Populo CURVE User Manual page 8

1
Step 4 – Open the clamp under the seat post, insert the seat post into the frame fully and head of the seat
is parallel with the frame, and set it to a height which fits for the rider then close the clamp to secure the
seat in place.
1
NOTE: Position the seat at the right height is key for better pedaling, safety and overall comfort. The rider' s
leg length is used to determine the seat' s position. When pedaling, your hips should remain level and your
legs should not over-extend. To determine the right seat height, sit on the eBike with pedal at its lowest
pointand place the ball of your foot on the pedal. If you knee slightly at this position, the seat at the right
height. Additionally, when placing your heel on the pedal, your leg should be nearly straight.
Step 5 – Holding the crank arm vertical, fold or unfold the pedal, repeat with other pedal as needed.
Now your new bicycle is fully setup.
1
2
2
3
2
3
07
