Related Manuals for RCA CC800
Summary of Contents for RCA CC800
- Page 1 U S E R ’ G U I D Table o f Contents ... Optional Accessories..l First-Time Operation ..8 Powering Y o u r Camcorder..16 Recording and Traveling Tips...2 1 Recording Features ...
-
Page 2: Safety Precautions
INSIDE. IF YOU SPILL LIQUID ON THE CAMCORDER OR ADAPTER/CHARGER, DISCONNECT THE AC ADAPTER/CHARGER’S POWER CORD TO PREVENT POSSIBLE FIRE OR SHOCK HAZARD AND CONSULT AUTHORIZED SERVICE PERSONNEL. MOISTURE CAN DAMAGE INTERNAL PARTS. REFER ALL SERVICE TO AUTHORIZED RCA CAMCORDER SERVICENTER PERSONNEL ONLY. INTRODUIRE... - Page 3 SAFETY PRECAUTIONS CAUTION: READ “IMPORTANT SAFETY INSTRUCTIONS FOR AC ADAPTER/CHARGER” ON THE NEXT PAGE BEFORE USING THE AC ADAPTER/CHARGER. CAUTION: MAINTAIN ELECTRICAL SAFETY. POWERLINE-OPERATED EQUIPMENT OR ACCESSORIES CONNECTED TO THIS UNIT SHOULD BEAR THE UL LISTING MARK OR, IF PURCHASED AND USED IN CANADA, THE CSA CERTIFICATION MARK ON THE ACCESSORIES THEMSELVES AND SHOULD NOT HAVE BEEN MODIFIED SO AS TO DEFEAT THE SAFETY FEATURES.
-
Page 4: Important Safety Instructions For Ac Adapter/Charger
Take it to a qualified serviceman. Do not disassemble adapter/charger. Take it to an Authorized RCA Camcorder Se¢er when service or repair is required. Incorrect reassembly may result in a risk of electric shock. -
Page 5: Important Safeguards
IMPORTANT SAFEGUARDS In addition to the careful attention devoted to quality standards in the manufacture of your product, safety is a major factor in the design of every instrument. However, safety is your responsibility too. These pages list important information that will help to assure your enjoyment and proper use of a camcorder, adapter/charger, and accessory equipment. - Page 6 IMPOR’IIANT SAFEGUARDS 8. Ventilation--Slots and openings in the products are provided for ventilation to ensure reliable operation of the product and to protect them from overheating. These openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface.
- Page 7 IMPORTANT SAFEGUARDS 12. Outdoor Antenna Grounding-If an outside antenna or cable system is connected to the product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSVNFPA No.
- Page 8 IMPORTANT SAE’EGUARDS 16. Lightning-For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power line surges.
-
Page 9: Table Of Contents
Product Registration..i Safety Precautions ... i-vii Optional Accessories..l-7 Accessory Order Form..5-7 First-Time Operation ..8-15 Powering Your Camcorder..16-20 Recording and Traveling Tips ..21 Video Cassettes..22-23 Features Camera Edit ... Quick Review.. - Page 10 FB1260 and FB120 Rechargeabie Batteries These rechargeable nickel-cadmium batteries are designed specifically for long life. The FB1260 powers your camcorder approximately 55 minutes and the FB120 approximately 110 minutes (depending on how much you use zoom and pause). Both can be recharged with the AC adapter/charger that came with your camcorder.
- Page 11 221125 Remote Control This remote control lets you operate the camcorder from across the room. Uses one 3-volt micro lithium battery. lCVA147C RF Output Adapter This RF output adapter is used with a coaxial RF cable, such as AH065G or AHO66G, to connect your camcorder to a standard TV (one without audio/video inputs) for playback.
- Page 12 AC025A Soft Carrying Case Custom compact soft case designed especially to provide protection and utility for your compact VHS camcorder and most accessories. Rugged fabric lined with soft non- abrasive material and generous padding. Has three outside pockets with storage for lens filters, adapters, batteries, and tapes, VCClOOO Video Color Control Center The VCClOOO is two accessories in one.
-
Page 13: Accessory Order Form
Order Form for Camcorder Model CC800 Part No. Description ACO25A Soft Camcorder Case Super Lightweight Tripod AC035 AC036 Monppod ACSO91 Shoulder Stra AH011 75-300 Cable Transformer AH25 Y-Adapter Coaxial RF Cable AH065G AH066G Coaxial RF Cable ( CPSO20 AC Adapter/Charger... - Page 14 Charge your order on your VISA or MasterCard by filline in below USE YOUR CREDIT CARD IMPORTANT: Copy complete account number from your VISA card IMPORTANT: Copy complete account number from your Mastercard Copy Number above YOUI name on MasterCard AUTHORIZED SIGNATURE Prices are subject to change without notice.
- Page 15 To order accessories, contact your local Dealer. If a dealer is not nearby, you can also follow the directions below to order by telephone or direct-by-mail. United States ahd Canada Orders To place your order by phone, have your Visa or Mastercard ready and call the toll-free number listed below between 8AM and 8PM Eastern Standard Time.
-
Page 16: Unpack The Camcorder And Accessories
Save the packing materials and box in case you ever need to ship or store your camcorder. The items shown below are packed with your camcorder. If any are missing or appear damaged, contact your dealer immediately. Camcorder: Model CC800 Adapter/Charger Part No. CPSOZO Shoulder Strap Part No. -
Page 17: Attach A Power Supply
2. Attach a power supply. Adapter/Charger POWER I n d i c a t o r 1. Connect the power connector’s small plug into the OUT jack on the adapter/charger. 2. Align the reference mark on the power connector with the mark on the camcorder. -
Page 18: Adjust The Handstrap To Fit Your Hand
3. Insert a tape. EJECT. Slide Turn the tape wheel on the cassette to remove any slack from the tape. Insert the cassette with the tape wheel facing up and the tape window facing out. Press on the area labeled the cassette door locks into place. - Page 19 TC-2O/TC-30 Switc &Select a recording speed (SP or EP) with the W/H’ switch. SP - Standard play provides the best picture, but the shortest recording time (20 minutes with a TC-20 tape). EP - Extended play provides three times the recording time as SP (60 minutes with a TC-20 tape).
-
Page 20: Eyepiece Focus Control
8. Place the POWER OFF/CAMERA) switch in CAMERA. indicator will light and POWER will the camcorder enter the record- 3 and - appear pause mode. PAUSE in the viewfinder when the camcorder is in record pause. The position of this switch tells the camcorder whether you want to record (CAMERA), turn the power off (OFF), or play back tapes... -
Page 21: Start And Stop Recording
10. Start and stop recording. Press and release the thumb trigger to start recording. REC will appear in the viewfinder, and the tally light will light when the camcorder is recording. Press and release the thumb trigger again to stop recording. The camcorder is now in the record- pause mode ( = PAUSE = and - appear in the viewfinder). -
Page 22: Review Camcorder's Operating Controls
13. Review camcorder’s operating controls. Power Zoom Buttons *W” - Wide Angle “T - Telephoto FOCUS LOCK Button Microphone Lens, Remote Control Sentir Electronic Viewfinder Zoom Eyepiece Focus Control Adjust Button DISPLAY Button... - Page 23 13. Review camcorder’s operating controls. DATEITIMEICHAR SELECT + and - Buttons (Also TRACKING Buttons) Q.(Quick) REVIEW Button (Also EDIT Button) STOP Button II . PLAY STOP/PLAY/PAUSE Button BATTERY RELEASE Button AUDIO, RF DC Shoulder Strap Attachment Ring OUT, and VIDEO A&b Battery or Power Connector for AC Adapter/Charger Here (continued)
-
Page 24: Using The Adapter/Charger To Power Your Camcorder
Using the Adapter/Charger to Power Your Camcorder The power connector attaches to the camcorder and lets you power your camcorder directly from standard household power. The adapter/charger operates on 100-240 volts, 50/60 Hz, so it can be used virtually anywhere in the world to power the camcorder or recharge the battery. -
Page 25: Using The Battery To Power Your Camcorder
Using the Battery to Power Your Camcorder The battery must be charged as described on the next first time. Initial charging will take approximately 70 the battery should supply about 55 minutes of operating time (depending on how much you use zoom and pause). Conserve battery power by turning the camcorder off during recording breaks. - Page 26 Using the Battery to Power Your Camcorder To AC Wall Outlet 100440 Adapter/Charger Side-B Ch’ARGE Indicator Indicator’ Battery Release Switch POWER Indicator CH-iRGE Indicator Indicator’ Charging Batteries If the power connector is attached to the OUT jack on the adapter/charger, remove its plug.
-
Page 27: Battery Care And Storage
Using the Battery to Power Your Camcorder Battery Warning The battery warning will appear and flash in the camcorder’s viewfinder when the battery needs to be recharged. l-----l Battery Warning in Viewfinder Battery Care and Storage II~~ Recharging takes approximately 70 minutes depending on the battery’s condition. -
Page 28: Optional Car Cord Adapter
Optional Car Cord Adapter The optional DCCOS car cord shown on page 2 allows you to power your camcorder from the cigarette lighter socket of a car, truck, or RV. It converts 1Zvolts to a 6-volt output. Note: Consult the installation and operating instructions enclosed with the DCC08 for complete operating... -
Page 29: Recording And Traveling Tips
In case of fire or theft, make a video recording of your home and contents to store in a safe place. Try to make sure indoor scenes are well-lit. This imtroves picture quality and color reproduction. Do not move the camcorder rapidly from side-to-side while recording. -
Page 30: Erase Protection - Safety Tab
We recommend that our cassettes be used with your camcorder. Use of poor quality tapes or tapes that have been damaged or mishandled can contaminate the video heads, resulting in a snowy picture or no picture at all during playback. Because there is no control over the type of tape purchased or rented by consumers, head cleaning is not covered under warranty. -
Page 31: Inserting And Removing Cassettes
Inserting and Removing Cassettes Before inserting a cassette, turn the tape wheel on the side of the cassette in the direction shown to remove any slack in the tape. ape Wheel Cassette Car& and Storage _~ When you are $nished with a cassette, rewind it, remove it from the camcorder, and label it. -
Page 32: Camera Edit
POWER Camera Edit Camera edit allows you to position the tape when the camcorder is in record pause. Place POWER in CAMERA. Press and hold REWIEDIT SEARCH - to visually search recorded tape in reverse. 8 Press and hold FFIEDIT SEARCH + to visually search forward on the recorded tape. -
Page 33: Electronic Viewfinder
The camcordet’s electronic viewfinder is a miniature monitor that displays the picture seen by the camcorder when recording. Eyepiece Focus Control m The eyepiece focus control lets you set the focus of the viewfinder for your personal visio . If you wear eyeglasses, you probably k n operate the camcorder without them. -
Page 34: Viewfinder Displays
1 Focus Indicators 2 Dew Warning 1 Focus switch must be in POWER Manual Focus Indicators ( rl A ) appear when focus is adjusted manually. Manual Focus Lock Indicators 4) appear when manual focus is locked Low-Contrast Indicators ( -Ii-i- ) flash when the auto-focus system cannot focus properly. - Page 35 8 INDEX--INDEX =PAUSE= FADE F A D E - - D E C 10 hite - - MWB Balance CAMERA and the safety tab has been removed from the cassette. The l&J indicator also flashes POWER when the switch is set to CAMERA and there is no cassette in the camcorder.
-
Page 36: Install The Clock Lithium Cell
Install the Clock Lithium Cell The clock cell indicator & will appear in the viewfinder when the cell has not been installed or needs to be replaced. The cell should last approximately one year. (+ Side Facing Out) 1. Make sure camcorder is turned off, and remove any power supply attached to the camcorder. - Page 37 After the date and time have been set, they can be displayed and recorded on your tapes. The clock cell must be installed. DATEITIiUElCHAR SELECT + and - DATE/TIME1 Switch and Indicator Set the Date and Time 1. Install the clock cell. 2.
- Page 38 Select the Date, Time, or Title You Want to Record on Your Tape be installed and the The clock cell must date and time set before they can be selected and recorded. 1. Attach a power supply and place switch in POWER CAMERA.
- Page 39 To Record the Date, Time, or Title Display on Your Tape 1. Place the camcorder in the record- pause mode. 2. Press DISPLAY to display the mode you want to record in the viewfinder. The mode you select will be recorded whenever it appears in the viewfinder.
-
Page 40: Creating And Recording A Title
You can create a title (up to ten characters), store it, and record it. DATEITIMEICHAR SELECT + and - DATE/TIME1 CIL4R SET Button POWER Switch and Indicator Creating and Recording a Title 1. Place POWER switch in CAMERA. POWER indicator will light. 2.Repeatedly press DISPLAY to display SET CHAR menu. -
Page 41: Power Zooming
The motorized zoom lens allows you to zoom in and out at two speeds for close-ups or wide-angle shots just by pressing one of the power zoom buttons. Zoom AdJust Button \ Adjusting the Zoom Buttons The zoom buttons are easily controlled by your index and middle fingers when you hold the camcorder through the handstrap. -
Page 42: Macro Focus
Power Zoom Buttons “W” a& “p LOCK LOCUS Button Auto Focus The camcorder will focus automatically. No indicators appear in the viewfinder during auto focus. Notes: The low-contrast indicator (-%*i -) in the viewfinder indicates the auto- focus system may not operate correctly due to low illumination, low or no contrast, repeated patterns, or two subjects at different distances overlapping. -
Page 43: Manual Focus
Manual Focus Indicators (A r - r - Manual Displays in Viewfinder Manual Focus Under certain conditions, such as those listed, you may need to focus manually. 1. Press power zoom button to zoom “T” in on your subject. To maintain proper focus throughout the zoom range, you must zoom in on the subject before adjusting the focus. -
Page 44: Fading In And Out Of Scenes
You can add a professional touch to your recordings when you fade in and out of scenes. The picture will gradually appear or disappear. The speed of the fade is automatically controlled by the camcorder. Button’ FADE Fade In 1. Place the POWER switch to CAMERA. The POWER indicator will light. -
Page 45: White Balance
Making colors look natural is what white balance is all about. This adjusting the way the camcorder “sees” and records the light source in the scene you wish to record. Your camcorder is equipped with automatic white balance. However, under certain cond tions, such as recording an object with various shades of the same color or when recording a predominant red or brown object outdoors, you may want to adjust white balance manually. - Page 46 E I ’ The time-counter display shows the actual time elapsed when recording a program or playing back a segment of a prerecorded tape. It helps you locate the end of programs. I I 1 Note the time counter reading when you finish recording or playing back a tape. For example, you recorded for 10 minutes.
- Page 47 The approximate time remaining on the tape in the camcorder is automatically TC-2O/TC-30 displayed in the viewfinder. The position before the camcorder can correctly calculate time remaining. P0~~~swit~b Set the Switch TC-2OlTC30 Before recording, set the TC-2O/TC-30 switch for the size of tape you are using. TC-20 Select when using a tape with...
-
Page 48: Using The Cassette Adapter
The camcorder uses a smaller size cassette, but records in standard VI-IS format. The cassette adapter allows you to play your VI-IS-C cassettes in a VCR just like other standard VHS cassettes. Insert the VHS-C cassette into the cassette adapter. Insert the cassette adapter into the VI-IS VCR like a normal VI-IS cassette. - Page 49 Insert Cassette into Cassette Adapter Load Detector 4. Gently close the cassette compartment lid until it locks into place. Make sure the cassette reel area under the adapter is free to turn while the cassette is loading. You should hear a whirring sound Note: while the tape loads.
-
Page 50: Attaching The Shoulder Strap
The camcorder’s shoulder strap is designed to let you carry the camcorder from your shoulder and - when you are ready to shoot -bring the camcorder to shooting position in one quick movement. To Attach the Shoulder Strap 1. If the strap keeper is over a double section of the strap, slide the strap keeper off the end of the strap. -
Page 51: Specifications
General Power requirement: 6VDC Power consumption: 6.5 watts (normal) Weight: 1.6 lbs. (720g) Dimensions - Including Viewfinder 4.5” x 4.6” x 7.2” (115 x 118 x 182mm) Video Recorder Section Format: VHS-C Record/Playback System: Four video record/playback heads One flying erase head Video Signal: EIA Standard NTSC color This equipment has been tested and... -
Page 52: Viewfinder Playback And Playback Features
EJECT Button Viewfinder Playback Viewfinder playback is the simplest way to watch tapes using the camcorder. To Play Back a Tape 1. Place POWER switch in VCR. The POWER indicator will light. 2. Slide EJECT and insert the cassette you want to play back. Close the cassette compartment. -
Page 53: Tape Positioning
“jitter” (picture bouncing up and down). Some “jitter” is normal during stop-action viewing. Simultaneously press both TRACKlNG buttons to return tracking to its preset center. Note: The buttons may have no TRACKING effect on tapes recorded on other camcorders or VCR’s. -
Page 54: Installation
“_ . . , .., . . , __ ^ to a TV monitor (or VCR) with To connect your camcorder you will need the audio/video cable that came packed with your camcorder. If your TV is already connected to a VCR, and watch what the camcorder is recording or playing on the Back of Mono VCR or... - Page 55 - , . _ .., ^ , Playback Opetition and How to Copy apes on the VCR 1. A. Camcorder connected directly to TV: Turn on the TV and tune it to the video in p ut channel. B.
-
Page 56: Playback On Tv Without Audio/Video Inputs
“j “,.. To connect your camcorder to a TV without audio/video inputs, you will need an optional lCVA147C RF output adapter and an optional coaxial RF cable, such as AH065G or AH066G shown on page 3. If your TV has AUDIO and VIDEO IN jacks (or is connected to a VCR), refer to pages 46-47. -
Page 57: Playback Operation
Playback Operation 1. Set the CH3KH4 switch on the RF output adapter to channel 3 or 4. 2. Turn on the TV, and tune it to the same channel you selected with the RF output adapter’s CH3lCH4 switch. 3. Place adapter’s VCRITV switch in VCR. -
Page 58: Cleaning The Camcorder's Viewfinder
Cleaning the Camcorder To clean the camcorder’s exterior, remove any power source connected to the camcorder and gently wipe it with a clean soft cloth. the Camcorder's tins ~:w~~~~~~~~~~:" .'~;:;,,,:l;,, :.l.:-' s...! : ,,,,,, i,;.;,;;.:. '% .,,. :x.'.'. y Cleaning To clean the camcorder’s lens, blow it with a blower brush, and then gently wipe the lens with cleaning tissue and commercially prepared cleaning solution designed for use on camera lens. -
Page 59: Proper Care And Storage
Do not expose the camcorder or adapter/charger to rain or moisture. If either component becomes wet, turn off the power and take the unit to an Authorized RCA Camcorder Servicenter. Do not use an adapter/charger or batteries other than the ones specified for the camcorder. -
Page 60: Trouble Checks
Before you call or take your camcorder to an Authorized RCA Camcorder Servicenter, look below for the type of trouble you are experiencing. Then perform the simple checks and adjustments listed for that trouble. - Page 61 Press PLAY to return to normal playback. Camcorder remains in pause mode Subject was too far from camcorder. Sound is too low or distorted I If the dew indicator ( 4 ) flashes in the viewfinder, there Dew indicator flashing in is moisture in the camcorder.
- Page 62 Try disconnecting power source. Wait ten seconds and then Error number (EOI, E02, etc.) connect power source again. If error number does not disappear from viewfinder, consult your Authorized RCA appears in Camcorder Servicenter. viewfinder...
-
Page 63: Limited Warranty
Servicenter for the new or, at our option, refurbished replacement parts required to repair your camcorder. How you get service: Check with your RCA Dealer or call l-800-336-1900 for the Authorized RCA Camcorder Servicenter nearest you. If an Authorized RCA Camcorder... -
Page 64: Index (Alphabetical)
AC Adapter/Charger, Safety Instructions Accessories, Included ... 8 Accessories, Optional..l-7 Accessory, Order Form ..5-7 Adapter/Charger, Using..9,16 Attaching the Shoulder Strap..42 AUDIO/RF DC OUTJVIDEO Jacks ... 15,46,48 Audio/Video Cable ..8,46,48 Auto Focus ... A u t o H e a d Cleaner ... - Page 65 Button..15,47 EDIT t Button..15,24 EDIT SEARCH - Button..15,24 EDIT SEARCH Button..10,12,15,23,44 EJECT Electronic Indexing..24 Electronic Viewfinder..15,25 Indicator..22,27 Switch..11,15,22,27 EPISP Erase Protection..22 Eyepiece Focus Control..12,15,25 Button ...
- Page 66 Playback Features ..45 Playback on a TV With AUDIO/VIDEO IN Jacks ..46-47 Playback on a TV Without Audio/Video Inputs ..48-49 Playback Speeds ..22 Playback, First ..13 Playback, Viewfinder ..44 Plug Adapter..16 POWER (CAMERAIOFFIVCR)Switch ...
- Page 67 TIMEkXARIDATE SELECT + and - Buttons..15,29,32 TIhfElChW?/DATE Button ..i ... 15,29,32 Time Remaining b rsplay ..26,3 9 Title in Viewfinder ... 26,32 Titler ... Buttons ..15,44-45 TRACKING Traveling and Recording Tips ..21 Tripod, Using ... 4 Trouble Checks..
- Page 68 For your nearest home entertainment Dealer or Authorized Servicenter call toll-free in the U.S.A. 1-800-336-1900 Canadian Consumers - Your toll-free numbers are: English: l-800-522-0338 French: l-800-522-0445 If your camcorder needs service, please contact your dealer or the nearest Servicenter from the yellow pages. Please do not send any products to the Indianapolis address listed in this manual or on the carton.
