame and push the clip against Solar Skirt till it is fully in place. Note: If clip is pushed off from panel frame, it is recommended to press it again with the plier to maintain a good strength.
- Page 7 Clenergy 1/10 Duerdin St Phone: +61 3 9239 8088 Clayton VIC 3168 Email: sales@clenergy.com.au Australia Web: www.clenergy.com.au @ClenergyGlobal / @ClenergyClub / ClenergyAUS @Clenergy @ClenergyClub @Clenergy_global @Clenergy A Clenergy Technologies Company...
