OwNERS
MANUAL
Model No.'s
45-01012
190-653B
CAUTION:
Read Rules for
Safe Operation
and Instructions
WMV-
Digitally signed by WMV-Dresden
PRINTED IN USA
DN: cn=WMV-Dresden, c=DE,
o=WMV-Dresden,
Dresden
email=noreply@wmv-dresden.de
Date: 2017.01.26 13:00:45 +01'00'
™
Assembly
Operation
Maintenance
Carefully
Repair Parts
the fastest way to purchase parts www.speedepart.com
UTILITY CARTS
(SEE SPECIFICATIONS ON PAGE 7)
FORM NO. 40311 (REV. 4/9/08)
Advertisement
Related Manuals for Agri-Fab 45-01012
Summary of Contents for Agri-Fab 45-01012
- Page 1 ™ OwNERS MANUAL Model No.'s 45-01012 190-653B UTILITY CARTS (SEE SPECIFICATIONS ON PAGE 7) CAUTION: Read Rules for Assembly Safe Operation Operation and Instructions Maintenance Carefully Repair Parts the fastest way to purchase parts www.speedepart.com WMV- Digitally signed by WMV-Dresden PRINTED IN USA FORM NO.
- Page 2 SAFETY RULES Remember, any power equipment can cause injury if operated improperly or if the user does not understand how to operate the equipment. Exercise caution at all times when using power equipment. CAUTION: VEHICLE BRAKING AND LOOK FOR THIS SYMBOL TO POINT OUT STABILITY MAY BE AFFECTED wITH THE IMPORTANT SAFETY PRECAUTIONS.
-
Page 3: Table Of Contents
HARDWARE SHOWN FULL SIZE Not Shown Full Size FIGURE 1 - HARDwARE PACK Ref. Description Quantity Hex Bolt, 1/4" x 5/8" Hex Bolt, 3/8" x 1" Truss Hd. Bolt, 5/16" x 3/4" Lg. Nylock nut, 1/4" Nylock nut, 5/16" Hex Lock Nut, 5/16" (SEMS) Nylock nut, 3/8"... -
Page 4: A Hex Bolt, 1/4" X 5/8
ASSEMBLY INSTRUCTIONS 5. Position the tailgate reinforcement bracket on outside of cart as shown in figure 3. Assemble to the bottom of the cart body using four 5/16" x 3/4" truss head bolts TOOLS REQUIRED FOR ASSEMBLY and 5/16" nylock nuts. Do not tighten. See figure 3. Screwdriver 6. Position the tailgate guides on the inside of the cart Pliers bodies with guide channels to the front as shown in 7/16"... -
Page 5: B Hex Bolt, 3/8" X 1
9. Assemble the front panel over the end of the cart using 11. Turn the latch stand bracket so that the aligning tab is four 1/4" x 5/8" hex bolts and 1/4" nylock nuts as shown at the rear (bottom) of the bracket. Assemble the latch in figure 5. Leave two holes shown in figure 5 empty stand bracket to the cart using four 1/4"... -
Page 6: E Nylock Nut, 5/16
13. Insert a flange bearing into each side of the tongue as 16. Place the latch lock lever through the slot in the draw shown in figure 9. bar tongue as shown in figure 10. Assemble the 5/16" x 3-3/4" hex bolt through the tongue, the lever and two 5/16" hex nuts (SEMS) (one on each side of the lever). Assemble the 5/16" hex lock nut onto the end of the FLANGE BEARING bolt and tighten so that the bolt can still rotate freely. -
Page 7: H Flat Washer, 3/4
3. Keep tires filled to the recommended tire pressure of NYOCK printed on the tire. CART MODEL SPECIFICATIONS FIGURE 14 MODELS 45-01012 & 190-653B 22. Place the tailgate down into the tailgate guides so that Tires: 16.00" x 4.0" Pneumatic the holes in the bottom lip of tailgate fit over the truss Axle: 3/4"... - Page 8 REPAIR PARTS FOR UTILITY CARTS MODELS 45-01012 & 190-653B...
- Page 9 REPAIR PARTS LIST FOR UTILITY CARTS MODELS 45-01012, 190-653B REF. PART 45-01012 DESCRIPTION 190-653B 23985 Cart Body 23502 Tailgate 62458 Tailgate Reinforcement Bracket 23548 Guide, Tailgate 23492 Front Panel 25996 Wheel Support 24497 Latch Stand Bracket 24498 Latch Lock Lever...
- Page 10 NOTES...
- Page 11 SLOPE GUIDE (Keep this sheet in a safe place for future reference.) Use this guide to determine if a slope is safe for the operation of your tractor and cart. Refer also to the instructions in your vehicle owners manual.
- Page 12 REPAIR PARTS Agri-Fab, Inc. 303 West Raymond Sullivan, IL. 61951 217-728-8388 www.agri-fab.com © 2001 Agri-Fab, Inc.
