  • Page 1 IC-9110W V2 User Manual 03-2018 / v1.0...
  • Page 2 (www.gnu.org) and LPGL(www.gnu.org) Websites to view the terms of each license. The GPL Code and LGPL Code used in Edimax products are distributed without any warranty and are subject to the copyrights of their authors. For details, see the GPL Code and LGPL Code licenses. You can download the firmware-files at http://www.edimax.com...

  • Page 3: Table Of Contents

    CONTENTS Product Information ................5 Package Contents ..................5 System Requirements ................... 6 LED Status ...................... 6 Product Label ....................7 Reset ......................7 II Camera Setup ..................9 II-1 Hardware Setup .................... 9 II-2 Connecting to EdiLife App ................12 II-2-1 Android OS ....................
  • Page 4 Basic ......................57 V-1-1 Network ....................58 V-1-2 Wireless ....................59 V-1-2-1 Smartphone ................60 V-1-2-2 Computer................. 62 V-1-2-3 WPS ..................63 V-1-3 Dynamic DNS ..................64 V-1-4 RTSP ...................... 65 V-1-5 Date & Time ..................66 V-1-6 Users ..................... 67 V-1-7 UPnP .....................
  • Page 5 VI-3-1 Add Camera/Camera Configuration ........... 107 VI-3-1-1 Camera .................. 108 VI-3-1-2 Scheduled Recording ............. 110 VI-3-1-3 Audio ..................112 VI-3-1-4 Motion Recording ..............113 VI-3-2 General Options .................. 114 VI-3-2-1 General .................. 114 VI-3-2-2 Email Settings ................ 116 VI-3-2-3 Security .................. 118 VI-3-2-4 About ..................

  • Page 6: I Product Information

    Product Information Package Contents Outdoor Image Unit Ethernet Cable Indoor Main Unit Outdoor Image Unit Indoor Main Unit Screws Adhesive Pad Screws Wall Template Quick Installation Guide Power Adapter Antenna...

  • Page 7: System Requirements

    System Requirements - Intel Pentium 4 2.4GHz (above or similar) - VGA card (1024*768 or above) - CD-ROM Drive - At least 128MB hard disk space (256 MB recommended) - Windows XP, Vista, 7 or 8/8.1 - Web browser (Internet Explorer 7.0, Firefox 3.6, Chrome 10, Opera 11, Safari 5 or above) LED Status LED Color...

  • Page 8: Product Label

    Product Label The product label located on the indoor main unit displays the MAC address, cloud ID and setup SSID of your network camera. The MAC address and cloud ID are the same for easy reference. Reset If you experience problems with your network camera, you can reset the camera back to its factory default settings.
  • Page 9 Wait for the network camera to restart. The camera is ready when the green power LED is flashing slowly. After setup, the green power LED will display on to indicate a successful connection to the cloud server.

  • Page 10: Camera Setup

    Camera Setup It is recommended that you setup your network camera as shown below and establish a working connection before you install the camera to its outdoor location. Your network camera’s unique SSID is displayed on the product label on the product’s indoor main unit and consits of “EdiView.Setup**” where ** are the last two characters of your camera’s unique MAC address.
  • Page 11 Connect the power adapter to the indoor main unit and to a power supply. Wait a moment for the camera to power on. The green power LED will flash slowly when it’s ready. Now you need to connect your network camera to your network. There are three easy ways: A.
  • Page 12 After connecting your camera to your network using one of the methods above, you can view your camera’s live image or configure its settings: Local network: A. Using the web based management interface (see V Web-Based Management Interface). B. Using the 16 channel viewer software (see VI 16 Channel Viewer for Windows).

  • Page 13: Connecting To Edilife App

    II-2 Connecting to EdiLife App Follow the instructions below to connect your network camera to your Wi-Fi using the EdiLife smart phone app. Your network camera’s unique SSID is displayed on the product label on the network camera and consists of “EdiView.Setup **” where ** are the last two characters of your camera’s unique MAC address.

  • Page 14: Ii-2-1 Android Os

    II-2-1 Android OS Please make sure the network camera is within the Wi-Fi range of a Wi-Fi router that has internet connectivity. Search and download “EdiLife” in Google Play. Open the EdiLife app and tap the icon to see the available wireless device list. Identify and tap the network camera Your network camera’s unique SSID is displayed on the product label on the network camera and...
  • Page 15 Once connected, the app will prompt you to enter a device name, new password and the password confirmation. Tap icon to continue. The app will display your local Wi-Fi network list. Tap your selection to continue. Enter the Wi-Fi password of the selected network and tap icon to continue.
  • Page 16 Please wait patiently for the camera to connect to the selected Wi-Fi network... A Setup complete screen will be displayed on the app when completed. Congratulations! Your camera is up and running! The camera’s green power LED and orange Internet LED should be on.

  • Page 17: Ii-2-2 Apple Ios

    II-2-2 Apple iOS Please make sure the network camera is within the Wi-Fi range of a Wi-Fi router that has internet connectivity. On your iOS device, go to Settings. Tap the “Wi-Fi” (outlined in red) option. Find and connect to the network camera by tapping the camera’s Wi-Fi name.
  • Page 18 Open the EdiLife app and tap the icon. Once connected, the app will prompt you to enter a device name, new password and the password confirmation. Tap “OK” to continue. The app will display your local Wi-Fi network list. Tap your selection to continue.

  • Page 19: Ediview Finder

    Enter the Wi-Fi password of the selected network and tap “OK” icon to continue. Please wait patiently for the camera to connect to the selected Wi-Fi network... A Setup complete screen will be displayed on the app when completed. Congratulations! Your camera is up and running! The camera’s green power LED and...

  • Page 20: Ii-3-1 Windows

    Ensure your computer is connected to the same router as the network camera using an Ethernet cable. II-3-1 Windows Insert the included CD into your CD-ROM drive and if the setup utility does not automatically open, please locate and open the “Autorun.exe” file in the “Autorun”...
  • Page 21 When installation is complete, select “Launch EdiView Finder Utility” before clicking “Finish”. Or double click the ”EdiView Finder Utility” icon on your desktop to launch EdiView Finder. EdiView Finder will list all cameras on your local network, along with each camera’s name, model, IP address and MAC address.
  • Page 22 Click the search icon to refresh the list if your camera is not displayed. The network camera’s IP address is displayed on this screen. After setup, you can enter this IP address into the URL bar of a web browser on the same local network to access your network camera’s web-based configuration interface.
  • Page 23 Unplug the Ethernet cable from your network camera and click “Next”. Please wait a moment for the camera to detect the connection. When the connection is detected as shown below, please click “Next”.
  • Page 24 Enter a name and password for your camera. The password will be used later to log in to your camera remotely via its cloud ID, web interface or via the EdiLife smartphone app. Click “OK” to continue. The next screen will indicate that setup is complete. The camera is operational and ready for use.

  • Page 25: Ii-3-2 Mac

    Copy the “EdiView Finder” file to your desktop and double click the icon to open EdiView Finder. EdiView Finder is also available for download from the Edimax website: http://www.edimax.com/EdiViewFinder.htm EdiView Finder will list all cameras on your local network, along with each camera’s name, model, IP address and MAC address.
  • Page 26 The network camera’s IP address is displayed on this screen. After setup, you can enter this IP address into the URL bar of a web browser on the same local network to access your network camera’s web-based configuration interface. Double click your network camera and wait a moment for the network camera to obtain an IP address and test the cloud connection.
  • Page 27 The next screen will indicate that setup is complete. The camera is operational and ready to be configured for a wireless connection. Click “Finish” and a preview window showing a live stream from your camera may open. To setup your network camera’s wireless connection, please follow V-1-2 Wireless.

  • Page 28: Ii-3-3 Using Ediview Finder

    II-3-3 Using EdiView Finder You can also use EdiView Finder to find your network camera’s IP address, view a live stream, or modify the network camera’s IP address. Double click the TV icon on the right side to view a live stream in a pop-up window, or click the wrench icon to open a new window with the network camera’s IP address settings:...
  • Page 29 EdiView Finder will locate your network camera as long as you are on the same local network. Static IP users who may be using a different IP address subnet to the network camera should still be able to locate the network camera with EdiView Finder. If you encounter difficulties, it is recommended that you use a DHCP server –...

  • Page 30: Wps (Wi-Fi Protected Setup)

    II-4 WPS (Wi-Fi Protected Setup) The WPS button is a quick and easy alternative to establish a secure wireless connection between your network camera and your wireless router/access point. Press and hold the WPS button on your wireless router/access point for the correct length of time to activate its WPS.

  • Page 31: Outdoor Installation

    Outdoor Installation Recommended installation: The instructions below are a guide – if you are unsure please seek professional assistance. Disconnect the outdoor image unit from the indoor main unit and remove the indoor main unit antenna and power cable before outdoor installation.
  • Page 32 Drill an additional hole through to the interior of the building wide enough for the outdoor image unit cable.
  • Page 33 Run the cable attached to the outdoor image unit through the hole from the outside to the interior. Use a sealant to seal the gaps around the cable and screw the outdoor image unit into place. Silicone based sealant is recommended. If your cable hole will not be behind the outdoor image unit, a plastic bushel is also recommended.
  • Page 34 Use the included screws to screw the outdoor image unit securely into place Adjust the angle of the camera lens on the outdoor image unit to your preference by loosening & tightening the screw. Use the included adherent pad to attach the indoor main unit to your interior wall, or drill holes in your interior wall and use the included screws to screw it firmly into place.
  • Page 35 Reconnect the antenna and outdoor image unit cable to the indoor main unit. Reconnect the indoor main unit power supply. Use cable clamps (not included) to fix loose cables to the walls according to your preference. You can use an Ethernet cable instead of Wi-Fi to connect the indoor main unit to your router/access point for more stable performance if you prefer.

  • Page 36: Using The Edilife App

    Using the EdiLife App EdiLife is a convenient app that allows you to remotely control your network camera on-the-go. Refer to the following sections on its functions. If you have not already, please go through II-2 Connecting to EdiLife App to connect your network camera to the EdiLife app.
  • Page 37 Clicking on the camera will bring you to the camera streaming page. The following sections will explain each options / information outlined in red. IV-7 IV-1 IV-6 IV-2 IV-3 IV-4 IV-5...

  • Page 38: Snapshot

    IV-1 Snapshot Tap the icon to take a snapshot. Share Snapshot Upon tapping the icon to take a snapshot, the app will ask whether to share the snapshot. Tapping “SHARE” will bring up the available methods to share the image. Selecting a sharing method will take you to the method’s page that is beyond the scope of this document.

  • Page 39: Video Settings

    IV-2 Video Settings Tap this icon to adjust the camera stream. The adjustable options are shown on the screen and can be swiped left or right to adjust.

  • Page 40: Event

    IV-3 Event Tap this icon to display the motion detection events. A maximum of 5 events would be displayed at a time, always replacing the oldest displayed event. Tapping any of the events will play the motion detection video recorded at the time of the event.

  • Page 41: Connection Information

    IV-4 Connection Information Tap this icon to display current connection information. 1. Connection Methods: P2P, Cloud or LAN. 2. Video Resolution (adjustable, please refer to IV-6 Resolution). 3. Frames Per Second (FPS).

  • Page 42: Push Notification On / Off

    IV-5 Push Notification On / Off Tap this icon to turn “Push Notification” On or Off. ON (default)

  • Page 43: Resolution

    IV-6 Resolution Tap this icon to adjust the resolution of the video stream. Options Available: 1280 X 720 640 X 360 Smooth: 320 X 176...

  • Page 44: Camera Settings

    IV-7 Camera Settings Tap this icon for the camera settings page as shown below: From top to bottom: 1. Camera Name: Tap to change camera name 2. ID: Device MAC address 3. Username: Login account name 4. Password: Login password - For another mobile device to access your camera.

  • Page 45: Iv-7-1 Camera Name

    Camera IV-7-1 Name Tapping the field will allow you to change the camera’s name as shown on the left: Enter a new name and tap “DONE” (for Android) or the button with similar meaning (for iOS). Change IV-7-2 Password Tapping the field will allow you to change the camera’s password as shown on the left: Enter a new password and tap “DONE”...

  • Page 46: Iv-7-5 Advance Settings

    Notification Settings Tap the Push Notifications bar to enter push notification settings. Push Notifications: Tap the icon to turn on / off all push notifications. Motion Detection Push Notification: Tap the icon to turn on / off push notifications from motion detection.

  • Page 47: Iv-7-5-1 Date & Time

    Date & Time IV-7-5-1 Daylight Savings: Tap the icon to turn on / off daylight savings setting. Date & Time: Displays current date and time. SYNCHRONIZE TO MOBILE DEVICE TIME: Tap this bar to synchronize date and time to your mobile device’s time.

  • Page 48: Iv-7-5-2 Email Account

    Email Account IV-7-5-2 To use email notifications, you need to configure an email address to send and receive the mail. Follow the guide below to configure the email notification settings for different email services: Tap the icon to select the email service (more information in its section below).
  • Page 49 Gmail, Yahoo! and Outlook email services have pre-configured settings to help facilitate the setup process. We will use Gmail as an example here: Enter the email address in the “Email” space. Enter the password of your email address service in the password space. Send a test email by selecting the “Send a Test Email”...
  • Page 50 Manual Settings If you wish to use other email services, please select “Manual Settings” with further options as shown below: Follow the table below to enter the information required to setup the email service. Where you are unsure about the information below, consult your email service provider.
  • Page 51 Sender Email Enter the sender’s email address here. When the arrow is selected, options are as shown on the right: SSL/TLS Select “SSL” or “TLS” when your SMTP server requires encryption. Enable this option when your SMTP server requires SMTP authentication.

  • Page 53: Iv-7-5-3 Generate Qr Code To Share

    Generate QR code to share IV-7-5-3 Tap the “Generate QR code to share” bar to display a QR code. You can share your device’s information directly using this QR code. Upon entering the QR code page, a warning message will be shown: Tap “OK”...

  • Page 54: Web-Based Management Interface

    Web-Based Management Interface When you are using the same local network as your camera, you can use the web-based management interface to view or configure the camera. You can access the web-based management interface with a web browser on a smartphone or computer. For smartphone users, the appearance of the interface will vary slightly to what is displayed here, though the menu functions described from V-1 Basic onwards are essentially the same.
  • Page 55 You may be prompted to allow a Java add-on to run. Please click the message where it says “click here” and then click “Run Add-on”. If any other security warnings/prompts appear, please select “Run” or “Allow” or similar, depending on your browser. Enter the username and password for your network camera (default username: admin default password: 1234).
  • Page 56 For computer users, the “Live View” screen will be displayed, as shown below. On the live view screen you can see a live stream from your camera and use the icons on the left side. Snapshot Save a snapshot (image) of the network camera’s current view.
  • Page 57 Select “Setup” at the top center and use the menu down the left side to navigate to the network camera’s various settings. Each menu item is described in the following chapters. After making any changes, click “Save Settings” to save the settings and bring the changes into effect.

  • Page 58: Basic

    Basic The “Basic” menu opens a submenu with eight categories of settings for your network camera’s basic operation. Select a category and refer to the appropriate chapter.

  • Page 59: V-1-1 Network

    V-1-1 Network Network settings are displayed on this page, as shown below. You can configure your network camera to dynamically receive a local IP address from your router’s DHCP server or you can specify a local static IP address for your network camera.

  • Page 60: V-1-2 Wireless

    V-1-2 Wireless The wireless page allows you to configure settings for your network camera’s wireless connection. For Windows users, your wireless connection should have been set up already using EdiView Finder, though you can still use this page to revise the settings if you need. Mac users need to configure these settings manually since EdiView Finder on Mac will not set up your camera’s wireless connection.

  • Page 61: V-1-2-1 Smartphone

    Smartphone V-1-2-1 Select “Basic” from the menu on the left side and then select “Wireless”. Configure the wireless settings A – E shown in the table below:...
  • Page 62 Wireless Select “Enable” to enable the wireless connection. Connection Available Click “Refresh” to display all available Wi-Fi networks. Network (1) Available Select your Wi-Fi network from the list. This is the Network (2) wireless network which your camera will connect to. WPA Pre Shared Enter your Wi-Fi password.

  • Page 63: V-1-2-2 Computer

    Computer V-1-2-2 Configure the wireless settings A – E shown in the table below: Wireless Select “Enable” to enable the wireless connection. Connection Available Click “Refresh” to display all available Wi-Fi networks. Network Select your Wi-Fi network from the list. This is the wireless C Connected network which your camera will connect to.

  • Page 64: V-1-2-3 Wps

    V-1-2-3 WPS (Wi-Fi Protected Setup) is a quick and easy way to set up wireless connections between compatible devices. Use the “Start PBC” or “Start PIN” button to activate WPS on your network camera. Your network camera’s WPS PIN code is also listed next to “Self PinCode”. Self PinCode Your network camera’s WPS PIN code is listed here.

  • Page 65: V-1-3 Dynamic Dns

    V-1-3 Dynamic DNS Dynamic DNS (DDNS) is a service which provides a hostname-to-IP service for dynamic IP users. If your Internet service provider didn’t issue a fixed IP address, you can use a third-party dynamic DNS provider to map your current IP address to a fixed IP address.

  • Page 66: V-1-4 Rtsp

    V-1-4 RTSP Real Time Streaming Protocol (RTSP) enables the network camera to be used with a streaming media server. Enter the required RTSP settings. RTSP Port Enter the RTSP port. MJPEG RTSP Path Enter the MJPEG RTSP path. H.264 RTSP Path (HD) Enter the H.264 High Definition (HD) RTSP path.

  • Page 67: V-1-5 Date & Time

    V-1-5 Date & Time You can set and adjust the network camera’s system time and date on this page. Maintaining a correct system time is particularly important for recorded video organization/playback. Mode Select ”NTP” or “Manual Setting”. NTP (Network Time Protocol) can set and maintain the time and date automatically via an NTP server on the local network, if available.

  • Page 68: V-1-6 Users

    V-1-6 Users In addition to the default administrator account, you can configure several different login accounts for the network camera, with two different levels of access – operator and guest. Operator accounts can configure partial functions of the network camera similar to the administrator account, while guest accounts can only view the camera’s image.
  • Page 69 Modify Save the changes to an existing, selected user. Remove Remove selected user. Anonymous Enable or disable anonymous login. Anonymous login allows Login anyone to login to the network camera and view images. This function is useful if you want to setup a remote video server.

  • Page 70: V-1-7 Upnp

    V-1-7 UPnP Universal plug-and-play (UPnP) is a set of networking protocols which enables network devices to communicate and automatically establish working configurations with each other. When enabled, Windows computers can automatically discover the network camera on the local area network. The network camera also supports IGD.

  • Page 71: V-1-8 Bonjour

    V-1-8 Bonjour Bonjour is a feature of Mac computers which allows Safari web browser to discover devices and services on the local network and provide a quick shortcut for access. When enabled, Safari users on the local network can find a shortcut to the network camera under Safari’s “Bonjour”...

  • Page 72: Video

    Video The “Video” menu consists of three categories for configuring the network camera’s video settings. Select an item from the submenu and refer to the appropriate following chapter.

  • Page 73: V-2-1 Video Settings

    V-2-1 Video Settings The “Video Settings” page enables you to modify the network camera’s resolution and frame rate settings for different profiles: HD, SD, Small (mobile) & MJPEG. H264 Select a H264 video resolution from the dropdown menu. A Resolution higher resolution provides more detailed video but requires more bandwidth.
  • Page 74 Resolution higher resolution provides more detailed video but requires more bandwidth. Maximum Select the maximum video frame rate. A higher frame rate Frame rate provides smoother video, but also requires more bandwidth. MJPEG Quality Select a quality level for MJPEG videos from the drop down menu.

  • Page 75: V-2-2 Image Appearance

    V-2-2 Image Appearance The “Image Appearance” page allows you to adjust various parameters relating to the network camera’s image appearance using the sliders shown below. Brightness/ Click and drag the blue lever to change the value according Contrast/ to your preference for each category. Saturation/ Sharpness/ Reset to default Click to reset all settings back to the default value of 50.

  • Page 76: V-2-3 Night Vision

    V-2-3 Night Vision Night-vision allows your network camera to capture images in dark environments by using infra-red LEDs. Auto-switch will detect light levels in your network camera’s environment and automatically switch to night-vision in low light. Select “Enable” or “Disable” for night-vision auto-switch.

  • Page 77: Events

    Events Select an item from the “Events” menu and refer to the appropriate following chapter. You can configure settings for motion detection, scheduling, SMTP and FTP.

  • Page 78: V-3-1 Motion Detection

    V-3-1 Motion Detection Motion Detection V-3-1-1 The network camera features a motion detection function and various options for (motion detection) events notification. When motion is detected, it is defined as an “event” and the camera will record for a specified length of time. You can set the camera to send this recording as a notification via email or FTP, and/or to local storage such as a NAS or MicroSD card inside the camera.
  • Page 79 Detection network camera. Interval Time After motion is detected, the network camera will not detect To Detect motion again for this length of time. For example, using an “Interval Time To Detect” of 20 seconds means that after motion is detected, the camera will not detect any further motion for 20 seconds.

  • Page 80: V-3-1-2 Detection Region

    Detection Region V-3-1-2 When using the network camera’s motion detection function, you can specify the area in the video where the network camera should be sensitive to motion. Motion outside of the detection region will be ignored by the network camera. This is useful to avoid false alarms. Region 1 / Check the box to enable up to three motion detection regions.
  • Page 81 Threshold Adjust the motion detection threshold level for Day Mode or Night Mode. A higher value will trigger the alarm for large objects in the video; a lower value will trigger the alarm for smaller objects. Save Save your settings. 1 Day mode and night mode have separate Sensitivity and Threshold settings.

  • Page 82: V-3-1-3 Schedule Settings

    Schedule Settings V-3-1-3 The network camera’s motion detection function can be scheduled to be active on/at specified times and days. Select “Enable” to enable this feature and then define which times the network camera’s motion detection will be active using the table below. For each day, click and drag across the timeline on the times which you want motion detection to be active.
  • Page 83 Delete Delete the selected blue recording block on the timeline. Delete All Delete all blue recording blocks on the timeline. Select All Select all blue recording blocks. Store Store the recording settings on the timeline.

  • Page 84: V-3-2 Notification

    V-3-2 Notification Mail Settings V-3-2-1 Recordings of events (motion or sound detected) can be sent to a designated email recipient. This function must be enabled in “Motion Detection” or “Sound Detection” settings in the “Events” menu. Enter the required information about your sender and recipient email accounts as shown below. Email Service Select “Manual Settings”...
  • Page 85 SSL/TLS Select ‘SSL or TLS’ when your SMTP server requires encryption. Consult your mail server administrator when in doubt. SMTP Select ‘Enable’ when your SMTP server requires Authentication authentication. This information can be provided by your email service provider. Account Input the SMTP account name when your SMTP server requires authentication.

  • Page 86: V-3-2-2 Ftp

    V-3-2-2 Recordings of events (motion or sound detected) can be sent to a designated FTP server. This function must be enabled in “Motion Detection” or “Sound Detection” settings in the “Events” menu. Enter the required information about your FTP server as shown below. FTP Server Enter the IP address or host name of the FTP server.

  • Page 87: V-3-2-3 Push

    Push V-3-2-3 The network camera can send push notifications to your smartphone if you have the EdiLife app installed. Push notifications can be sent based on motion detection and sound detection events, and also when your camera reconnects to the Internet after a disconnection. Reconnection alerts are sent when the camera actually reconnects to the Internet, not when a disconnection occurs.

  • Page 88: Storage Settings

    Storage Settings The “Storage Settings” menu enables you to configure the settings for local storage of motion or sound detection events/recordings. You can also configure scheduled recording.

  • Page 89: V-4-1 Storage Directory

    V-4-1 Storage Directory The network camera can store recordings of motion detection events to local storage: NAS or MicroSD. Select a video profile for the recordings (HD, SD or Small) and select your storage location and click “Save settings”. A MicroSD card must be installed in the network camera to use this function.

  • Page 90: V-4-2 Schedule Settings

    V-4-2 Schedule Settings The network camera can be scheduled to record automatically at/on specified times and days. Select “Enable” to enable this feature and then define at which times the network camera will record using the table below. For each day, click and drag across the timeline on the times which you want to record.

  • Page 92: V-4-3 Nas Settings

    V-4-3 NAS Settings If using a NAS server for local storage, configure the settings on this page according to your NAS. Status Displays the status (connected or disconnected) of your network camera and NAS server. NAS IP & Sharing Enter the local IP address of your NAS and the path of a Resource shared folder to store your network camera’s recordings.

  • Page 93: V-4-4 Sd Card Settings

    V-4-4 SD Card Settings The “Basic” menu enables you to set the camera’s name and administrator password, as well as switch the LED(s) on/off according to your preference. Unmount your MicroSD card using the “Unmount” button before removing the card from your network camera. Status Displays the MicroSD card status of your network camera: available or unavailable.

  • Page 94: V-4-5 File Management

    V-4-5 File Management The file management tool enables you to browse, download and delete recording files on your MicroSD card. Files are grouped according to the following categories: Event: Recordings or images from motion detection events are displayed here. Schedule: Recordings from scheduled recording are displayed here. Manual: Manual recordings are displayed here.

  • Page 95: System

    System The “System” menu consists of three categories, “Basic”, “Advanced” and “Cloud Service”. Select a category and follow the appropriate chapter for more information.

  • Page 96: V-5-1 Basic

    V-5-1 Basic The “Basic” menu enables you to set the camera’s name and administrator password, as well as switch the LED(s) on/off according to your preference. Network Set the name of the network camera for Camera Name reference/identification purposes. This is especially useful when managing multiple network cameras.

  • Page 97: V-5-2 Advanced

    The “Advanced” page allows you to upgrade the network camera’s firmware, backup or restore the network camera’s settings, and reset or restart the network camera. Please check the Edimax website for the latest firmware for your network camera. Do not switch off or disconnect the device during a firmware upgrade, as this could damage the device.
  • Page 98 default click “Reset to Default”. When the camera resets, “Keep Network Settings” will reset all settings but keep the current network settings. The network camera’s IP address will remain the same. “Default Settings” will reset all of the camera’s settings, including network settings, back to the factory default status.

  • Page 99: Status

    Status The “Status” menu provides important information about the status of the network camera. This information is useful for troubleshooting purposes or for network configuration.

  • Page 100: V-6-1 System Information

    V-6-1 System Information A summary of system-wide information about the network camera is displayed on this page, displayed under four categories: System, LAN, Wireless LAN and IGD (UPnP Port Forward). V-6-2 System Log...
  • Page 101 A system log provides information about the network camera’s usage and actions. The system log can also be sent to a remote server for archiving. Log Level Select a level of detail for the log from the dropdown list, from 0 - 4.

  • Page 102: 16 Channel Viewer For Windows

    16 Channel Viewer for Windows The included 16 channel viewing software provides powerful access to your network camera’s functions, along with the capability to view and manage up to 16 network camera simultaneously. VI-1 Installation Insert the included CD into your CD-ROM drive and if the setup utility does not automatically open, please locate and open the “Autorun.exe”...
  • Page 103 Check the installation location and click ‘Next’ to continue. Click “Next” to continue.
  • Page 104 A summary of your installation will be displayed. Please check everything is correct and click “Install” to begin the installation. Please wait a moment for the installation to complete.
  • Page 105 Click “Finish” and then double click the “IPCam Surveillance Software” icon on your desktop to open the software.

  • Page 106: Using The 16 Channel Viewer

    VI-2 Using the 16 Channel Viewer Your monitor’s resolution must be “1024 x 768” for the 16 channel viewer to work properly. Please set your monitor’s resolution to “1024 x 768”. The main screen of the 16 channel viewer is described below: Video display area Language Display Layout...
  • Page 107 software will switch through the images of all connected camera automatically. Click this button once to activate the scan function (scan icon will become blue ), click again to stop scanning (scan icon will become white PTZ control There are 8 directions in the Pan Tilt Zoom (PTZ) control ring. If the camera you connect to supports PTZ, you can use the PTZ control ring to change the direction that the camera faces.

  • Page 108: Configuring The 16 Channel Viewer

    VI-3 Configuring the 16 Channel Viewer VI-3-1 Add Camera/Camera Configuration In order to use the 16 channel viewer software, you must configure/add each camera(s) that you wish to connect. Please click the wrench icon ( ) and a popup menu will appear: Please select “Camera Configuration”...

  • Page 109: Vi-3-1-1 Camera

    Camera VI-3-1-1 In the “Camera Configuration” tab you can add and configure all the cameras you wish to connect to the viewer software. To connect a camera to the viewer software, you need to enter the required information in the “Camera Configuration”...
  • Page 110 Refresh Refresh the list of cameras on your local network. Name Enter a reference name for the camera here. The default name is the first 6 characters of the camera’s MAC address. The camera name can be used to easily identify its location for example.

  • Page 111: Vi-3-1-2 Scheduled Recording

    Scheduled Recording VI-3-1-2 You can schedule your network camera(s) to record automatically according to weekly schedules, or unique “one-time” schedules. Channel Select the channel number you wish to set. One Time You can specify the one-time schedule for a selected Schedules camera;...
  • Page 112 Edit You can modify a scheduled recording item. Select a schedule in ‘One Time Schedules’ list, and click the ‘Edit’ button to edit the start and end time of this schedule. Delete Delete a selected schedule item. (Weekly Schedules) You can define a weekly recording schedule for specified times and days.

  • Page 113: Vi-3-1-3 Audio

    Audio VI-3-1-3 For cameras that support audio, you can use this tab to decide if you wish to hear the audio captured by the selected camera. Channel Select the channel number you wish to set. Mute Audio Check this box and the network camera surveillance software will not play the audio captured by this camera.

  • Page 114: Vi-3-1-4 Motion Recording

    Motion Recording VI-3-1-4 The network camera features a motion detection function and various options for (motion detection) events notification. On this page you can enable or disable motion detection and set the camera to send an email or trigger an alarm when motion is detected.

  • Page 115: Vi-3-2 General Options

    VI-3-2 General Options Click the wrench icon ( ) and a popup menu will appear: When you select “General Options”, please refer to the appropriate following chapter: General VI-3-2-1 All general settings such as the file storage directory and recording spaces can be set here.
  • Page 116 Video Storage Use the “New”, “Edit” and “Delete” buttons to set the Settings directory for local video storage. Available space in the specified directory will be displayed. Scan Time Define the time period to pause between every camera switch when you activate the ‘Scan’ function. Max Video Set the maximum file size of every video file.

  • Page 117: Vi-3-2-2 Email Settings

    Email Settings VI-3-2-2 If you set your network camera to send email notifications for motion detection events (see V-3-1 Motion Detection), you need to configure your email settings here. E-Mail Subject Specify the subject of the email notification you will receive. Recipient E-Mail Use the “New”, “Edit”...
  • Page 118 SMTP port Specify the port number of the SMTP server you wish to use here. The default value is 25. SMTP Enable or disable SMTP authentication. If you are unsure, Authentication check with your ISP. SMTP Account If using SMTP authentication (above), then enter the SMTP account (username) of your SMTP server here.

  • Page 119: Vi-3-2-3 Security

    Security VI-3-2-3 You can set a password to protect the 16 channel viewer software. When enabled, the password will be required each time to open the 16 channel viewer software. To set the password, please use the ‘Security’ tab in the ‘General Options’ menu: Enable When enabled, the password is required to open the 16...
  • Page 120 When you open the 16 channel viewer software, you will be prompted to enter the password:...

  • Page 121: Vi-3-2-4 About

    About VI-3-2-4 The “About” tab displays the software version number.

  • Page 122: Changing The Display Layout

    VI-4 Changing the Display Layout This network camera surveillance software provides eight display layouts: Each layout displays a different number of cameras in different arrangements. Click the icon which represents your preferred layout and the video display area will change accordingly. Layout style 1: 1 Displays the video of 1 camera only.
  • Page 123 Cameras Layout style 4: 8 Displays the video of up to 8 cameras. Cameras Layout style 5: 9 Displays the video of up to 9 cameras. Cameras Layout style 6: 10 Displays the video of up to 10 cameras. Cameras Layout style 7: 13 Displays the video of up to 13 cameras.
  • Page 124 Layout style 8: 16 Displays the video of up to 16 cameras. Cameras...

  • Page 125: Full Screen Mode

    VI-5 Full Screen Mode Click the ‘Full Screen’ button to switch the display mode to full-screen mode. This uses all available space on your monitor to display the surveillance image. Press the “ESC” key to exit full-screen mode.

  • Page 126: Scan

    VI-6 Scan If you have more than one camera configured, the “Scan” button will switch the display between cameras. “Disconnected” will be displayed in the image window when a configured camera is disconnected. Click the ‘Scan’ button once to activate the scan function (the scan icon will become blue ), click again to stop scanning (the scan icon will become white...

  • Page 127: Zoom In/Out

    VI-7 Zoom In/Out For cameras which support the zoom-in/zoom-out function, you can use this function to enlarge or reduce the image size according to your requirements e.g. to see a certain object in greater detail. Please select a camera in the video display area by clicking on its image, then click the button to see more objects within the camera’s view, or click to enlarge the image size of a certain object to see it in more detail (before...

  • Page 128: Pan & Tilt

    VI-8 Pan & Tilt For cameras which support pan & tilt functions, you can adjust the direction the network camera is facing. Please select a camera in the video display area by clicking on its image, and then click the directions you wish the camera to move to (total 8 directions available).

  • Page 129: Snapshot

    VI-9 Snapshot You can take a snapshot of a selected camera and save it to a ‘Snapshot’ sub-folder in a pre-defined data directory. Click the snapshot button once to take a snapshot; you can take as many snapshots as you want until the hard disk is full.

  • Page 130: Recording

    VI-10 Recording You can start video recording a selected camera’s image by clicking the ‘Start Recording’ button: When recording starts, you’ll see a message displayed in the message display box, such as ‘1/1 10:00:00, Camera 2 Start Manual’, which means camera 2 started recording manually on 1/1 at 10:00:00.

  • Page 131: Video Playback

    VI-11 Video Playback You can playback all recorded video by clicking this button. A new window will appear: You have to search the video file before you can play it. There are two kinds of video search: Time Search (search all videos file that fall within a specific period of time) and Motion Search (search all videos recorded by the motion detection function and fall within a specific period of time).

  • Page 132: Troubleshooting

    If you are experiencing problems with your camera, please check below before contacting your dealer of purchase for help. Are there any microSD/SDHC cards recommended for the IC-9110W V2, IC-7113W & IC-3140W? a. Minimum 8GB capacity is recommended with Class 10 speed rating. Below 2GB and above 32GB are not supported.
  • Page 133 My camera stopped recording to my microSD/SDHC card. a. Go to ‘SD Card Settings’ in the camera’s user interface: 1. Ensure there is enough space on your microSD/SDHC card. 2. Try using “cycle recording” to periodically overwrite old recordings. b. Alternatively you can try formatting your SD card. Be aware that formatting your card removes all existing data, and backup accordingly.
  • Page 134 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 135 EU Declaration of Conformity English: This equipment is in compliance with the essential requirements and other relevant provisions of Directive 2004/108/EC, 2006/95/EC, 2009/125/EC. French: Cet équipement est conforme aux exigences essentielles et autres dispositions de la directive 2004/108/EC, 2006/95/EC, 2009/125/EC Czechian: Toto zařízení...
  • Page 136 Declaration of Conformity We, Edimax Technology Co., Ltd., declare under our sole responsibility, that the equipment described below complies with the requirements of the European R&TTE directive (1999/5/EC, 2006/95/EC) Equipment: Internet Camera Model No.: IC-9110W V2 The following European standards for essential requirements have been followed: Spectrum : ETSI EN 300 328 V1.8.1 (2012-06);...
  • Page 137 Notice According to GNU General Public License Version 2 This product includes software that is subject to the GNU General Public License version 2. The program is free software and distributed without any warranty of the author. We offer, valid for at least three years, to give you, for a charge no more than the costs of physically performing source distribution, a complete machine-readable copy of the corresponding source code.
  • Page 138 Activities other than copying, distribution and modification are not covered by this License; they are outside its scope. The act of running the Program is not restricted, and the output from the Program is covered only if its contents constitute a work based on the Program (independent of having been made by running the Program).
  • Page 139 If distribution of executable or object code is made by offering access to copy from a designated place, then offering equivalent access to copy the source code from the same place counts as distribution of the source code, even though third parties are not compelled to copy the source along with the object code.
  • Page 140 NO WARRANTY 11. BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE, THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM ‘“AS IS’“ WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

Table of Contents
