Jayco PINNACLE FIFTH WHEELS 2019 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
2016 CAMPING TRAILERS
2019
FIFTH WHEELS
Owner's Manual
PRINTED ON RECYCLED PAPER
0210677.2019

Advertisement

Table of Contents
loading

Related Manuals for Jayco PINNACLE FIFTH WHEELS 2019

Summary of Contents for Jayco PINNACLE FIFTH WHEELS 2019

  • Page 1 2016 CAMPING TRAILERS 2019 FIFTH WHEELS Owner’s Manual PRINTED ON RECYCLED PAPER 0210677.2019...
  • Page 3 Great Outdoors. 2019 Jayco Pinnacle FW Rev.A Page 9: Factory Tours section added, Page 10: Revised Emergency Warranty phone number, Page 16: Revised Warranty, Page 27: Exit Windows – add caution box, Page 40: Wire Harness / Connector Plug –...
  • Page 5 Table of Contents Section 1: Warranty & Service Factory Tours Options and Equipment Dealer Responsibility Customer Relations About This Manual Warranty Packet Safety Alerts Reporting Safety Defects Customer Responsibility Change Of Address/Ownership Suggestions For Obtaining Service Obtaining Service For Separately Warranted Items Obtaining Service At Our Customer Service Facility Parts and Accessories Section 2: Occupant Safety...
  • Page 6 Table of Contents Entrance Door Rear Backup Camera Prep Campsite Hook-Up LCI 3.0 Leveling System (if so equipped) Auto Leveling Touch Pad OneControl Touch Panel Linc Remote Control Troubleshooting OneControl Touch Panel Linc Remote Dexter EZ Flex Equalizer (if so equipped) Stabilizer Jacks Manual Stabilizer Jacks (if so equipped) Electric Stabilizer Jacks (if so equipped)
  • Page 7 Table of Contents Section 6: Electrical System The Electrical System In Case Of An Electrical Fire Command Center Command Center Panel Command Center Panel W/Switch Modules GFCI Receptacle LCI One Control® System 5” Touchscreen Testing The Campsite Power Connection Connecting the Power Cord Inverter (if so equipped) Power Converter Converter with Charge Wizard (if so equipped)
  • Page 8 Table of Contents Using the Propane System Cooking with Propane Gas Calculating Propane Gas Usage Cooking / Comfort Heating Label Installing Propane Cylinder(s) Refueling Warning Label Double Cylinder Single Cylinder Traveling With Propane Main Supply Hose Two Propane Cylinders Section 8: Plumbing System Plumbing System Plumbing System Maintenance Monitor Panel...
  • Page 9 Table of Contents Power Roof Vent (if so equipped) Attic Fan Control Ceiling Fan (if so equipped) Furnace Fireplace (if so equipped) Section 10: Appliances Microwave Cooking Safety In Case Of a Grease Fire Cooktops; Range and Oven (if so equipped) Electric Drop-In Cooktops (if so equipped) Cooking With Propane (if so equipped) Gas Drop-In Cooktops (if so equipped)
  • Page 10 Table of Contents Booth Dinette (if so equipped) Free-Standing Table and Chairs (if so equipped) Pantry or Hutch (if so equipped) Countertops Laminate Countertops (if so equipped) Solid Surface Countertops (if so equipped) Flooring Carpet Vinyl Flooring Bed Storage Loft Sleeping Area (if so equipped) Bunk Beds (if so equipped) Bunk Bed Ladder (if so equipped) Safe (if so equipped)
  • Page 11 WARNING: Read all instructions in this manual and component manufac- turer supplied information before using your RV. This manual has been provided by your recreational vehicle manufacturer for the sole pur- pose of providing instructions concerning the operation and maintenance of this recreational vehicle.
  • Page 12 Maintenance Record Table of Contents...

  • Page 13: Section 1: Warranty & Service

    Canada may differ to conform to Canadian Codes. Dealer Responsibility At the time of sale of the new recreation vehicle, your Jayco dealer is expected to: Deliver your recreation vehicle in the best condition possible. Your recreation ve- hicle must pass the dealer’s pre-delivery inspection (PDI), including all systems...
  • Page 14 (or any effect of the alterations) to any of the parts, components, systems or assemblies installed by Jayco. Jayco is not responsible for the safety or quality of design features, materials or workmanship of any alterations by such suppliers.

  • Page 15: About This Manual

    Canada. In addition, the club offers a variety of local and regional activities throughout the year. By belonging to the Jayco Travel Club, you will find new ways to enjoy your RV and make friends all across the country.

  • Page 16: Warranty Packet

    Section 1: Warranty & Service Warranty Packet There are components that are excluded from the vehicle warranty, or are warranted sepa- rately by their own individual manufacturer’s limited warranty. The Warranty Packet con- tains these component manufacturer supplied manuals or information sheets, warranty cards and/or registrations.

  • Page 17: Reporting Safety Defects

    Section 1: Warranty & Service  Indicates a potentially hazardous situation that, if not avoided, may result in death or serious injury. Reporting Safety Defects In the United States: If you believe that your recreation vehicle has an alleged defect which could cause a crash or cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA), in addition to notifying our Cus- tomer Service Department.

  • Page 18: Customer Responsibility

    Section 1: Warranty & Service Customer Responsibility It is important you read and understand all instructions and precautions before operating the recreation vehicle. Even if you are an experienced RV’er we encourage you to thoroughly read this Owner’s Manual, as well as the information contained in your Warranty Packet and Chassis Guide (motorized only).

  • Page 19: Obtaining Service For Separately Warranted Items

    Section 1: Warranty & Service Please be aware that all service shops require notification of any issues with their repairs within a specified time limit. Make sure you are familiar with their repair policies. Obtaining Service For Separately Warranted Items Your selling dealer is responsible for servicing your recreational vehicle before delivery, and has an interest in your continued satisfaction.
  • Page 20 If a substantial defect in material or workmanship, attributable to Jayco, is found to exist and is reported to Jayco or an autho- rized servicing dealer during the applicable warranty period, it will be repaired or replaced, at Jayco’s option, without charge to the RV owner, in accordance with the terms, conditions...
  • Page 21 RV is delivered to the first retail purchaser by an independent, authorized dealer of Jayco, or, if the dealer places the vehicle in service before retail sale, on the date the RV is first placed in such service.
  • Page 22 RV not attributable to Jayco; • items that are added or changed after the RV leaves the possession of Jayco; • additional equipment or accessories installed at any dealership, or other place of busi- ness, or by any other party, other than Jayco;...
  • Page 23 Certain things completely discharge Jayco from any obligation under this warranty and void it. By way of example, the following shall discharge Jayco from any express or implied warranty obligation to repair or replace any defect that results from: any rental or other busi-...
  • Page 24 In addition, this warranty is not intended to extend to future performance, and nothing in this warranty, or any action of Jayco, or any agent of Jayco, shall be interpreted as an extension of the warranty period or this limitation period.

  • Page 25: Section 2: Occupant Safety

    Section 2: Occupant Safety Secondary Means of Escape (Exit Window) Your recreation vehicle has been equipped with a window(s) that serves as a secondary means of escape. The window(s) will allow a quick exit from the vehicle during an emer- gency if access to the main entrance door is not available.

  • Page 26: Fire Safety

    Section 2: Occupant Safety Lever style latch Remove the screen by pulling the red tab (upper rightarrow). Pull the lever out from the sash clamps. Swing the lever out so it is positioned straight out from the win- dow. Push the lever (and window) out to open and exit the vehicle. Lever style latch Remove the screen by pulling the red tab (upper rightarrow).

  • Page 27: Smoke Alarm

    Section 2: Occupant Safety  Do not check the pressure, test or practice using the fire extinguisher by squeezing the trigger, even briefly. The fire extinguisher is not rechargeable or refillable. Once used, it will gradually lose pressure and will not be fully charged for use in an emergency.

  • Page 28: Combination Carbon Monoxide /Propane Alarm

    Section 2: Occupant Safety When the battery becomes weak, the alarm will “beep” about once a minute indicating a low battery. This warning should last for 30 days. You MUST replace the battery once the alarms low battery warning (beep) starts to assure continued protection. When the battery is removed from the alarm, the battery flag will pop up;...
  • Page 29 Section 2: Occupant Safety The alarm is directly wired to the 12-volt electrical system, with continuous power being supplied by the recreational vehicle batteries. There is no 9-volt battery power supply. As a result, the alarm is al- ways drawing a small amount of current from the recreation vehicle batteries.
  • Page 30 Section 2: Occupant Safety What you should do if the alarm sounds  Actuation of this detector indicates the presence of carbon monoxide which can kill you. Never turn the 12-volt battery disconnect control to the off position and disconnect the battery cable to silence an alarm. The alarm will auto- matically sense when the level of carbon monoxide in the air reaches below dangerous levels.
  • Page 31 Section 2: Occupant Safety Testing the combination carbon monoxide/propane alarm  Test the alarm operation after the RV has been in storage, before each trip and at least once per week during use. The TEST/RESET button tests all ELECTRICAL functions of the alarm. The TEST/Mute switch is located on the front of the alarm.

  • Page 32: Extended Or Full Time Usage

    Section 2: Occupant Safety Extended Or Full Time Usage Your new recreation vehicle has been built for enjoyment in a recreational manner. It is not intended for use as full-time quarters or a permanent residence. Continuous living in your vehicle could cause accelerated wear and damage to the various components. ...

  • Page 33: Section 3: Pre-Travel Information

    Section 3: Pre-Travel Information Tow Vehicle If you plan to tow your recreation vehicle with a tow vehicle you already own, or if you plan to purchase a new one, make sure the Gross Vehicle Weight Rating (GVWR) or your recreation vehicle does not exceed your tow vehicles towing rating.
  • Page 34 Section 3: Pre-Travel Information OCCC Label (Occupant and Cargo Carrying Capacity: The upper portion of this yellow label is fed- erally required and includes the maximum Oc- cupant & Cargo Carrying Capacity that may be placed in or on the trailer as it was manufac- tured and weighed before leaving the factory.

  • Page 35: Loading Your Recreation Vehicle

    Section 3: Pre-Travel Information Loading Your Recreation Vehicle  Never load the RV in excess of the GAWR for either axle. Over- loading your RV may result in adverse handling characteristics and damage to the RV. DO NOT EXCEED YOUR GVWR! This means you should weigh your RV as loaded for your normal travel to determine the actual weight.

  • Page 36: Rear Bumper

    Section 3: Pre-Travel Information Rear Bumper  Do not add items to the recreation vehicle rear bumper. Add-on items will eventually damage your bumper. Damage caused by such aftermarket equip- ment installation or improper loading voids the Towable Limited Warranty. The rear bumper of your RV is not designed to carry cargo.
  • Page 37 Section 3: Pre-Travel Information Your recreation vehicle manufacturer cannot be responsible for the suspension system of any tow vehicle. There are a variety of tow vehicle suspension systems available that will affect the pin box height, stability and levelness of a hooked up Make sure your dealer is aware of the tow vehicle you are using so a compatible hookup is achieved.

  • Page 38: Wire Harness/Connector Plug

    Section 3: Pre-Travel Information Wire Harness/Connector Plug A 7-way wire harness/connector plug is wired into your trailer to connect electrical power from the tow vehicle for travel. This supplies power to the RV brakes, taillights, clearance lights, turn signals, brake lights, etc. Wiring to operate your brakes must be the same size in both the tow vehicle and RV (the RV brake wiring is 12-gauge wire).
  • Page 39 Section 3: Pre-Travel Information Weigh the RV including the tongue weight, while detached from the tow vehicle. This actual overall weight must be less than or equal to the GVWR for safe operation. If the overall weight is greater than the GVWR, some contents must be removed until the actual overall weight is less than or equal to GVWR.
  • Page 40 Section 3: Pre-Travel Information Notes: Maintenance Record Table of Contents...

  • Page 41: Section 4: Vehicle Operation

    Section 4: Vehicle Operation Towing  Your RV braking system is rated for operation at GVWR not GCWR. Whenever possible, do not travel with waste in the holding tanks. Liquid or debris in the holding tank(s) may affect the towing characteristics and may result in property damage or personal injury.
  • Page 42 Section 4: Vehicle Operation have not been affected. Never operate any vehicle if a difference in braking efficiency is noticeable. Electric Brakes  Failure to maintain the brakes in proper working condition as specified in the operator’s manual supplied by the axle OEM will cause property damage, personal injury and possibly death.

  • Page 43: Towing Behind Your Rv

    If you do not have a Jayco factory installed hitch receiver, towing items behind your Jayco RV, or overloading the rear, will void the warranty and may result in: damage to the RV or add-on items, towing difficulties, property dam- age and/or personal injury.
  • Page 44 Section 4: Vehicle Operation Stowable Entrance Door Step(s) (if so equipped)  Do not try to lift the steps while the door is closed. This may cause dam- age to the steps and the door. When returning steps to the stored position: adjustable feet may have to be retracted to fit inside the door opening.

  • Page 45: Entrance Door

    Section 4: Vehicle Operation Entrance Door Always hold onto the entrance door when opening or closing it. Damage caused because you failed to do so is not covered by the Limited Warranty.  Make sure the entrance door is completely closed and locked when traveling. Locking the door helps prevent it from opening unintentionally and keeps in- truders from your recreation vehicle.

  • Page 46: Campsite Hook-Up

    Section 4: Vehicle Operation Campsite Hook-Up Refer to Electrical Systems section before connecting the shore line power cord (when using full hook-up) OR before starting the generator (if so equipped) or operating the vehicle on 12-volt power when dry camping. Refer to Fuel &...
  • Page 47 Section 4: Vehicle Operation  Failure to act in accordance with the following warnings may result in serious personal injury or death! Never use the auto leveling system to lift the RV off the ground. Lift- ing the RV so the wheels are not touching the ground will create an un- stable and unsafe condition.
  • Page 48 Section 4: Vehicle Operation The OneControl touch screen or Leveling App will show the specific error. Refer to troubleshooting section of the LCI Ground Control 3.0 manual to clear the error. NOTE: Refer to the Lippert Ground Control 3.0 manual included in our warranty packet for complete instructions on the following procedures.
  • Page 49 Section 4: Vehicle Operation NOTE: If the AUTO LEVEL sequence does not perform as described above, place the system in manual mode and test that the jacks operate correctly by using the OneControl touch panel inside the RV. OneControl Touch Panel Press the button at the bottom of the touch panel to power up the display.
  • Page 50 Section 4: Vehicle Operation The following functions can be operated using the OneControl App. Refer to the Ground Control 3.0 manual for complete instructions. Standard Mode and Menu Basic Jack operation Unhitching Instructions Auto Leveling Linc Remote Control Configuring the remote to sync with the OneControl Touch panel: Press the chrome button on the bottom of the remote to turn it on.

  • Page 51: Stabilizer Jacks

    Section 4: Vehicle Operation Dexter EZ Flex Equalizer (if so equipped) Your recreation vehicle may be equipped with the Dexter EZ Flex Equalizer suspension. This includes heavy-duty shackles and wet bolts. Wet bolts have a grease zerk attached to the head of the bolt, and a hollow channel inside going to a single hole in the middle of the bolt.

  • Page 52: Emergency Stopping

    Section 4: Vehicle Operation Disconnect the battery from the system prior to manual operation. Operation: Insert the 1/2” diameter crank handle inside the coupler. The slot in the end of the crank handle accommodates the pin inside the coupler to allow manual extension/retrac- tion of the stabilizer jack.

  • Page 53: Emergency Towing

    Section 4: Vehicle Operation Emergency Towing  Never allow anyone to go under the recreation vehicle while it is being lifted and/or being towed. If your recreational vehicle needs to be towed, please contact an emergency road service provider or a qualified service facility for assistance. Wheel Lugs After your first trip, check the wheel lug torque periodically for safety.
  • Page 54 Section 4: Vehicle Operation Wheel Lug Nut Diagrams Because of the importance of having proper torque on the wheel lug nuts, you should always have the wheels mounted and properly torqued by a qualified technician using the proper tools. Wheel Lug Nut Torque Values Prior to travel and after excessive braking, wheel lug nuts should be checked for torque.
  • Page 55 Section 4: Vehicle Operation Lug Nut Pattern and Warning Label The following labels showing the proper lug nut tightening pattern and a warning label are located on the driver side of the A frame hitch on travel trailers, and on the driver side of the pinbox on fifth wheel units.
  • Page 56 Section 4: Vehicle Operation Tires Read and understand the following before taking your first trip in your RV. Routine maintenance on your RV is important. To insure your tires are operating safely, regular inspection of the tires and checking tire pressures is absolutely mandatory. Alignment, balance and bearing wear will affect tire wear.

  • Page 57: Changing A Tire

    Section 4: Vehicle Operation NOTE: Cold tire inflation pressure is defined as a tire that has not been used for three or more hours, or has been driven less than one mile. Tire inflation pressure of a hot tire may show an increase of as much as 6 psi over a cold tire.

  • Page 58: Spare Tire Carrier (If So Equipped)

    Section 4: Vehicle Operation If you experience a flat tire on your recreational vehicle while driving, gradually decrease your speed and move the recreational vehicle to a safe place on the side of the road. Keep the recreational vehicle attached to the tow vehicle. Block the tire on the opposite side of the recreational vehicle from the tire you are changing.
  • Page 59 Section 4: Vehicle Operation Raising and lowering the hoist The crank handle to raise and lower the tire will be located (fastened to the sidewall) in a basement compartment of the recreational vehicle. Insert the crank handle into the crank access port located either in the center of the rear bumper, or on the sidewall of the RV.

  • Page 60: Setting Up Your Recreation Vehicle

    Section 4: Vehicle Operation Place the support bracket over the bottom lug bolt across the center of the rim (photo). Install the bottom lug nut over the support bracket. Tighten the lug nuts securely before returning to travel. Vinyl Tire Cover (if so equipped) Your tires are manufactured with components that cause “bleeding”...
  • Page 61 Section 4: Vehicle Operation To set up the patio deck, unlatch the two keyed handles from the side of the RV (Fig 4). Lower the patio deck until the cables on each side support it. Support cables are attached at the top of the door opening with a quick link (Fig 1) and to the deck with a safety pin (Fig 3).

  • Page 62: Awnings (If So Equipped)

    Section 4: Vehicle Operation Optional Step Ladder There is an optional step ladder which can be set up at the front of the patio deck. The railing must be unfolded and secured before it can be used. Unsnap the band holding the rail to the steps (Fig 10).

  • Page 63: Power Awnings (If So Equipped)

    Section 4: Vehicle Operation Your recreation vehicle may include one or more of the following options: Power window awning Slide out awnings Power awning over entrance door Power switches to operate the awnings are typically found in the control panel above the entrance door.
  • Page 64 Section 4: Vehicle Operation Adjusting the Awning Pitch  Do not set the individual arm pitch at more than three (3) positions differ- ent between the left and right arms. Damage to the arms and the canopy can occur if the awning is retracted when the arms are set at more than three (3) positions difference.
  • Page 65 Section 4: Vehicle Operation Emergency Operation If power to the vehicle is not available, the awning can be retracted by jumping the motor using a 10VDC – 14VDC power source such as a cordless drill battery or car battery. Remove the front cover (the cover snaps onto the rear cover).
  • Page 66 Section 4: Vehicle Operation Locate and separate the quick disconnects located in the motor arm channel. Position the wires from the motor on the outside of the channel. Attach jumper wires to the motor wires. Connect the other ends of the jumper leads to the 10VDC–14VDC source. If the awning moves in the wrong direction, reverse the leads.

  • Page 67: Section 5: Slideout Systems

    Section 5: Slideout Systems Electric Slide Room(s) (if so equipped) The mechanical components of the slide out are gear driven. Electric powered slideout room systems have a manual override to allow you to extend or retract the slideout room(s) in case of a power loss.
  • Page 68 Section 5: Slideout Systems After the slideout is extended, visually inspect the slideout and the surrounding area to make sure the slideout has extended properly and has adequate clearance from any outside obstruc- tions. If the slideout is equipped with rubber seals, verify that the corners of the black rubber seal are set up correctly.
  • Page 69 Section 5: Slideout Systems Trouble shooting the flush floor slideout Refer to the general troubleshooting check list before proceeding. Electric Operation NOTE: Install transit bars (if so equipped) on the slideout room during storage and transportation. Extending/retracting the room Level the unit. Main Power switch at stepwell (locations may vary) must be ON.
  • Page 70 Section 5: Slideout Systems Schwintek In-Wall Slideout System The in-wall slideout system requires no maintenance or adjustments. This system has two vertical columns with a drive motor located at the top of each column. The right and left motors are synchronized by a circuit board. Schwintek slideouts are typically used on both towables and motor homes.
  • Page 71 Section 5: Slideout Systems This slideout system requires very little maintenance. It contains a pre-lubed bearing that is lubricated when the room is moved in and out. Do not spray oil or grease on the rails while the room is extended. Trouble shooting the in-wall slideout system Checking Fuses: The in-wall slide requires a minimum 30-amp fuse.
  • Page 72 Section 5: Slideout Systems The red and green LED’s will flash indicating you are in override mode. Release the mode button. Using either a wall or command center panel switch, press and hold the switch toward the word IN or RETRACT until the unit comes in completely. This will allow you to get the recreation vehicle to a service center to have the slideout malfunction diagnosed.
  • Page 73 Section 5: Slideout Systems Physically push/ pull the room back into the opening; keep both sides relatively even. The room must be travel locked to keep the room in place for road travel.  DO NOT MOVE THE RV UNLESS THE MOTORS ARE PLUGGED IN TO THE CONTROLLER AND THERE IS BATTERY POWER TO THE RV.
  • Page 74 Section 5: Slideout Systems Norco Slideout Manual Operation Locate the included flexible shaft in your own- er’s packet. Attach flexible shaft to the 1/4” hex fitting on the end of the motor. Attach 1/4” socket & ratchet, or drill to the other end, and turn in the proper direction to move the room.
  • Page 75 Section 5: Slideout Systems  When the motor brake is disengaged the slideout room WILL NOT lock into place and will not be sealed. When the room has been manually retracted, be sure to install transit bars (if so equipped) and return the motor brake lever to its normal engaged position in order to seal and lock the room into position.
  • Page 76 Section 5: Slideout Systems 10. Install the transit bars (if so equipped) to the slideout room and take the unit to an authorized dealer for service. Refer to the Power Gear® Electric Slideout Operation Manual for detailed operation, safety and troubleshooting information. Power Gear Slim Rack Slideout System The Power Gear®...
  • Page 77 Section 5: Slideout Systems or the IN button when fully retracted, and stops moving. Turn OFF the on/off switch or key. Fault Diagnostics / Troubleshooting:
The control has the ability to detect and display sev- eral faults. When a fault is detected, room movement stops and two different LEDs will flash in a pattern.
  • Page 78 Section 5: Slideout Systems Preventative Maintenance: The Power Gear® slideout system requires very little maintenance. Read and follow these procedures: When the room is extended, visually inspect the slide rail assemblies. Check for excess buildup of dirt or foreign material; remove any debris that may be present. If the system squeaks or makes any noises, blow out any debris from the gear rack arms and apply a dry lubricant to prevent and/or stop squeaking.
  • Page 79 Section 5: Slideout Systems Press the IN button on the front of the wall touchpad until the room is fully retracted. If one side of the room needs to retract further in order to get a good seal, press and hold the motor button (Fig 3) corresponding to ONLY the motor you want to move.
  • Page 80 Section 5: Slideout Systems Power Gear Ram Slideout System Typically used for Class C motorhomes. Manual Override Procedure: The system has been equipped with 3/4” hex override couplers located on the drive compo- nent of the system. Due to the size and weight of some rooms, assistance may be needed to push the room in.
  • Page 81 Section 5: Slideout Systems you figure out how this works. The side-by-side photo (below) shows the spring lock lever and the brake lever. The spring lock lever is a thin metal arm with a slight bend at the end, which will hold the brake lever in the released position.
  • Page 82 Section 5: Slideout Systems Maintenance Record Table of Contents...

  • Page 83: Section 6: Electrical System

    Section 6: Electrical System The Electrical System The RV electrical system is comprised of two independent electrical systems. One operates off of 12-volt DC power and the other off of 120-volt 60hz AC power. All installations have been made in compliance with industry standards applicable on the date of manufacture. Because the electrical equipment and associated circuitry are engineered into a dedicated system specific to your RV, do not make unauthorized changes or add fixed appliances to it.

  • Page 84: Command Center

    Section 6: Electrical System Command Center The command center is typically located inside the entrance door or in the living area of the RV, and contains switches and controls for various electrical functions. Command center applications, con- figurations and components will vary by model. Command Center Panel or Command Center Panel with Switch Modules Items found on these panels may include:...

  • Page 85: Gfci Receptacle

    Section 6: Electrical System GFCI Receptacle There is a ground fault current interrupter (GFCI) engineered into the electrical system. It is designed to reduce the possible injury caused by electric shock. The GFCI will not protect against short circuits or circuit overloads. Test all GFCI receptacles monthly: Push in the GFCI “TEST”...
  • Page 86 Section 6: Electrical System To use the system, select My RV Control Panel (Fig 3) from the menu. This opens the screen showing all the items that can be operated from the touchscreens, or the handheld remote. The device selection screen (Fig 4) has icons depicting the different systems in your RV that can be controlled from the various control devices.
  • Page 87 Section 6: Electrical System Monitor Panel Operation Select the MONITOR PANEL icon (Fig 10), the screen opens containing graphic representations of all tank levels in your RV (fresh, black and gray water tanks) along with the current battery status. There are additional buttons to turn on the electric or gas water heater, the water pump and the water tank heater (if so equipped;...

  • Page 88: Testing The Campsite Power Connection

    Section 6: Electrical System If the Master Light switch is selected, all the lights controlled with the tablet will turn ON. Light switches may have to be toggled twice for them to operate as this system is multi- plexed with the command center panel and other wireless controllers in the RV. Accent Lights: Both the upper accent (LED) lights above each slideout, and the lower accent (LED) lights at the bottom of the kitchen island, and in the bathroom and bedroom cabinetry, can be controlled by the touchscreens, hand-...
  • Page 89 Section 6: Electrical System  Do not hook up the power cord to any receptacle until you have verified proper polarity and grounding. DO NOT plug the shore power cord into a campsite receptacle(s): That has reverse polarity With non-functioning ground circuits That shows outward signs of heat damage.
  • Page 90 Section 6: Electrical System The shore line power cord should be unplugged when the recreation vehicle is left unattended. If something would happen to the electrical system, this may help limit potential damage. When you are ready to leave, reverse the power cord connection process. Use care to pre- vent damaging the power cord electrical connection pins when connecting or disconnecting the shore line power cord.

  • Page 91: Power Converter

    Section 6: Electrical System • STATUS & DISPLAY LEDS - both AMBER - Inverter Mode is active. Inverter is ON, pressing the SELECT button will display inverter power output. Display shows power output in KW. • STATUS LED FLASHES AMBER, DISPLAY LED IS OFF - If the unit is in Inverter Mode, and you plug in shore power, the STATUS LED will begin flashing AMBER and the unit will switch to Bypass Mode within 20 seconds of detecting an AC input.
  • Page 92 Section 6: Electrical System If your lights are dimming or flickering that usually indicates an overloaded con- verter. Remove some of the load by turning off DC lights or appliances. Fan is controlled by load. It will begin running at 3 to 6 amp DC draw. It increases in speed with a higher load until 14 to 15 amps.

  • Page 93: Volt Dc System

    Section 6: Electrical System Converter with Charge Wizard (if so equipped) Some converters may be equipped with a charge wiz- ard. There are (3) possible charging modes; NORMAL, BOOST and STORAGE. The charge wizard will auto- matically select the best mode to charge your battery. A green LED next to the wizard mode button will indicate by flashes, which mode is currently being used.

  • Page 94: Auxiliary Battery (Customer Supplied)

    Section 6: Electrical System Replacing A Fuse Before replacing a fuse, always turn off the electrical components protected by it. Disconnect the shore power cord. Turn “off” the inverter (if so equipped). Disconnect the house or auxiliary batteries main negative battery cable. Remove the fuse panel cover to check fuses.
  • Page 95 Section 6: Electrical System Dry Camping The auxiliary battery should be fully charged prior to dry camping. If the auxiliary battery is not being recharged and power is being drawn from it, it will eventually discharge. A battery will discharge at a faster rate as its energy level becomes depleted. Plan your electrical us- age accordingly.

  • Page 96: Load Center

    Section 6: Electrical System Rotating Dial Disconnect Switch When this switch is ON, there will be a green area showing a “1” along the top of the switch. To turn the switch OFF, turn it counter-clockwise until you see the red area along the left side of the switch showing a “0”...
  • Page 97 Section 6: Electrical System NOTE: Load Centers may not always include a main circuit breaker.  Circuit breakers and fuses will not offer complete protection of the electrical system in the event of power surge or voltage spike. Replacement Only replace circuit breakers with those of the same specified type, voltage, and current rat- ing.

  • Page 98: Approximate Electrical Load Ratings

    Section 6: Electrical System Approximate Electrical Load Ratings 12 VOLT SYSTEM Exterior Entertainment Center 5-7 AMPS 1.5 AMPS Furnace 12.0 AMPS Generator Start 95.0 AMPS* Illuminated Switch .125 AMP Inverter variable Leveling System 95.0 AMPS* LP Detector .125 AMP Light; Halogen 1.7 AMPS Light;...

  • Page 99: Volt (50 Amp) Ac System (If So Equipped)

    Section 6: Electrical System 120-Volt (50 AMP) AC System (if so equipped) The 50 amp 120-volt 60hz AC electrical system can be powered by an outside 120/240-volt 60hz utility service like those commonly found in campgrounds or by 120/240-volt 60hz generator power.
  • Page 100 Section 6: Electrical System The shore power cord is designed to continuously carry the 50-amp current flow required to power each leg of the electrical system. It also creates a critical ground connection between the vehicle electrical system and the campground shore power receptacle. Always test the external power source (i.e., the campsite power receptacle or electrical box) with a ground monitor before connecting your power cord to it.
  • Page 101 Section 6: Electrical System  CARBON MONOXIDE IS DEADLY! Do not run the generator when your motor home is indoors or in a confined space. Asphyxiation or carbon monoxide poisoning hazards exist whenever generator exhaust gasses can ac- cumulate. MOVING PARTS AND ELECTRICITY can cause severe personal injury or death.

  • Page 102: Solar Prep (If So Equipped)

    Section 6: Electrical System Exercising Your Generator – It is important to run your generator regularly, to keep every- thing in good working order and to avoid fuel varnishing, which can affect performance, if the generator is stored for an extended time. Lack of exercise can cause moisture build-up and fuel system degradation that make it run poorly.

  • Page 103: Exhaust Gas Fumes

    Section 7: Fuel & Propane System Exhaust Gas Fumes  Avoid inhaling exhaust gases as they contain carbon monoxide, which is a potentially toxic gas that is colorless and odorless. If you are in a recreation vehicle with either a nearby tow vehicle engine running or the generator (if so equipped) running there is a potential for exhaust fumes to filter back into the recreation vehicle To avoid breathing exhaust gases, follow these precautions:...
  • Page 104 Section 7: Fuel & Propane System recommended. Hand tighten the LP gas system valves only, do not use a wrench or pliers as over tightening may damage the valve seals and cause them to leak. NOTE: All propane lines have been checked with air pressure at the time of manufacture.
  • Page 105 Section 7: Fuel & Propane System Be sure to securely re-install DOT cylinder(s) after they have been removed for filling or replacement. Always close the service valve and install a dust cap or plug when transporting or storing disconnected containers whether full or empty. ASME tanks are permanently mounted to the RV and are commonly used on RV motor homes.
  • Page 106 Section 7: Fuel & Propane System The position of the propane container(s) and the hoses are critical to proper operation and propane flow. Follow these instructions to make sure your propane container(s) are con- nected properly. LP Gas Container Overfill Never allow your propane tank to be filled above the maximum safe level as indicated by the fixed liquid level gauge.

  • Page 107: Propane Use And Safety

    Section 7: Fuel & Propane System counter-clockwise to tighten. The P.O.L. fitting has been designed to help restrict the flow of LP gas in the event of a regulator failure or hose malfunction. Propane Regulator  Propane regulators must always be installed with the regulator vent facing downward.
  • Page 108 Section 7: Fuel & Propane System Propane Leak Test Leaks may be found easily with a soapy water solution. Do not use a solution containing ammonia or chlorine when locating leaks. These products are corrosive to copper gas lines and brass fittings, which could result in deterioration of the copper and brass components. Apply the soapy solution to the outside of the gas piping fittings.
  • Page 109 Section 7: Fuel & Propane System Unlike homes, the amount of oxygen supply is limited due to the size of the recreation vehi- cle. Proper ventilation when using the cooking appliance(s) will help you avoid the danger of asphyxiation. It is especially important that cooking appliances not be used for comfort heating, as the danger of asphyxiation is greater when the appliance is used for long periods...

  • Page 110: Installing Propane Cylinder(S)

    Section 7: Fuel & Propane System Traveling With Propane NOTE: Some states prohibit propane appliances to be operated during travel, especially in underground tunnels. Make sure you know the laws for the areas where you travel. Use care when fueling your motor fuel tanks and/or propane containers.
  • Page 111 Section 7: Fuel & Propane System Place the second cylinder on the A-frame bracket so the cylinder valve is pointed to the roadside of the recreation vehicle. Secure the second cylinder to the A-frame using the bolts, nuts and washers provided. Attach the second 24”...
  • Page 112 Section 7: Fuel & Propane System Maintenance Record Table of Contents...

  • Page 113: Plumbing System

    Section 8: Plumbing System Plumbing System There are two different water systems in your recreation vehicle: The fresh water system consists of the fresh water holding tank, faucets and con- nections, water pump, outside shower assembly (if so equipped), water heater, tub/ shower, and water purification system (if so equipped).
  • Page 114 Section 8: Plumbing System Operation Press only one tact switch at a time. As you push ei- ther the FRESH, BLK GREY1 or GREY2 switch, one or more LED lights will illuminate (from left to right) indicating the content level for that tank. When push- ing the “BATT”...

  • Page 115: Fresh Water System

    Section 8: Plumbing System Fresh Water System All water contains contaminant and mineral particles that can cause fresh water system odors. Untreated well water is a major source of water system odors. The fresh water (po- table water) system needs periodic sanitization and winterization to take care of all the com- ponents in the plumbing system to discourage the growth of bacteria and other organisms that can contaminate the water supply.

  • Page 116: Water Purification System (If So Equipped)

    Section 8: Plumbing System Water Pump Switch (if so equipped): Most water pump switches illuminate when the water pump is activated. In most models, the (red) pump switch is located on the monitor panel or the utility center. When the water pump switch is ON the pump runs until 45 lbs.

  • Page 117: Draining The Fresh Water System

    Section 8: Plumbing System NOTE: There is no bypass feature on a canister style water filter. The water filter must be removed before sanitizing or winter- izing the RV. Each new recreational vehicle is winterized with RV antifreeze before it is shipped to the dealer.
  • Page 118 Section 8: Plumbing System Drain the sink by removing the drain cap. Turn ON the water pump and allow it to run as needed. If the RV water heater has bypass valves: Set them to the BYPASS configuration (refer to the Water Heater Bypass section). Operate the toilet flush lever until water stops flowing.
  • Page 119 Section 8: Plumbing System Uni-Dock Utility Center (if so equipped) The Uni-Doc Utility Center is located in an exterior compartment and allows you to per- form the following functions: Power fill the fresh water tank for remote or dry camping Use the pump to supply water to fixtures from the fresh water tank Use the pump to siphon fill or sanitize the fresh water tank from a bucket Connect to city water at the camp site to supply water to RV fixtures...
  • Page 120 Section 8: Plumbing System Nautilus - 5 Valve Position and Routing Information: White Handle: Receives water from water inlet on the front panel. Sideways: Water goes to pump inlet. Downward: Water goes into the blue handled diverter. Blue Handle: Receives water from the white handle valve/water inlet on thefront panel. Sideways: Water goes to or comes from the fresh water tank.
  • Page 121 Section 8: Plumbing System "SANITIZE” (or Siphon Fill) the Fresh Water Tank via Pump NOTE: Refer to the Sanitizing Plumbing System section before starting this process. Connect a garden hose to the city water inlet (do not use your fresh water hose to sani- tize the water lines or the tank).
  • Page 122 Section 8: Plumbing System “CITY WATER” (Pressurized fresh water source) Connect the fresh water hose to the city water inlet. Set the color coded valves to the CITY WATER setting: (A) White handle pointing right (B) Blue handle pointing down (C) Black handle pointing right (D) Red handle pointing up (E) Green handle pointing up...
  • Page 123 Section 8: Plumbing System Sanitizing the Plumbing System When to sanitize When your RV is new. At the beginning and end of each season. When the water system becomes contaminated or every three months of use. How to Sanitize Turn water heater power OFF. Both switches (electric &...
  • Page 124 Section 8: Plumbing System ter heater should be OFF (both switches: electric & LP gas), Set the valves to the DRY CAMPING setting. Turn the pump ON and sanitized water will flow into the water lines from the tank. 11. Open all hot water faucets one by one until water begins to flow continuously and a chlorine smell is noticeable.
  • Page 125 Section 8: Plumbing System Refill the fresh water tank with fresh water again and when water heater is full of water, turn the water heater power ON. Refer to Step 13 for instructions on refilling the fresh water tank. Lingering Chlorine Taste: If a chlorine taste lingers in the water, flush the water system with a solution consisting of one-quart vinegar to five gallons of clean water.
  • Page 126 Section 8: Plumbing System Close low point drains and fresh water tank drain. Refill the fresh water tank with clean potable water. Use the city water fill connection inlet, and one of the two methods explained in Step 3. Open faucets and check that the chlorine taste is gone. 10.
  • Page 127 Section 8: Plumbing System  If the recreation vehicle is going to be stored in a non-temperature controlled environment with a risk of temperatures reaching 32°F (0°C) or lower, the air pressure method is not adequate, winterizing with RV antifreeze must be used in the plumbing system.
  • Page 128 Section 8: Plumbing System Red, Blue, Green & White Valves must be set to 45° before applying air pressure 30 PSI Max. (Fig 2). There is no drain plug. Water filter should be removed for winterizing. See Water Purification System section. Your RV may have one of two types of filters: Full System Canister Filter: On full system canister water filters remove the canister, take out the filter, and re-attach the empty canister.
  • Page 129 Section 8: Plumbing System Close the black tank drain gate valve. Winterize with Antifreeze Method: Requires non-toxic RV antifreeze in the water lines and does not require any special tools. Use ONLY RV ANTIFREEZE in your fresh water system for freeze protection. No other product or commodity should be used.
  • Page 130 Section 8: Plumbing System When you are finished adding RV antifreeze: 12. Turn only the BLUE, GREEN, and WHITE valve handles so they are at a 45° angle for 10 seconds(Fig 3). The pump should still be ON. 13. Turn the water pump OFF with the switch on the utility cen- ter panel.

  • Page 131: Water Heater

    Section 8: Plumbing System Water Heater  Hydrogen gas may result if you have not used the water heater for two weeks or more. HYDROGEN GAS IS EXTREMELY FLAMMA- BLE. To reduce the risk of injury under these conditions, open the hot water faucet for several minutes at the kitchen sink before you use any electrical appliance connected to the hot water system.
  • Page 132 Section 8: Plumbing System NOTE: Each ignition cycle will have a 15 second purge before spark cycle if the system is a three try system. If lock-out occurs before the main burner lights, turn the water heater control switch to OFF, wait five seconds and turn the switch to the ON position. This will restart the ignition cycle.
  • Page 133 Section 8: Plumbing System To prevent a water leak when replacing the anode rod, a pipe thread sealant approved for potable water (such as Teflon tape) must be applied to the threads of the anode rod. Proper application of a thread sealant will not interfere with the anode’s function. High altitude deration Operation of the water heater at high altitudes may require derating.
  • Page 134 Section 8: Plumbing System Periodically, inspect the water heater vent for soot. Soot is a sign of incomplete combustion and must be corrected before operating the water heater. This is your visual warning that the water heater is operating in an unsafe manner. If soot is present, immediately shut the unit down and contact your dealer or a qualified service agency.
  • Page 135 Section 8: Plumbing System To reduce temperature: ○ Turn GMC dial “counter-clockwise”. ○ Increase hot water flow. ○ Gradually add cold water. To increase temperature: ○ Turn GMC dial “clockwise”. NOTE: Use caution not to increase the dial too much which could cause the hot water temperature to rise to the point the water heater “limits’...
  • Page 136 Section 8: Plumbing System  Before operating the macerator pump, make sure the external dump hose is properly attached at the RV and at the dump station. The hose is under pres- sure and therefore waste is discharged under pressure. Failure to follow in- structions can lead to possible injury or property damage.

  • Page 137: Black Tank Flush (If So Equipped)

    Section 8: Plumbing System NOTE: The bypass valve also doubles as an emergency cutoff in the event of a problem with the flex hose or dump connector. Closing the valve stops waste flow out of the macerator pump and up to the flex hose, but will divert waste to the main dump connector under the RV.

  • Page 138: Tank Heaters (If So Equipped)

    Section 8: Plumbing System Dump the black water tank (see Gray Tank Drain & Black Tank Drain) and leave the black tank drain valve open. Connect a garden hose from the water supply source to the black tank flush. With the water source turned ON, flush the black water holding tank until the water running out of the black tank drain valve is clear (not discolored or cloudy).

  • Page 139: Outside Shower (If So Equipped)

    Section 8: Plumbing System The tank heater switch should be turned OFF: When there is NO liquid present (tanks are empty). When dumping the black and gray holding tanks and the drain pipes. When fresh water tank and supply lines are empty or being drained for storage. When the recreation vehicle is connected to city sewer and the gate valves are open.

  • Page 140: Bathroom Tub / Shower

    Section 8: Plumbing System Bathroom Tub / Shower Keep the water heater and holding tank capacities in mind when using the fresh water sys- tem. The used water will drain through the plumbing pipes into the grey water holding tank. Be sure the water heater is ON and had sufficient time to heat the water.
  • Page 141 Section 8: Plumbing System ternal seal that may potentially allow sewer gases to escape into the RV interior. The water- less trap can be unscrewed from the water lines. A label has been placed near the location of the waste valve that reads as follows: REMOVE WATERLESS TRAP BEFORE USING MECHANICAL DRAIN CLEANING DEVICES Sewer Hose Storage:...
  • Page 142 Section 8: Plumbing System  Never leave the black tank drain in the open position continuously when connected to the campground sewer system. Leaving the drain open will allow the liquid to drain out increasing the potential for a blockage in the tank.
  • Page 143 Section 8: Plumbing System Release one to two quarts (1 or 2 liters) of water into the toilet bowl. Follow the directions on your (RV approved) toilet chemical bottle (customer sup- plied), by placing the recommended quantity of holding tank chemical into the toilet bowl.
  • Page 144 Section 8: Plumbing System Cleaning and maintenance The toilet should be cleaned regularly for maximum sanitation and operational efficiency. For detailed information refer to the manufacturer’s operator manual. Maintenance Record Table of Contents...

  • Page 145: Section 9: Heating & Cooling

    Section 9: Heating & Cooling Air Conditioner The air conditioning system is controlled by a thermostat. Cooled air enters the RV through the grill. Make sure you have sufficient power available before operating the air conditioner. Do not operate the air conditioner without the return air filter. Operating the system without the filter allows the lint and dirt that is normally stopped by the filter to accumulate on the cooling coil of the air conditioner.

  • Page 146: Ceiling Fan (If So Equipped)

    Section 9: Heating & Cooling Ceiling Fan (if so equipped)  Be careful to avoid placing any object in the path of the ceiling fan blades! Turn the ceiling fan ON/OFF using an interior wall switch. The 3-speed ceiling fan is controlled by the pull chain switch.

  • Page 147: Fireplace (If So Equipped)

    Section 9: Heating & Cooling Furnace The furnace installed in your recreation vehicle is controlled by a 12-volt DC thermostat. Depending on your model, there may be up to two thermostats enabling you to control the temperature to your comfort level. The furnace requires both 12-volt power and propane gas for full operation.
  • Page 148 Section 9: Heating & Cooling Maintenance Record Table of Contents...

  • Page 149: Section 10: Appliances

    Section 10: Appliances Microwave  To prevent damage, remove the turntable from the microwave when trav- eling. Make sure you are connected to a 120-volt power source.  Never use the microwave cavity for storage. The microwave cavity should always be empty when not in use. For details on operation, cleaning and safety information, refer to the manufacturer’s user guide.
  • Page 150 Section 10: Appliances Cooking With Propane (if so equipped) See the Propane System Section for important safety instructions. Refer to the manufactur- er’s owner’s manual for detailed operating and safety instructions for all propane appliances. Cooktops; Range and Oven (if so equipped) For detailed operating and safety information, refer to the manufacturer’s user guide.
  • Page 151 Section 10: Appliances  Do not use aluminum foil on the electric range cooktop, as this material will damage the cooktop surface if it melts. Do not use aluminum foil under any circumstances on the electric range cooktop. Gas Drop-In Cooktops (if so equipped) Depending on your model, it may be equipped with either a 2 burner or 3 burner cooktop.
  • Page 152 Section 10: Appliances Gas BBQ Grill (if so equipped)  Be sure to read, understand and follow all information supplied with your recreation vehicle concerning the use of propane before operating the BBQ grill. The propane hose must be correctly connected before lighting the grill.
  • Page 153 Section 10: Appliances Rail Mount (if so equipped) Hang the grill bracket on the aluminum mount- ing strip located on the side of the recreation vehicle. Open the (2) folding arms on the bracket mak- ing sure they lock in position. Slide the grill onto the (2) arms against the stops.

  • Page 154: Range Hood (If So Equipped)

    Section 10: Appliances Range Hood (if so equipped) If your recreational vehicle is equipped with a range hood, it will be connected to an exterior vent. The vent has an inner flap with two snaps. This flap can be snapped shut when the vehicle is in motion, or during storage to keep in- sects, debris, snow, rain, etc.
  • Page 155 Section 10: Appliances  The ice maker (if so equipped) should be turned off and the ice tray emptied when power to your recreation vehicle has been shut off. With no power, the ice will melt and water may “pool” in the refrigerator door. When power is restored, the vibration may cause this water to run out of the door and on to the vehicle floor.

  • Page 156: Washer/Dryer Prep (If So Equipped)

    Section 10: Appliances If you need to clean the condenser: Remove the base grille. Use a vacuum cleaner with a soft brush to clean the grille, the open areas behind the grille and the front surface area of the condenser. Replace the base grille when finished.
  • Page 157 Section 10: Appliances The central vacuum system installed cleans virtually any surface with no electric cords and has a variety of attachments for many cleaning needs. Make sure you have 120-volt AC power available before operating your central vacuum system (refer to Electrical Systems, calculating electrical load).
  • Page 158 Section 10: Appliances Attaching the “quick coupler” connection The “quick coupler” is directly connected to the RV propane system. The “quick-coupler” connection has a positive shut-off valve as required by code and standards. Place the “quick coupler handle in the OFF position and push back the sleeve.
  • Page 159 Section 10: Appliances  The grill requires proper ventilation. It is designed for RV outdoor use only. NEVER put lava rocks or charcoal or anything else on or under the grate. Grill is designed so it does not require those items. Serious injury or property damage can occur by placing foreign objects on the grate.
  • Page 160 Section 10: Appliances Notes: Maintenance Record Table of Contents...

  • Page 161: Hdtv Antenna/Satellite System(S)

    Section 11: Electronics HDTV Antenna/Satellite System(s) HDTV Antenna (if so equipped) Your recreation vehicle is equipped with an exterior fixed height high definition TV antenna. This antenna rotates 360° and is capable of re- ceiving any over-the-air (OTA) high definition television signals being broadcast in your receiving area.
  • Page 162 Section 11: Electronics Exterior Sliding / Pivoting TV Your recreation vehicle may be equipped with a TV located in an exterior compartment that allows you to slide it in and out of the compartment, along with the ability to pivot and reposition for viewing.

  • Page 163: Cleaning The Interior

    Section 12: Interior Cleaning The Interior To keep the value of your recreation vehicle, perform regular maintenance using the proper materials and procedures. Using the wrong cleaner may result in damage to the surfaces in your vehicle. Check with the manufacturer’s information for the recommended cleaning agent.
  • Page 164 Section 12: Interior Fill a spray bottle with water and a tiny amount of soap. Then spray a lint-free towel with the mixture and use the towel to wipe down each slat. While cleaning, try not to bend the slats. They can also be soaked in a bathtub to loosen up any debris so the slats can be wiped down easily.
  • Page 165 Section 12: Interior NOTE: Oil based soaps and cleaners are not recommended. No abrasive cleaners or alcohol cleansers should be used. If other cleaner solutions are used, we recommend trying a spot in an incon- spicuous area. ABS Plastics Dust and wipe clean with soft, damp cloth or chamois, wiping gently. Do not use gritty or abrasive particle soaps or scouring compound to clean ABS plastic.
  • Page 166 Section 12: Interior Cube Sofa The Cube Sofa functions similar to a residential futon. The slanted back pillows offer nu- merous options as a sofa, along with the ability to extend the cushions for additional sleeping space. Booth Dinette (if so equipped) The dinette is designed to seat up to four adults.

  • Page 167: Pantry Or Hutch (If So Equipped)

    Section 12: Interior Pantry or Hutch (if so equipped) Your recreation vehicle may have a pantry or hutch that you can use for storage. Make sure all items stored in the pantry or hutch are secured to prevent shifting during travel. This cabinetry has been designed to accommodate the normal camping items which may be bulky but not necessarily heavy.

  • Page 168: Bed Storage

    Section 12: Interior Solid surface sink maintenance Occasionally, clean the solid surface sink by filling one-quarter full with a 50/50 water/ bleach solution. Let soak for 15 minutes, and then wash sides and bottom of sink as solution drains. Run cold water when pouring hot/boiling water into the sink. Flooring Always test a cleaning agent in an inconspicuous area for colorfastness.
  • Page 169 Section 12: Interior Loft Sleeping Area (if so equipped) Your RV may be equipped with a loft sleeping area. Access to the loft sleeping area is through the use of a (wood or steel) ladder. The steel ladder is equipped with hooks that fit over the side board of the loft bed. Typically the wood ladder is attached to a closet door (or wall) and pivots out for use (A &...
  • Page 170 Section 12: Interior NOTE: Some types of bunk beds will not include a ladder.  Exercise extreme care when entering or exiting the bunk beds and using the ladder (if so equipped). Do not allow more than one person on the top bunk. Do not allow children under 6 years of age to use the upper bunk.

  • Page 171: Cleaning The Exterior

    Section 13: Exterior Cleaning the Exterior To protect your recreation vehicle’s exterior finish, wash it often and thoroughly. For recreation vehicles with painted exterior graphics: If desired you may wash and wax your vehicle 60 days after purchase. The exterior paint does need time to cure before any wax is applied to the exterior surface.
  • Page 172 Section 13: Exterior Drying the recreation vehicle is just as important as washing your vehicle. Tap and well water contain many chemicals that could water stain your vehicle’s finish. We suggest using a damp natural or synthetic chamois. There are other drying products such as lint-free micro-fiber towels that work just as well.

  • Page 173: E-Z Lube Or Super-Lube Axle (If So Equipped)

    Section 13: Exterior ing to the damaged surface only; polish a somewhat wider area, moving the polishing cloth in one direction. After polishing, flush the compound from the surface and apply a coat of wax to regain a beautiful luster. Damaged paint To prevent corrosion, touch up small cracks and scratches in the paint coat as soon as pos- sible with touch-up film or paint.

  • Page 174: Exterior Ladder (If So Equipped)

    Section 13: Exterior Exterior Roof and Sidewall Vents Inspect the roof vents (including sealants) for cracks and keep them clean. Inspect the re- frigerator and holding tank vents for blockages from bird nests, spider webs, leaves, etc. All exterior access doors and vents need to be kept clean and free of obstructions (i.e., insect nests, mud daubers, etc.) while the appliances are in use.
  • Page 175 Section 13: Exterior  LADDER CAPACITY MAXIMUM 300 lbs (136 kg) DO NOT exceed the ladder maximum weight rating. The maximum rating includes the person’s weight PLUS weight of items carried. When climbing: • Always face the ladder. • Climb slowly with weight centered between side rails. •...
  • Page 176 Section 13: Exterior If you notice water inside the recreation vehicle, immediately have the dealer check for the source of the leak. Failure to correct the leak may result in serious damage to your recreation vehicle; this damage may not be warrantable. Although the following diagrams may not accurately reflect the exact model of your recre- ation vehicle, make sure you inspect all sealants as indicated in the text.

  • Page 177: Section 14: Travel/Camping/Storage Checklists

    Section 14: Travel/Camping/Storage Checklists Travel Checklist Following is a preliminary list of items that need to be checked before leaving your home or campsite. This is a general list, which you may want to customize as you determine your own needs. Safety Make sure you follow all safety precautions noted in this owner’s manual and in any manufacturer’s operators manual when preparing to travel.
  • Page 178 Section 14: Travel/Camping/Storage Checklists Before leaving the campsite Check the area under the RV after overnight parking and look for water or other fluid leaks. If leaks are detected, find the cause and correct it immediately. Turn off propane tanks. Empty black and gray holding tanks, rinse as needed (if so equipped).
  • Page 179 Section 14: Travel/Camping/Storage Checklists Close the propane cylinder valve(s). We recommend using a propane cylinder cover, and to make sure the propane regulator is covered. If is equipped with a gas/ electric DSI range, light a range gas burner to consume any gas remaining in the lines.
  • Page 180 Section 14: Travel/Camping/Storage Checklists Notes: Maintenance Record Table of Contents...

  • Page 181: Section 15: Additional Information

    Your recreation vehicle may be equipped with some of the items listed below. This is a partial listing and it is not intended to cover all components. All information is the latest available at the time of publication. Jayco reserves the right to change any of the following information without notice.
  • Page 182 Section 15: Additional Information Thermostat Coleman Mach www.airxcel.com/coleman-mach Toilet Thetford Corp. www.thetford.com See manufacturers’ user guide Winegard Company www.winegard.com TV Antenna King Jack www.kingconnect.com Water Heater, Tank DSI Atwood Greenbrier www.atwoodmobile.com Girard Systems www.greenrvproducts.com Water Heater, Tankless Truma AquaGo www.truma.com Shurflo East www.shurflo.com Water Pump, 12V...

  • Page 183: Vehicle Maintenance Record

    Section 15: Additional Information Vehicle Maintenance Record Make: Model: Model Year: Vehicle Serial#: Service Performed Mileage Work Performed Notes Date Maintenance Record Table of Contents...
