Monitor User Manual
Updated 1.04.2021
XM551U
XM650U
XM651U
This manual is based on firmware version 2.1.9
Flanders Scientific, Inc.
6215 Shiloh Crossing
Suite G
Alpharetta, GA. 30005
Phone: +1.678.835.4934
Fax: +1.678.804.1882
E-Mail:
Support@FlandersScientific.com
www.FlandersScientific.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the XM551U and is the answer not in the manual?

Questions and answers

Summary of Contents for FSI XM551U

  • Page 1 Monitor User Manual Updated 1.04.2021 XM551U XM650U XM651U This manual is based on firmware version 2.1.9 Flanders Scientific, Inc. 6215 Shiloh Crossing Suite G Alpharetta, GA. 30005 Phone: +1.678.835.4934 Fax: +1.678.804.1882 E-Mail: Support@FlandersScientific.com www.FlandersScientific.com...
  • Page 2: Table Of Contents

    Contents TOPIC PAGE(S) Safety Precautions 3 - 5 Parts & Their Functions 6 - 7 Menu 8 - 18 Removing Pedestal Feet Dimensional Drawings Return to Table of Contents © 2021 Flanders Scientific, Inc.
  • Page 3: Safety Precautions

    Safety Precautions OLED PANEL BURN-IN WARNING This display has been designed primarily for SDR Mastering / Monitoring applications. HDR monitoring modes are provided as well and may be useful for short term client review of HDR material. However, this display is not suggested for HDR mastering or long term HDR monitoring as prolonged use of these modes can reduce the lifespan of the display as well as have a negative impact on overall display performance.
  • Page 4 Safety Precautions Safety Precautions • All operating instructions must be read and understood before the product is operated. • These safety and operating instructions must be kept in a safe place for future reference. • All warnings on the product and in the instructions must be observed closely. •...
  • Page 5 Safety Precautions • For proper screen maintenance please follow the guidelines below to prevent scratches, discoloration, or other damage to the panel: • Avoid striking the screen with any object. • Do not wipe screen hard. Apply only gentle pressure if cleaning. •...
  • Page 6: Parts & Their Functions

    Parts & Their Functions Keyboard • SDI 1: Used to select SDI Input 1 as the active Input. • SDI 2: Used to select SDI Input 2 as the active Input. • SDI 3: Used to select SDI Input 3 as the active Input. •...
  • Page 7 Parts & Their Functions Back Panel • SDI In: 4 Multi-Format 12G/6G/3G/HD-SDI Inputs. • SDI Out: 4 Looped 12G/6G/3G/HD-SDI Outputs. • MON Out: Processed output. Follows Mode Selection. • DP In: Display Port Input. • Audio In/Out: Analog Stereo Mini-phono Au- dio Input &...
  • Page 8: Menu

    Menu Navigating the Menu Pressing the MENU button on the monitor’s keypad will call up the on screen menu. To navigate use the UP and DOWN buttons and press the ENTER button to select the highlighted sub menu. Navigate the sub menu in the same way by using the UP and DOWN buttons to highlight a particular function and press ENTER to change that function’s settings.
  • Page 9 Menu - Scope Menu Scope Menu Function Luminance Scope Lum Position Bottom Right Video Lum Style Color Vector System Vec Position Bottom Right Lum Coloring Lum & Vec Position Use Lum & Vec Position to select in what area of the screen you would like your Scopes to be displayed. Lum Style Select IRE or HDR (PQ) Waveform.
  • Page 10 Menu - Video Menu Video Menu Function Input SDI 1 Scope Mode AUTO Video SDI Format AUTO Color Pixel Mapping System Deinterlace Mode Mode 2 SDI Format Select the correct incoming signal format. SDI Format selection overrides payload ID if not set to AUTO. Mode The mode selection allows you to set the SDI input configuration as well as the processed monitor output configuration.
  • Page 11 Menu - Video Menu Video Menu Function Input SDI 1 Scope Mode AUTO Video SDI Format AUTO Color Pixel Mapping System Deinterlace Mode Mode 2 Pixel Mapping Pixel Mapping toggles between various available pixel mapping options including: With Pixel Mapping set to OFF the incoming source is scaled to fill as much of the screen as possible while preserving aspect ratio.
  • Page 12 Menu - Video Menu - Pixel Mapping Return to Table of Contents © 2021 Flanders Scientific, Inc.
  • Page 13 Gamma 2.4 Luminance Mode Luminance Custom ColorSystem Default - Default selection where XM551U, XM650U, and XM651U factory calibration LUTs are stored. GaiaColor - Reserved for future Use. LightSpace / CalMAN - Open slots for use with LightSpace and CalMAN. LUT Mode Does not apply to GaiaColor Color System.
  • Page 14 Menu - Color Menu Color Menu Function ColorSystem User Scope LUT Mode Normal Video Range SMPTE Full 4-1019 Color Gamut BT.709 System Temperature Default EOTF Gamma 2.4 Luminance Mode Luminance Custom Gamut Select from available options to instantly change the active color space. This will enable both the 3D Calibration LUT and Post 1D Calibration LUT positions stored to the corresponding memory bank.
  • Page 15 This setting deletes the Factory AWB calibration. Do not use this setting unless you have the proper equipment to redo the factory AWB calibration. Basic settings for the most commonly used configuration on the XM551U, XM650U, and XM651U are provided below: For Rec709 2.4 SDR...
  • Page 16 Panel Dimming Apply Settings Update Firmware When left to Allow (default) allows firmware to be remotely updated using the FSI IP Remote Utility. When set to Block prevents firmware from being remotely updated. Current IP Shows monitor’s current IP address.
  • Page 17 Menu - System Menu System Menu Function Update Firmware Allow Scope Current IP 192.168.1.100 Video Version 2.1.9 Color Serial Number XM310A0000 System Payload ID 0000 Profile Current Profile Set Done Set Static IP 192.168.1.100 192.168.1.100 IP Reset DHCP 255.255.255.0 Clear Panel Noise 192.168.1.1 Panel Dimming Apply Settings...
  • Page 18 Menu - OSD Menu OSD Menu Function Time Code Scope Status Position Top Left Video Status Set Color Menu Position Top Left System Menu Set Area Marker Safety Marker Center Marker Time Code Allows you to select whether to display Time Code on screen pulled from an SDI signal. Reserved for future use, inactive in 1.1.75 Menu &...
  • Page 19: Removing Pedestal Feet

    Removing Pedestal Feet XM551U, XM650U, and XM651U have pedestal style feet that can be removed when wall mounting. The feet are held on by six screws per foot on the bottom. Return to Table of Contents © 2021 Flanders Scientific, Inc.
  • Page 20: Dimensional Drawings

    Dimensional Drawing - XM551U Large Dimensional Drawing PDF available online. http://www.flandersscientific.com/uploads/XM551Udim.pdf Return to Table of Contents © 2021 Flanders Scientific, Inc.
  • Page 21 Dimensional Drawing - XM650U Large Dimensional Drawing PDF available online. http://www.flandersscientific.com/uploads/XM650Udim.pdf Return to Table of Contents © 2021 Flanders Scientific, Inc.
  • Page 22 Dimensional Drawing - XM651U Large Dimensional Drawing PDF available online. http://www.flandersscientific.com/uploads/XM651Udim.pdf Return to Table of Contents © 2021 Flanders Scientific, Inc.
