- Page 1 SolarRoof™ Slate Tile Code-Compliant Planning and Installation Guide V1.0 Complying with AS/NZS1170.2-2011 AMDT 2-2016 Ver 1.0 / Last Updated - Oct. 2021...
-
Page 2: Table Of Contents
Installation Guide / SolarRoof™ Slate Tile Introduction The Clenergy PV-ezRack® SolarRoof ™ has been List of contents developed as a universal PV-mounting system for roof-mounting on pitched and flat roofs. The use of Introduction patented aluminium base rails, Z-Module technology... -
Page 3: Tools And Components
Installation Guide / SolarRoof™ Slate Tile Tools and Components Tools Angle Grinder with Screw Driver Torque Spanner Spanner 5m Tape Stone Disk (for M8 Hexagon Socket Screw) String & Marker Pen Slate Rip Lead Flashing Components (Manufacturer: Clenergy) ER-EC-ST ER-IC-ST C-U/30/46-G C-U/30/46 ER-EC-DU35/40... - Page 4 Installation Guide / SolarRoof™ Slate Tile Components (Manufacturer: Clenergy) EZ-RE-200 ER-HB-8/150 ER-HB-MP/8/150EP Hanger Bolt for metal Roof Hook Extender Hanger Bolt for wood purlin purlin - Tools and Components - Code-Compliant Planning and Installation Guide V1.0 - Complying with AS/NZS1170.2-2011 AMDT 2-2016...
-
Page 5: System Overview
Installation Guide / SolarRoof™ Slate Tile System Overview PV-ezRack® SolarRoof™ Slate Tile with Tile Interface A. End Clamp B. Inter Clamp C. ECO Rail D. Tile interface PV-ezRack® SolarRoof™ Slate Tile with Hanger Bolt A. End Clamp B. Inter Clamp C. -
Page 6: Installation Instruction
Installation Guide / SolarRoof™ Slate Tile Installation Instruction 1. Tile Interface Installation 1) Choice of Tile Bracket ER-I-02 would be the most appropriate tile interface for slate tile application. Given slate tiles are generally flat and low-lying, nailed into the roof battens. Figure 4.1.1 2) Removing Slate Tiles Determine the positions of the tile brackets according to your plans. - Page 7 Installation Guide / SolarRoof™ Slate Tile 4) Fixing Tile Bracket to Rafters Fix the tile brackets to the slate tiles using Clenergy provided 2x Buildex 14-gauge Hex Head Zips screws as shown in the figure on the right following the Buildex screws installation guide below: - Use a 3/8"...
- Page 8 Installation Guide / SolarRoof™ Slate Tile 7) Rail, clamps, and panel installation Please refer to PV-ezRack® Solar Roof Installation Guide for steps on installing rails, clamps and PV panels. The guide also gives our standard engineering spacing for tile interface based on site conditions.
- Page 9 Figure 4.2.6B 7) Rail, clamps, and panel installation Please refer to PV-ezRack® Solar Roof Installation Guide for steps on installing rails, clamps and PV panels. The guide also gives our standard engineering spacing of hangar bolts based on site conditions.
-
Page 10: Certification Letter
Please refer to table below for reference to the correct manual for your installation method: Mounting System Setup Manual Tile Interface PV-ezRack® Solar Roof Installation Guide Hangar bolts - Certification Letter - Code-Compliant Planning and Installation Guide V1.0 - Complying with AS/NZS1170.2-2011 AMDT 2-2016... -
Page 11: Product Warranty
Installation Guide / SolarRoof™ Slate Tile Product Warranty As the manufacturer of quality solar mounting systems, Clenergy Australia provides a warranty for all PV-ezRack® products it supplies in Australia and New Zealand (“Products”). The warranty provided by Clenergy Australia is subject to the conditions contained in this document (“Warranty”). - Page 12 Installation Guide / SolarRoof™ Slate Tile Warranty Scope Your solar mounting Product has been manufactured to high standards, however, should any manufacturing defect arise, please contact Clenergy Australia. We will arrange for an inspection of the affected Product(s) to determine the extent of the problem.
- Page 13 Installation Guide / SolarRoof™ Slate Tile Our Products may come with guarantees that cannot be excluded under the Australian Consumer Law. You may be entitled under statute to a replacement or refund for a major defect in the Products. You may also be entitled under statute to have the products repaired for any defect which does not amount to a major defect.
- Page 14 Clenergy 1/10 Duerdin St Phone: +61 3 9239 8088 Clayton VIC 2168 Email: sales@clenergy.com.au Australia Web: www.clenergy.com.au @ClenergyGlobal / @ClenergyClub / ClenergyAUS @Clenergy @ClenergyClub @Clenergy_global @Clenergy A Clenergy Technologies Company...
