Operating Your Receiver

Display

DVD / VCD / CD / mp3
• Unit in DVD, VCD, CD or mp3 mode.
D I G I TA L
• Audio output is in Dolby Digital mode. (For DVD only)
PL
• Audio output is in Dolby PL II Movie, Dolby PL II Music
or Dolby Prologic Emulation mode.
RND
• Random playback mode activated.
• Currently in playback mode.
• Currently in pause mode.
TITLE
• Title number for DVD playback.
TRK
• Track number being played.
CHP
• Chapter number for DVD playback.
PROG.
• Program mode is activated.
STEREO
• Tuner stereo signal detected.
12
REP 1 / REP / A.B. / REPEAT FOLDER (mp3 only)
• CD, mp3 and DVD in repeat mode.
KHz / MHz
• Tuner frequency unit.
• Speaker Icons.
SLP
• Sleep mode is activated.
Switching on /off
• To switch on the receiver, press STANDBY/ON on the
receiver once to wake up from standby mode. Press one of
the source buttons or ON/OFF on the remote control to
turn on the receiver.
STANDBY/ON
• When the receiver is on, press ON/OFF on the remote or
STANDBY/ON on the receiver to return to the standby
mode.
When you turn up the unit for the first time:
1. A startup menu will show on the screen when you turn
on the unit for the first time.
English Select a Menu Language
Francais Select langue de menu
Espanol Seleccione Idioma Menu
Menusprache auswahlen
Deutsch
Selez lingua dal menu
Italiano
2. Use UP/DOWN to highlight the language you want, then
press OK.
3. The chosen language will be your default menu lan-
guage.
Note:
When the startup menu shows on the
display, the OPEN/CLOSE button is
disabled.
Operating Your Receiver

Selection of Audio source

When one of the audio source is selected, the audio input
corresponding to the name will be activated.
The receiver acts as a switching device between all the
sources that are plugged into it.
Example 1:
If you connect a MD player to the AUX 1 input on the
receiver and press SOURCE until "AUX 1" shows on the
display. You will be able to have the signal from the MD
player.
AUX 2 AUX 2 AUX 1 AUX 1
VCR VCR
SAT.CABLE SA .CABLE
EN
