- Page 1 Tuya Smart Wi-Fi PIR With Direct / Indirect Switching Model WFPIRB - Black Model WFPIRWH - White...
-
Page 2: General Information
1. General Information These instructions should be read carefully and retained for further reference and maintenance. Timeguard reserve the right to alter these instructions Note: at any time. Up to date instructions will always be available for download at www.timeguard.com 2. -
Page 3: Operating Modes
• Contact Type: Normally Open, micro disconnection • PIR Switching Capacity: 1000W Incandescent 500W Fluorescent 250W LED • PIR Detection Range: Up to 12m at a 2.5m mounting height (adjustable) • Dectection Angle: 140˚ (Fixed) 30 seconds - 30 minutes •... -
Page 4: System Requirements
5. System Requirements • Smartphone/Tablet with at least iOS 9.0 or Android 6.0. Minimum software version requirements will be subject to App updates from Tuya Inc. and not Timeguard. • WLAN-enabled router: 2.4GHz (Separate Band) • Tuya Smart App 6. Selecting a location •... -
Page 5: Installation
• Avoid positioning the PIR near any sources of heat in and around the detection area such as extractor fans, tumble dryers or boiler exhausts etc. This would also include other light sources such as secuirty lights. • Reflective surfaces (i.e. pools of water, white painted walls, overhanging branches and other types of foliage) may cause false activation under heightened weather conditions. - Page 6 • Remove the wall plate from the PIR sensor as shown on the diagram. • Using the wall plate as a template mark the position of the fitting holes. Drill the holes. Then, insert the rawl plugs into the holes. •...
-
Page 7: Connection Diagram
8. Connection Diagram Connect the mains supply cable to the terminal block on the back plate as follows (see connection below). Use the earth (loop) ISOLATION SWITCH terminal to join the supply 230V AC and load if required. 50Hz LOAD MAINS L’... - Page 8 9. Commisioning and Operation • Restore the power from the mains supply breaker or isolating switch and test for the correct operation. Walk Test Procedure Important Note: Skip to Section 10, (Pairing Your Device) if you wish to set the lux and timeout parameters via the Tuya Smart app.
- Page 9 PIR Lens PIR Controls Time Delay Dial Lux Dial 10 Min 1000 (Dusk/Dawn/Learn) 5 Min 15 Min 2000 1 Min 30 Min Test TIME RESET Reset Button (Used for pairing and factory reset) Note: the sensitivity of the dials can vary slightly 10.
- Page 10 • Install the App and open it to the registration screen. Click on the ’Register’ button. • Tap ‘Agree’ to accept the privacy policy. • Choose your region by selecting your ‘Country Code’. Enter your email address and phone number and click ‘Get Verification Code’. •...
-
Page 11: Pairing Your Device(S)
• Assign a password (this must be between 6 to 20 characters including letters and digits) and click ‘Done’. The App home page will now appear. 11. Pairing Your Device(s) Note: if you are using a VPN, make sure this is disabled before continuing, and ensure that the 2.4GHz Wi-Fi band is enabled for this device, separate from the 5GHz band. - Page 12 TuyaSmart App may change as it is a 3rd party App Service. Any services that may be removed are the responsibility of TuyaSmart developers and not Timeguard. 13. Offline Control If the device was to lose its Wi-Fi connection to your network, the device will continue to work under the last configured setting applied.
-
Page 13: Control Screen
14. Control Screen Switch: Current ON/OFF Status / Manual Trigger: PIR Trigger Display ON: Motion Detected Override Toggle OFF: No Motion Detected ON : Active Load OFF : Non - Active Load Learn ON: Active / OFF Inactive After the PIR has completed the learn process, the toggle will switch off automatically. -
Page 14: Troubleshooting Guide
15. Troubleshooting Guide Problem Cause/Solution The luminaire does Bulb faulty or missing. not switch on when Nearby light sources causing interference. in the detection Redirect the PIR or light source if possible. area. Smart automation function is not active or set on the app. -
Page 15: Year Guarantee
Note: a proof of purchase is required in all cases. For all eligible replacements (where agreed by Timeguard) the customer is responsible for all shipping/postage charges outside of the UK. All shipping costs are to be paid in advance before a replacement is sent. - Page 16 If you experience problems, do not immediately return the unit to the store. Email the Timeguard Customer Helpline: HELPLINE helpline@timeguard.com or call the helpdesk on 020 8450 0515 Qualified Customer Support Coordinators will be online to assist in resolving your query.
