This manual is based on firmware version:
2.0.00-2370
If you have an older or newer firmware version some of the
functions mentioned in this manual may not be present or may
operate differently.
Flanders Scientific, Inc.
6215 Shiloh Crossing
Suite G
Alpharetta, GA. 30005
Phone: +1.678.835.4934
Fax: +1.678.804.1882
E-Mail:
Support@FlandersScientific.com
www.FlandersScientific.com
Monitor User Manual
Updated 5.5.2023
DM Series
DM160
DM170
DM211
DM220
DM231
DM240
DM241
DM250
DM420
DM550

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DM160 and is the answer not in the manual?

Questions and answers

Related Manuals for FSI DM160

Summary of Contents for FSI DM160

  • Page 1 Monitor User Manual Updated 5.5.2023 DM Series DM160 DM170 DM211 DM220 DM231 DM240 DM241 DM250 DM420 DM550 This manual is based on firmware version: 2.0.00-2370 If you have an older or newer firmware version some of the functions mentioned in this manual may not be present or may operate differently.

  • Page 2: Table Of Contents

    Contents TOPIC PAGE(S) Safety Precautions Parts & Their Functions Menu Navigation / System Status Function Menu 9-22 Real Time Scopes Menu Scopes & Audio Meters Menu 24-26 Video Menu 27-29 Audio Menu Marker Menu Alarm Menu 32-33 OSD Menu GPI Menu Color Management Menu 36-44 Color Management Menu - HDR Preview...

  • Page 3: Safety Precautions

    Safety Precautions Connecting and Disconnecting SDI BNC Cables To prevent damage to components from electrical discharge follow these steps: • Connect power first on all devices. • Power on all devices. • Connect BNC cables. To disconnect: • Disconnect BNC cables. •...
  • Page 4 Safety Precautions • If the product requires replacement parts, make sure that the service person uses replacement parts specified by the manufacturer, or those equivalent parts having the same characteristics and performance specifications as the original parts. Use of unauthorized parts can result in fire, electric shock, and/or other damage.
  • Page 5 Safety Precautions FCC (Federal Communications Commission) This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interface when the equipment is operated in a commercial environment.

  • Page 6: Parts & Their Functions

    Parts & Their Functions Keyboard • SDI 1: Used to select SDI Input 1 as the active Input. • SDI 2: Used to select SDI Input 2 as the active Input. • DP: Used to select the Display Port Input as the active Input. •...
  • Page 7 Parts & Their Functions Back Panel • LAN: IP Control via select programs including the FSI IP Remote Utility and Pomfort’s LiveGrade Pro. • GPI: General Purpose Interface for Contact Closure Remote Control. Remote Control Functions can be assigned from the GPI Menu.

  • Page 8: Menu Navigation / System Status

    Menu Navigation & System Status Main Menu Pressing the MENU button on the monitor’s keypad will call up the On Screen Menu. Main Menu Function Function Scopes & Audio Meters 1 Real Time Scopes Scopes & Audio Meters 2 Scopes & Audio Meters Scopes &...

  • Page 9: Function Menu

    Function Menu Main Menu Function NOTE: Many features (Waveform, Function Realtime Scopes Vector Scope, Audio Level Real Time Scopes Scopes & Audio Meters 2 Meters, etc.) require a function Scopes & Audio Meters Scopes & Audio Meters 3 key in order to operate.
  • Page 10 Function Menu - Real Time Scopes Real Time Scopes (Firmware release 1.1.04-2194) Real Time Waveform and Vectorscope that update every frame. Scope position, background, size, and scale can be adjusted independently using the rotary knobs on the face of the monitor or configured from the Real Time Scopes menu. Real Time Scopes work in all processing modes including Zero Delay Fast Mode.
  • Page 11 Function Menu Scopes & Audio Meters 1, 2, 3 In addition to Real Time Scopes a wide variety of additional scopes and meters are available. Note that Real Time Scopes are detected as active video on these scopes. These scopes and meters update approximately every 2 to 3 frames and work in both Normal and Noise Reduction processing modes on DM series monitors.
  • Page 12 Function Menu Rec. Status Tally This function is designed for use with cameras that output Start/Stop Record flags in the ancillary data of their serial digital output. To activate this function set Rec. Status Tally to a function button and press that function button once. While active the monitor’s red tally light will turn on when the Start Record SDI flag is detected and will turn the red tally light off when the Stop Record SDI flag is detected.
  • Page 13 Function Menu Details on Overscan Function With the overscan function off all active lines of video can be displayed on screen. With overscan on a small percentage of the outermost active video will not be displayed. Additionally, the monitor can scale the overscanned video full screen or ‘blackout’...
  • Page 14 Function Menu Sub Window Largely deprecated. For side by side viewing please use the dedicated PAP function instead. The Sub Window function enables a still picture by live picture mode. After assigning the Sub Window function to a function key the first key press will result in a picture by picture display of your active input.
  • Page 15 Function Menu Full Screen This function simply stretches any incoming source to fill the entire screen. Unlike the Zoom feature this full screen stretch does not preserve aspect ratio, but it does keep all of the active video signal present. Though the full screen mode has many potential uses it was designed primarily for use with rasterizers that generate a 16:10 or 16:9 aspect 1024x768 output.
  • Page 16 Function Menu Measurement (10bit & 8bit) This function allows you to get precise real time YRGB measurements of any point or area within your incoming signal. With the Measurement function on you can use the H POS and V POS rotary knobs to position your cross-hair over the point within your source that you would like to measure.
  • Page 17 Function Menu Video Data The Video Data function is a sophisticated signal data analyzer providing realtime decimal or hexadecimal readout of video data at the pixel level. Data is represented in a 18 x 10 pixel grid where each pixel’s corresponding color is used as the background color for that position within the grid.
  • Page 18 Function Menu CIE Measurement This function allows you to get precise real time chromaticity measurements of any point or area within your incoming signal as well as a real time plot of the measured position on a CIE color space diagram. With the CIE Measurement function on you can use the H POS and V POS rotary knobs to position your cross-hair over the point within your source that you would like to measure.
  • Page 19 Function Menu CIE Scope This function maps out full frame signal data on a CIE diagram. Signal levels are mapped out relative to your active color space selection on the Color Management menu. Your active color space selection is represented by a black triangle on the CIE diagram.
  • Page 20 Function Menu 3rd Generation Focus Assist When activated this feature will highlight in focus areas with a trace color. The sensitivity of the focus assist feature can be adjusted using the H POS rotary knob. The weight (transparency) of the focus assist feature can be adjusted using the V POS Rotary knob.
  • Page 21 Function Menu DSLR Zoom (continued) DSLR in 1080i Preview with DSLR Zoom feature Off DSLR in 1080i Preview with DSLR Zoom Feature On DSLR in 480p Record Mode with DSLR Zoom feature off DSLR in 480p Record Mode with DSLR Zoom feature On Safety Broadcast Safety Broadcast is a special monitoring mode designed for Control Room and QC station environments.
  • Page 22 Function Menu AFD (Active Format Description) Activating this function will enable an Active Format Description AFD: 0x0d reader on the monitor that will provide both a text readout of AFD code frame 16:9 data and display corresponding markers on-screen indicating active image 4:3 the portions of the image described by the AFD code.

  • Page 23: Real Time Scopes Menu

    Real Time Scopes Menu Main Menu Real Time Scopes Function Background Black Real Time Scopes Display Window Both Scopes & Audio Meters Lum Win Pos. Bottom Right Video Lum Win Size Audio Vector Win Pos. Bottom Right Marker Vector Win Size Alarm Lum Win Style Color1...

  • Page 24: Scopes & Audio Meters Menu

    Scopes & Audio Meters Menu Main Menu Scopes & Audio Meters NOTE: The Scope & Audio Meters Menu only sets your Function Scopes & Audio Meters Profile 1 Waveform, Vector, & Audio Level Real Time Scopes Window 1 Luminance Meter display preferences. To Scopes &...
  • Page 25 Scopes & Audio Meters Menu Main Menu Scopes & Audio Meters NOTE: The Scope & VU Meters Function Scopes & Audio Meters Profile 1 Menu only sets your Waveform, Real Time Scopes Window 1 Luminance Vector, & Audio Level Meter Scopes &...
  • Page 26 Scopes & Audio Meters Luminance Vector Scope Hue Vector RGB & GBR Parade Color Histogram YCbCr RGB Histogram Column (YRGB Peak) Histogram YCbCr Overlay RGB Overlay Audio Phase Meter Audio Loudness Audio Level Meters Return to Table of Contents © 2023 Flanders Scientific, Inc.

  • Page 27: Video Menu

    SDI Format FSI Monitors are capable of detecting the payload ID contained in an SDI signal. However, some sources or upstream equipment may not generate or pass payload ID. For sources lacking proper Payload ID you may override the SDI Format auto detect function and manually select the appropriate format.
  • Page 28 Video Menu 3G Level B 3D Monitoring Modes In addition to this Line by Line mode all FSI monitors with 3Gbps SDI inputs will have the following diagnostic modes for monitoring 3D signals without glasses: 3D Checkerboard: Checkerboard display of both signals with alternating blocks shown from Link A and Link B of the multiplexed 3Gbps SDI signal.
  • Page 29 Video Menu Fast Mode This selection allows you to set the type of Fast Mode processing that will be used when the Fast Mode function is enabled via an assigned function button. This setting only applies to interlaced video signals. For progressive and PsF video signals there is only 1 type of fast mode processing that will automatically be selected when Fast Mode is enabled so the setting here does not apply in those scenarios.

  • Page 30: Audio Menu

    Audio Menu Main Menu Audio Function SDI 1 Audio Digital CH1&2 Real Time Scopes SDI 2 Audio Digital CH1&2 Scopes & Audio Meters DVI-D Audio Digital CH1&2 Video DP Audio Digital CH1&2 Audio Audio Sync Signal Clock Marker Audio Lockout Alarm Color Management System...

  • Page 31: Marker Menu

    Marker Menu Main Menu Marker Function Marker Select Profile 1 NOTE: The Marker Menu only sets your Real Time Scopes Graticules marker preferences. To toggle the on- Scopes & Audio Meters Graticules Info screen display of your configured marker Video Area Marker assign the Marker function to one of the function keys.

  • Page 32: Alarm Menu

    Alarm Menu Main Menu Alarm NOTE: On-screen Alarms are processing power intensive. Function Alarm When active the monitor may Real Time Scopes Visual Alarm respond more slowly to user Scopes & Audio Meters Remote Alarm Monitoring input via buttons/remote control Video IRE Trigger Level 100 IRE...
  • Page 33 System Status Support Remote Alarm Monitoring When set to ON allows for remote alarm monitoring via FSI’s remote alarm monitoring software. IRE Trigger Level Sets the luminance threshold at which IRE alarms will be triggered, adjustable from 90 to 109 IRE Audio Trigger Time Sets the amount of time with mute audio that should elapse before the mute audio alarm is triggered.

  • Page 34: Osd Menu

    OSD Menu Main Menu Function Status Display Real Time Scopes Menu Position Top Right Scopes & Audio Meters Status Position Top Left Video Rotary Position Bottom Audio Source ID Marker Source ID Position Bottom Alarm Source ID Character CAM1 Time Code Time Code Size Small Color Management...

  • Page 35: Gpi Menu

    (menu locking), which will still allow functions and rotary knobs to work or to fully lock access by disabling the keypad entirely (keyboard locking). To unlock simply disable the GPI toggle remotely or if using the FSI GPI Keypad Lock, sold separately, simply unplug it from the GPI port.

  • Page 36: Color Management Menu

    Color Space DM series monitors are equipped with the FSI CFE3 Color Fidelity Engine and have the ability to work in several different color spaces. Select from available options to instantly change the active color space. Please note that switching color spaces may take several seconds.
  • Page 37 Color Management Menu - Mesopic Optimization Mesopic Optimization Select between DISABLE and ENABLE. When Mesopic Optimization is disabled the AutoCal LUT generation engine will prioritize low dE values during LUT creation. Using traditional evaluation methods you will obtain the best overall measured results, with the lowest dE values, when Mesopic Optimization is set to DISABLE.

  • Page 38: Color Management Menu - Hdr Preview

    Color Management Menu - HDR Preview HDR Preview The ST2084 HDR Preview Modes have been designed to provide an affordable monitoring option for PQ (ST2084) signals. These modes are not a replacement for proper HDR monitoring and all reference level HDR evaluation should be done on a true HDR reference display.
  • Page 39 Color Management Menu - HDR Preview Graphs showing how ST2084-SoftRoll and ST2084-Clip respond are shown below. The black line represents a ST-2084 reference EOTF response with hard clip at 1,000nits. The blue lines represent the various HDR Preview Mode Options. Return to Table of Contents ©...
  • Page 40 Color Management Menu - HDR Preview Expectations and Understanding Limitations: The HDR Preview Modes are incredibly powerful as a very affordable HDR signal monitoring solution, but they do not represent a replacement for reference level HDR displays. Specifically, while the Soft Roll functionality does allow users to continue to see highlight detail present in the signal, something no SDR monitor will be able to do well is mimic the color volume of an HDR display.
  • Page 41 Used when creating custom LUTs. See Appendix A or B or contact FSI Support for more information about LUT creation. Update LUT Used to update LUTs once LUT files have been loaded to the monitor. See Appendix A or B or contact FSI Support for more information about loading LUTs to the monitor.
  • Page 42 Custom Gamma Allows a custom 1D LUT for EOTF / Gamma to be activated. Contact FSI support for assistance with generating and loading custom EOTF LUTs. Up to 3 custom user LUTs for EOTF can be uploaded to the display.

  • Page 43: Color Management - Gaiacolor Autocal

    Valid matrix names are DM160, DM170, DM211, DM220, DM231, DM240, DM241, DM250, DM420, and DM550 3. On DM160, DM170, DM211, DM220, DM231, DM240, DM241, DM420, and DM550 disconnect all signal cables from the monitor if possible. For DM250 please see the optimizing calibration for DM250 topic on the next page of this docu- ment.
  • Page 44 For the DM550, DM420, DM241, DM240, DM231, DM220, DM211,DM170, and DM160 disconnecting cables if possible is a best practice. For the DM250 please see the optimizing calibration for DM250 topic for further considerations.

  • Page 45: System Menu

    System Menu Main Menu System Function Load Profile Real Time Scopes Save Profile Scopes & Audio Meters Update Firmware Video Keypad LED Normal Audio Chroma/Bright/Contrast Unlock Marker Luminance Interval Alarm Language English DHCP IP Address 192.168.001.111 Color Management Subnet Mask 255.255.255.0 System Gateway...
  • Page 46 RS422 Address, Baud Rate, & Parity Set the monitor’s RS422 address for remote control and alarm monitoring. Baud Rate should remain at 9600 and Parity at None unless otherwise specified by FSI Support. Return to Table of Contents © 2023 Flanders Scientific, Inc.

  • Page 47: Troubleshooting Guide

    YCbCr. Image has a heavy green or magenta Set SDI Format to match your signal FSI monitors detect payload ID, if pres- cast over SDI type. This is found at the bottom of the ent, and automatically set the monitor Video Menu.
  • Page 48 Troubleshooting Guide Problem Solution Notes Scopes refreshing slowly Displaying 1 traditional scope window Scope refresh rate is governed by instead of 2 will greatly increase scope available processing power. update speed. Normal update speed with a single scope active is approxi- mately every other frame.

  • Page 49: Appendix A - Dit Luts

    DM series monitors are capable of loading multiple custom DIT / Look LUTs which unlike calibration LUTs do not require you to profile the panel. You can use Lattice, LightSpace, or ColourSpace to convert LUTs to FSI’s format. The LightSpace workflow is shown below.
  • Page 50 As of version 1.9.1, FSI’s IP Remote Utility can also be used to save Look / DIT LUTs to DM series memory over ethernet instead of USB. Formatting must still be in FSI’s .dat LUT format, but unlike USB based LUT loading, the LUT file can be given any name you like as the save-to memory position on the monitor is directly selected from the IPRU and does not rely on file name (e.g.

  • Page 51: Appendix B - Calibration Luts

    FlandersScientific.com. For guidance on profiling a monitor with a third party program that outputs LUTs in a compatible FSI LUT format please see the program specific instructions for the solution you are using. The instructions in this manual will only cover pre-profiling setup and how to load a completed 3D LUT to the monitor.
  • Page 52 Appendix B - Calibration LUTs (DM) Connect the FSI update cable (USB for DM Series) that came with your monitor to an available USB port on your computer and the back of your monitor. After a short time, the computer should recognize the FSI monitor as a mass storage device, viewable in Mac’s Finder or PC’s My Computer.

  • Page 53: Appendix C - Ethernet Connectivity

    IP address or disconnects, try toggling DHCP On and Off to reset the network settings. Remote Control DM Series Monitors can be controlled remotely using FSI’s IP Remote Utility, available free at FlandersScientific.com. From the Manage menu, select “Add Monitor” to add a monitor control tab to your IPRU window.
