- Page 1 Instruction manual LA-350/650/950 Small Ceiling Hood...
-
Page 2: Before Mounting
INSTRUCTIONS FOR USE and PRECAUTIONS Before the fist use pay attention to what has been written in the attached manual. ▪ This appliance should not be operated by minors, children under the age of eight years old or people with learning difficulties, Children above eight years old must be supervised and given clear instruction as to the operation of this appliance. -
Page 3: Mounting Instructions
It is absolutely forbidden for the user to connect the air discharge of the appliance, when used a suction use, to boiler chimneys, gas, fume or vapour scavenging chimneys or any other duct, even only ventilation ducts, which have been used or will be used for other devices. - Page 4 ELECTRICAL TECHNICAL DATA The electrical technical data are visible inside the appliance after the removal of the filters. CONNECTION TO THE POWER SUPPLY The appliance must be used only with the transformer unit supplied with the appliance, and must be connected only to a very safety low tension, corresponding to the marking on the appliance.
-
Page 5: Function And Use
For the sizes of the cable section of the connection-cables between the tranformer and the appliance, please follow the instruction in the following table: Length of cables between the transformer unit and the appliance Section cables mm² ≤ 8 m ≤... - Page 6 button for sensor), in case the humidity or temperature increase, the motor is started in automatic way at the intermediate speed for 20 minutes. The led bars have got a protective layer resistant to liquid infiltration. Small surface imperfections belong to the process and are to be considered normal. The remote control is not waterproof, so it must be used in appropriate way.
-
Page 7: Maintenance
External Push button for sensor (PS). Activation/deactivation of the automatic function: Make sure that the motor is off before the push button is pressed. ■ Press the push button: if 4 acoustic signal are issued the automatic function is ■ activated. -
Page 8: If You Encounter A Problem
IF YOU ENCOUNTER A PROBLEM Disconnect the appliance from the mains electricity supply and keep it disconnected for ca 1 minute, then reconnect. If the behaviour of the hood seems strange, read the procedure for resetting carbon and grease filters concerning the kind of control in your hood. (see FUNCTION AND USE). If the lights of the lamps is weak when the hood is in stand-by, then invert the plug. - Page 9 ¨ 120 ¨ 120 ¨ 120 Model SHOWAIR 300 SHOWAIR 600 SHOWAIR 900...
- Page 10 220-240 Vac 12Vdc TRAFO 0,6 m 0,6 m 0,6 m <0,15 m >0,15 m...
- Page 11 0,6 m 0,6 m 0,6 m <0,15 m >0,15 m 1,2 m 1,2 m 1,2 m...
- Page 12 (OPTIONAL) 12 Vdc...
- Page 15 Luxair (see spares section on our website). Your ceiling extractor is already pre-wired to the transformer, however should you need to replace it in the future please see picture below showing the electrical connections.
- Page 16 Setting Your Remote Control! 1. Turn Off The Power Completely to your ceiling extractor 2. Press and hold the + button on your remote continually pointing it at you extractor. 3. whilst keeping your finger on the + button now turn the power back on to your fan, (keep the + pressed all the time) you will hear a BEEP to confirm the unit has accepted the code.
- Page 17 Warranty Activation www.luxairbathroomfans.com Two Year Parts and Labour Warranty - Your product must be registered with Luxair within 21 days of installation either , or by mail. A 12 month parts and labour warranty is standard without product registration but proof of purchase may be required.
