- Page 1 HOOD INSTALLATION, MAINTENENCE AND USAGE LA-60-ASCENTI-SS LA-90-ASCENTI-SS Please register your warranty at www.luxairhoods.com...
- Page 4 Ć 8 x 40 mm Ć 4.5 x 50 mm Ć Ć 4.5 x 50 mm 8 x 40 mm Ć Ć 10 cm Ć16cm >1 cm Ć16cm >30 cm This hood must be installed on minimum 125mm round ducting or rectangular equivalent*...
- Page 5 >1 cm -2 cm 220-240V 50-60Hz >30 cm This hood must be installed on minimum 125mm round ducting or rectangular equivalent*...
- Page 6 4x Ć3.9 x 9.5 LED 2x3W...
- Page 7 Closely follow the instructions set out in this manual. All re- sponsibility, for any eventual inconveniences, damages or fires caused by not complying with the instructions in this manual, is declined. The extractor hood has been designed exclusively for domestic use. The hood can look different to that illustrated in the drawings in this booklet.
- Page 8 by a person responsible for their safety. This appliance is designed to be operated by adults, children should be monitored to ensure that they do not play with the appliance. This appliance is designed to be operated by adults. Children should not be allowed to tamper with the controls or play with the appliance.
- Page 9 instructions provided in this manual). Failure to follow the instructions provided in this user guide regarding the cleaning of the hood and filters will lead to the risk of fires. Do not use or leave the hood without the lamp correctly mounted due to the possible risk of electric shocks.
-
Page 10: Ducting Version
Ducting version In this case the fumes are conveyed outside of the building by means of a special pipe connected with the connection ring located on top of the hood. Attention! The exhausting pipe is not supplied and must be purchased apart. Diameter of the exhausting pipe must be equal to that of the connection ring. - Page 11 Electrical connection The mains power supply must correspond to the rating indicated on the plate situated inside the hood. If provided with a plug connect the hood to a socket in compliance with current regulations and positioned in an accessible area, after installation. If it not fitted with a plug (direct mains connection) or if the plug is not located in an acces- sible area, after installation, apply a double pole switch in accordance with standards which assures the complete disconnection of the mains under conditions relating to over-current...
-
Page 12: Operation
Operation Use the high suction speed in cases of concentrated kitchen vapours. It is recommended that the cooker hood suction is switched on for 5 minutes prior to cooking and to leave in operation during cooking and for another 15 minutes approximately after terminating cooking. To select the functions of the hood, it is enough to lightly touch and hold the control. -
Page 13: Maintenance
With the control panel turned on (ON) press buttons P4 and P5 simultaneously for more than 3 seconds, button P5 will light up steadily for about 5 seconds. to confirm activation of the function. To disable the indicator function also press the P4 and P5 buttons simultaneously for approx. -
Page 14: Grease Filter
Grease filter Traps cooking grease particles. This must be cleaned once a month using non aggressive detergents, either by hand or in the dishwasher, which must be set to a low temperature and a short cycle. When washed in a dishwasher, the grease filter may discolour slightly, but this does not affect its filtering capacity.
