Srhythm X1 - Noise Cancelling Headphones Manual

Table of Contents

Contents

1 Safity Instructions
- 1.1 Hearing Safity
- 1.2 Operation Safity
2 What's in the Box
3 At a Glance
4 How to Use
5 Functions
6 How to Wear
7 Specification
8 Technical Specification
9 Q&A
10 Documents / Resources
- 10.1 Download manual

Safity Instructions

Hearing Safity

To avoid hearing damage, please do no t listen for a long time at high volume.
Please use cautiously or stop using the headphones in potentially dangerous situations.
Do not use the headphones while driving.
For your safety, please do not turn the volume too high while running outsideso as to ensure that you can hear sounds in your surroundings.

Operation Safity

Avoid dropping.
Do not disassemble.
Keep away from children to avoid danger from improper use.
Do not submerge in water.
Do not use outdoors during thunderstorms.
Avoid operating in extreme temperatures. Please use the headphones within their operation temperature range: -15°C (5 F) – 55°C(131 F).
Use original or certified cables for charging.
Do not use corrosive cleaner/oil to clean the headphones.

What's in the Box

At a Glance

How to Use

Hold the Multi-function Button for 3 seconds to turn the headphones on and they will enter pairing mode. (the indicator light will turn blue)

Hold the Multi-function Button for 3 seconds to turn the headphones off.

Press to adjust volume. Long press to skip to next/previous song.

Press the Multi-function Button to play/pause music.

Press the ANC Button to turn Active Noise Cancellation on/off (the indicator light will turn green).

Press the Multi-function Button to answer/end call.

Double-press the Multi-function Button to reject an incoming call.

Charging: Use the included micro USB charging cable to connect to the Charging Port of of the headphone. Connect the other end of the charging cable to either a computer USB port or USB wall charger.

Functions

Easy Paring

Hold the Multi-function Button for 3 seconds to turn the headphones on and they will enter pairing mode.
Keep the headphones and your Bluetooth device as close as possible during the pairing process.
Turn on the Bluetooth function of your Bluetooth device. Search for the Bluetooth signal of the headphones on your Bluetooth device, and select"X1"to pair it with your Bluetooth device. The indicator light will slowly flash blue when the headphones are paired successfully.
If you are asked for a password/PIN code during the pairing procedure, enter "0000" (four zeros).

Pair to the secod Bluetooth Device

Make sure the headphones are connected to the first Bluetooth device successfully and music is not playing.
Hold the Multi-function Button until the headphones re-enter pairing mode (the indicator light will flash red and blue alternately).
Pair the headphones with the second device according to "Easy Pairing" steps.
Return to the first Bluetooth device and pair it with the headphones again. Now both of your devices are paired with the headphones.

ANC-Active Noise Cancelling

To turn on ANC, press the ANC Button;
the green ANC Indicator light will turn on.
To turn off ANC, press the ANC Button;
the green ANC Indicator light will turn off.

AUX wired connection

The headphones support AUX input for wired external audio source connection. Simply turn the headphones off and plug in the audio cable.

Voice Dialing

Press both the Volume Up and Volume Down buttons simultaneously to activate the voice dialing function(compatible with iPhone Siri and selected Android voice dialing software).

How to Wear

Specification

Indicator Light

Pairing: Red and blue lights flash alternately
Paired: Blue light flashes
Playing: Blue light slowlyflashes
Charging: Red light turns on
Full Charge: Red light turns off
Battery Low: Red light turns on with voice prompt
ANC On: Green light turns on.

Technical Specification

Product name: X1
Battery capacity: 800mAh
Input: 5V-12V
Charging time: About 1-2 hours
Use time: 30-40 hours
Bluetooth version: V5.0
Chip: CSR
Bluetooth profile: A2DP, AVRCP, HSP, HFP, CVC
Bluetooth range: 10m/33ft
Waterproof rating: IPX4
Net weight: 180g
Impedance: 32 Ω
Driver diameter: Φ40mm
Frequency response: 20–20KHz

If any isssues, please full charge your headphone, then Reset the headphone by inserting the audio cable into audio socket then removing it.

Q&A

Q: Why can't the headphones pair with my mobile phone?

A: Please check whether your headphones are in pairing mode or reconnection mode, check if the Bluetooth search function of your Bluetooth device is turned on, then go to the Bluetooth menu of your Bluetooth device, delete/forget the headphones and reconnect them.

Q: Why can't the headphones turn on?

A: Please double check the battery status of your headphones.

Q: Can I replace the battery in the headphones?

A: No. These headphones use a built-in non- detachable Li-Polymer battery which can't be replaced.

Q: Can I use the headphones while driving?

A: For your safety, we strongly recommend you do not use headphones while driving so as to avoid distraction.

Q: Why do the headphones sometimes disc-onnect from the Bluetooth device within 10 meters?

A: Please check if there is any metal material within a relatively close range that may be interfering with the
Bluetooth connection. This may happen because
Bluetooth is a radio technology which is sensitive to objects between the headphones and the inconnected devices.

Q: Why can't I hear any sound from my computer or mobile phone?

A: Please check if the output channel of your computer supports the A2DP profile. Also check the volume settings on your headphones and computer/mobile phone.

Q: Why am I unable to use the headphones to control the volume of a track playing on an APP on my mobile phone?

A: Due to the configurations of different application software, the headphones may not be completely compatible with some APPs.

Q: What do I do if Bluetooth crashes?
(Cannot close or open)

A: Please reset the Bluetooth function of the headphones by inserting an audio cable into the audio port and removing it.

Q: Why does Bluetooth turn off when I connect an audio cable?

A: This is one of our special features. When the user inserts an audio cable into the audio port, all Bluetooth feature buttons stop working and Bluetooth turns off. Don't worry, Bluetooth will be available again when the audio cable is moved.

Q: Why can't I turn the headphones on/off?

A: Please note that ANC and Bluetooth are indicated by the same indicator light, with a green light for ANC and a blue light for Bluetooth. If you need to turn Bluetooth on/off, please make sure you first turn off ANC.
