Summary of Contents for Populo CURVE
- Page 1 User Manual CURVE 20” Foldable Electric Bicycle Please Read Before Operating Your NEW Electric Bicycle.
-
Page 2: Table Of Contents
GENERAL SAFETY SPECIFICATIONS PRODUCT OVERVIEW ASSEMBLY BATTERY AND CHARGER BATTERY LOCK/REMOVAL DISPLAY DISPLAY SETTINGS HOW TO RIDE FOLD YOUR BIKE MAINTENANCE AND SERVICE TROUBLESHOOTING WARRANTY... -
Page 3: General Safety
GENERAL SAFETY WARNING! It is your responsibility to comply with all tra c related laws and to use proper equipment. This includes appropriate cycling attire and bike maintenance. Observe all local bicycle tra c laws and regulations. Observe regulations about bicycle lighting, licensing riding on pavements/sidewalks, bike path and trail use, helmet laws, child laws relating to cycling, and special bicycle tra c laws, it is your responsibility to know and obey your local laws. - Page 4 Always ride slowly when riding at night. RIDING SAFETY Populo Curve Foldable Electric Bike is designed for paved roads only. Do not attempt to perform jumps, stunts or any other tricks that are outside of the parameters of transport means. The misuse of your bicycle could severely a ect the performance of the components and could cause potential injury.
-
Page 5: Specifications
SPECIFICATIONS Model Name Populo Curve Max. Load Capacity 264.lbs. / 120 kg Max. Speed (Throttle-Only) 20mph / 32km/h Motor 36V 250W Brushless Hub Battery 36V 237.6Wh Li-ion Range Per Charger (Pure-electric 15 Miles / 24Km mode)* Wheel Size 20 x 2.20" Front / Rear Max Inflation to 40 PSI(280KPA), Max Load... -
Page 6: Product Overview
PRODUCT OVERVIEW The Populo Curve eBike is a compact, Eco-friendly with Zero emissions, personal transportation device that feels. Like a bike but rides like a moped. SHIFTER BELL CLAMP HANDLE DISPLAY SEAT REAR BRAKE THROTTLE SEAT CLAMP RACK STEM FRONT BRAKE... -
Page 7: Assembly
ASSEMBLY Populo Curve Foldable Electric Bicycle is designed and simplest assembly without the aid of any tools. You can straight take it from its package and quick to setup by following below steps. Step 1 – Unfold the rear wheel/section and keep your eBike upright with kickstand. While holding the latch lock up, push the latch closed, make sure the hook end of the latch is secure and let the latch lock turn down into the latch to lock everything in place. - Page 8 Step 4 – Open the clamp under the seat post, insert the seat post into the frame fully and head of the seat is parallel with the frame, and set it to a height which fits for the rider then close the clamp to secure the seat in place.
-
Page 9: Battery And Charger
Always use the charger provided with your Populo Curve eBike ONLY, if you have lost or misplaced your charger, contact Populo customer support to obtain a replacement. -
Page 10: Battery Lock/Removal
BATTERY LOCK/REMOVAL For your convenience, the Populo Curve’ s battery can be removed and locked as needed, fold the bike before unlocking and/or removing the battery. Step 1. Use the included keys to unlock the battery through the keyhole inside the folded frame, to... -
Page 11: Display
DISPLAY Display Information The display on the Populo Curve features several di erent elements. Quick-press to adjust power-assisted level from lower to high (1-5), press and hold for 1 second to switch the lights on and o . Press and hold for about 2 seconds to turn the display on/o . Quick-press to cycle between TRIP, VOL, TI and ODO on display. -
Page 12: Display Settings
Always Inspect gears, examine brakes and check tire pressure before riding. Proper tire inflation can reduce flats and improve performance, including travel distance per charge. This Populo Curve Electric Bicycle is designed with 3 di erent riding modes of Pure Electric, Power-assisted as well as Pedal mode. -
Page 13: Fold Your Bike
FOLD YOUR BIKE The Populo Curve can be folded to get it more compact size when not ride for storage, transportation. To fold your eBike by following below steps. 1. Holding the crank arm vertical and fold the pedals. -
Page 14: Maintenance And Service
MAINTENANCE AND SERVICE Properly maintaining your Populo Curve eBike ensures it has longevity and smooth operation. When cleaning your bike, use a damp cloth and gentle dish soap. Note: Do ot use a pressure washer or sprayer. -
Page 15: Troubleshooting
TROUBLESHOOTINGS Code Error How to Resolve Current Error 1.Stop riding and let the bike cool down for. 2 minutes Current Limit Exceeded or to see if the error code disappears. If the error code Damaged Cable persists, check to confirm that the motor and controller cables are properly connected, also check cables for damage or wear and tear on the connectors. - Page 16 Motor Lock Protection Remove the bike from the obstacle, power o , and Hub Motor power on again to resume riding. Encounters Resistance Check all cable connections between the controller Communication Error Controller Has No or Poor and the display and that the connectors are Connection to Display undamaged and not contaminated with grit.
-
Page 17: Warranty
LIMITED 30 DAYS FULL REPLACEMENT WARRANTY IF an Populo Curve bicycles is not working properly because of a major defect within the first 30 days, Populo will repair or replace any defective Populo bike at its sole option and expense upon determining whether the damage, failure, or loss is due to a major defective. - Page 18 THANK YOU FOR CHOOSING www.populo.com info@populo.com...
