GENERAL DESCRIPTION
The Hy-Gain Model 216 SAT is a high-perfor-
mance "OSCAR" (Orbiting Satellite Carrying
Amateur Radio) satellite antenna for the 145.8 -
146.0
MHz
frequency
polarization switching circuitry for manual selec-
tion of either Right Hand Circular Polarization
(RHCP) or Left Hand Circular Polarization
(LHCP). This flexible design is suitable for
worldwide applications with any of the amateur
satellites having either an uplink or downlink in the
145.8 - 146.0 MHz frequency range, such as AO-10,
FO-12, AO-13, DO-17, AO-16, LO-19, UO-22,
KO-23, RS-10, RS-11, RS-12, RS-13, etc. These
include modes A, B, J, JA, JD, JL, KA, KT, and
T.
It is also usable over the entire 2-meter hand, 144-
148 MHz; and could he used with future satellites
placed near 144.5 MHz, or with terrestrial modes
such as repeaters and SSB/CW DX. The vertical and
horizontal sets of elements may he fed with separate
feedlines for total flexibility.
Boom Length........................................................................................................ 168.75 in. (429 cm)
Maximum Boom O.D. ...............................................................................................1-25 in. (32 mm)
Turning Radius (Max) ................................................................................................... 8..ft. (2.44 m)
Total Number of Elements ................................................................................................................. 1f
Longest Element ...................................................................................................39.5 in. (100 cm)
Wind Survival ...............................................................................................&0 mph (128.7 km/h)
Mast/Boom Diameter Accepted .............................................1.250-1.625 in. (32 mm - 41 mm)
Wind Area ..................................................................................................... l..1 sq. ft. (.102 sq. m)
Net Weight ............................................................................. ' ......................... 7..lbs. 3 oz. (3.26 kg)
Stacking Distance (min) .............................................................82 in. (2.08 m) (1.0 wavelength)
hand.
It
features
SPECIFICATIONS
Mechanical
The 216 SAT Antenna features 16 elements
(total) on a 2.1 wavelength boom. Each set of '8
elements is designed to give 10.7 dBd gain based
on a (quasi-logarithmic tapering of element
spacings. This design also gives a very clean
pattern, with very small sidelobes. The 216
SAT also features high efficiency 'T" matched
driven elements for easy assembly and high gain.
True R F, 50 ohm switching relays are rated at
200 watts PEP and contribute to improved
VSWR. Feedpoints are encapsulated for long life in
all types of climates. Most hardware is stainless
steel
including
the
(pushnuts). All insulators are UV protected. The
coaxial
assembly
is made
Polytetrafluoethylene
Fluorinated Ethylene Propylene (FEP) jacketed
coaxial cable.
The 216 SAT "OSCAR" beam can he used with the
Hy- Gain 70- 30 SAT 70 cm OSCAR Beam and
the 217S, fiberglass, 5 foot boom, be used with
other commercial or "homebrew" "OSCAR"
antennas. The 216 SAT antennas may be stacked
for more gain.
element
retaining
from
high-quality
(PTFE)
dielectric
rings
and

Advertisement

loading
Need help?

Need help?

Do you have a question about the 216SAT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hy-Gain 216SAT

  • Page 1 GENERAL DESCRIPTION The 216 SAT Antenna features 16 elements (total) on a 2.1 wavelength boom. Each set of '8 The Hy-Gain Model 216 SAT is a high-perfor- elements is designed to give 10.7 dBd gain based mance "OSCAR" (Orbiting Satellite Carrying on a (quasi-logarithmic tapering of element Amateur Radio) satellite antenna for the 145.8 -...
  • Page 2 handle. One nut drive r should h a hollo PREPARATION FOR ASSEMBLY This can be used for pushing on the pushnuts. FOR OUR OVERSEAS CUSTOMERS: If you Standard wrenches or adjustable wrenches may use the Metric System, see the Americanto- also be used in place of the nut drivers.
  • Page 4 ASSEMBLY OF OTHER ELEMENTS After assembly, the boom-to-mast bracket may be Select the two reflector elements, 3/16" x 39 1/2" rotated on the boom so that after mounting, the (Item 1), marked with 2 black bands near one elements are in an "X" configuration. Securely end of each.
  • Page 5 Slide another element insulator over the other Select one each of elements D1 and D2. Iden- end of the reflectors and push it onto each ele- tify these elements by the length and color ment until it seats into the mounting hole. Each bands listed in Table 1.
  • Page 6 A0-0216-C - 0 0 3 Item No Description D2, 3/16" x 35 1/4" D3,3/16" x 35" D4, 3/16" x 34 3/4" D5,3/16" x 34 12" D6, 3/16" x 34 1/4" Boom, front, 1 1/8" x 57 1/4 " Boom, mid, 1 1/4" x 57 I2" Figure 3 Assembly of Directors to Boom ATTACHMENT OF COAX ASSEMBLY...
  • Page 7 Use black electrical tape, and secure this The other coaxial cable coming from the coaxial cable to the boom on both sides of the coupler tube should go around the boom and rear D1 element. loop backwards to attach its terminals to the rear driven element's T-bars, as shown in Figure 4.
  • Page 8 AO-2165-A-005 NOTE: Looking at rear end of boom and encap- sulated feed points. Figure 5 Feedpoint Orientation for LHCP in the Unswitched Mode AO-216S-A-006 NOTE: Looking at rear end of boom and encapsulated feed points. Figure 6 Feedpoint Orientation for RHCP in the Unswitched Mode Either LHCP or RHCP will result if these at- NOTE: To achieve LHCP in the unswitched...
  • Page 9 When mounting the 216 SAT OSCAR Beam If you are unable to resolve technical problems, above any other antennas, allow at least 6.5 feet for you should contact the Telex/Hy-Gain Cus- clearance of the rear boom. tomer Service Department in Minneapolis, Minnesota.
  • Page 10: Parts List

    For ordering replacement parts contact: All requests, inquiries or warranty claims Telex/Hy-Gain Telex should be made to: Communications, Inc. 8601 N.E. Amateur Department Highway 6 P.O. Box 5579 Telex Communications, Inc. Lincoln, NE. 68505 9600 Aldrich Avenue South ATTN: Customer Service Department...
  • Page 11 PARTS LIST (Continued) Item Part No. Description 877881 Parts Pack 216S - Hardware (Continued) 555747 Nut, hex, 5/16"-18 ................4 562961 Lockwasher, 1/4" internal ......... 564792 Lockwasher, split, 5/16" ..............8 565697 Lockwasher, #10 internal ............. 20 500185 Bolt, #8-32 x 1/2"................2 560035 Lockwasher, #8 internal ..............
  • Page 12: General Description

    OSCAR-Boom GENERAL DESCRIPTION maximum O.D. of 1 inches (35 mm), which The Hy-Gain 217S is a high-strength fiberglass allows it to work with both the Alliance boom m designed to support circular polarized U100/U110 rotators and the KENPRO KR- antennas for "OSCAR" communications. The 500/KR-5400 rotators.
  • Page 13 INSTRUCTION MANUAL Most hardware is stainless steel including the ele- GENERAL DESCRIPTION ment pushnuts. All insulators are UV protected. The The Hy-Gain Model 70-30 SAT is a high-perform- coaxial assemblies are made from high-quality ance "OSCAR" (Orbiting Satellite Carrying Polytetrafluoroethylene...
  • Page 14 SPECIFICATIONS Electrical Frequency Range ......................432-438 MHz Gain ............................14.0 dBdc Beamwidth ........................28-30 degrees Front-to-Back Ratio ........................25 dB Ellipticity ..........................3 dB Max. Power Rating ........................200 W/PEP Connector ..........................Type N Polarity Switch Voltage and Current Requirements ........ 9-15 VDC @ 30-60 mA VSWR (435-437 MHz) ............Less than 1.5 when using fiberglass boom A bench-vise with jaws no wider than 6 inches is Make all measurements to the given dimensions,...
  • Page 16 ASSEMBLY OF DRIVEN ELEMENTS Carefully slip the inch pushnuts (item 27) 3/16 Select the two (2) driven elements, over each end of the two (2) driven elements, and 3/16" x 12 1/4", marked with a single black color band need push them along each element until they are one end of each.
  • Page 17 A O - 0 2 1 5 - 8 - 0 0 3 Item No. Description Item No. Description Driven Element, 3/16"x 12 1/4" Bolt, #8-32 x 1/2", round head Boom, rear, 11B" x 60" Nut, #8-32, hex Insulator, element Pushnut, 3/16"...
  • Page 18 ASSEMBLY OF OTHER ELEMENTS Select one each of elements - Dl, D2, D3, D4, D5, and D6. Install these elements on the rear boom Select the two (2) reflector elements, 3/16" x 13", marked with two black bands near one end of each. section in the vertical set of holes shown partially in Also select four (4) insulators and four (4) pushnuts.
  • Page 19 After the installation of all elements, check each Use black electrical tape, and secure this exposed length from Table 1. Also check each coaxial cable to the boom at two locations be- set of 15 elements to make sure the elements are tween the elements.
  • Page 20 A0-0215-A-008 NOTE: Looking at rear end of boom and encap- sulated feed points. Figure 6 Feedpoint Orientation for LHCP in the Unswitched Mode AO-0215-A-009 NOTE: Looking at rear end of boom and encap - sulated feed points. Figure 7 in the Unswitched Mode Feedpoint Orientation for RHCP To achieve RHCP in the unswitched mode, the Either LHCP or RHCP will result if these at...
  • Page 21: Installation

    9913 should be used with Type N connectors. Service Information If you are encounter technical problems and need WARNING: assistance, you should contact Hy-Gain Customer DO NOT allow any part of the antenna to Service Department. touch power lines. This could cause severe burns or fatal injuries.
  • Page 22 PARTS LIST Item Description Part No. 160057 Reflector, 3/16" x 13" ................2 160058 Driven Element, 3/16" x 12 1/4" ............2 - ......................160060 D1, D2, 3/16" x 11 3/4" 160061 D3, 3/16" x 115/8"...4 ................2 160062 D4, 3/16" x 11 1/4" ................2 160063 D5, 3/16"...
  • Page 23: Metric Conversion

    METRIC CONVERSION Converting American measurements to Metric: Using the scale below to identify lengths of bolts, diameters of tubes, etc. The American inch (1") and foot (1') can be converted in this way. 1 inch (1") = 2.54 cm 1 foot (1') = 30.48 cm Example: 42" x 2.54 = 106.7 FRACTION AND METRIC EQUIVALENTS FOR ONE INCH Fractional...
