Summary of Contents for Defy DMO383

  • Page 1 DMO383 Microwave oven Microwave PAGE OF 24 Instruction manual...

  • Page 2: Table Of Contents

    CONTENTS AND PAGE NUMBER IMPORTANT SAFETY INSTRUCTIONS SPECIFICATIONS EXAMINING YOUR MICROWAVE OVEN AFTER UNPACKING REDUCE THE RISK OF INJURY TO PERSONS EARTHING INSTALLATION RADIO INTERFERENCE ARCING UTENSIL AND COOKWARE GUIDE OVEN PARTS AND ACCESSORIES COUNTERTOP INSTALLATION THE CONTROL PANEL OPERATING INSTRUCTIONS SETTING THE CLOCK SETTING THE KITCHEN TIMER MICROWAVE COOKING...

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS his appliance is classified as Group 2 Class B ISM. Defined as (Industrial, Scientific and Medical) equipment in which radio-frequency energy is intentionally generated and/or used in the form of electromagnetic radiation for the treatment of material, and spark erosion equipment.
  • Page 4 o not put foreign material between the oven surface and door. It could • result in excessive leakage of microwave energy. o not use recycled paper products for cooking. They may contain • impurities which could cause sparks and/or fires when used during cooking.
  • Page 5 Microwave heating of beverages can result in delayed eruptive • boiling, therefore care must be taken when handling the container. o reduce the risk of injury to persons: a) Do not overheat liquids. b) Stir the liquid both before and halfway through heating it. c) Do not use straight-sided containers with narrow necks.
  • Page 6 Make sure that the power supply cord is undamaged and does not • run under the oven or over any hot or sharp surface. The wall socket must be readily accessible so that the Microwaves • plug can be easily unplugged in an emergency. Do not use the oven outdoors.

  • Page 7: Specifications

    SPECIFICATIONS Model: DMO383 Rated Voltage: 230V~50Hz, 1100W (Microwave) Rated Output Power (Microwave): 700 W Operating Frequency 2450MHz External Dimensions: (H x W x D) 243mm(H)×446mm(W)×332mm(D) Oven Cavity Dimensions: (H x W x D) 202mm(H)×301mm(W)×311mm(D) Oven Capacity 20 Litres Net Weight: Approx.

  • Page 8: Reduce The Risk Of Injury To Persons

    REDUCE THE RISK OF INJURY TO PERSONS DANGER Electric Shock Hazard Touching some of the internal components can cause serious personal injury or death. Do not disassemble this appliance. WARNING Electric Shock Hazard Improper use of the grounding can result in electric shock. Do not plug into an outlet until appliance is properly installed and grounded.

  • Page 9: Radio Interference

    RADIO INTERFERENCE Microwave ovens can cause radio and TV interference. This may be reduced or eliminated by taking the following measures: 1. Clean the door and sealing surfaces of the oven. 2. Reorient the receiving antenna of the radio or the television. 3.

  • Page 10: Oven Parts And Accessories

    OVEN PARTS AND ACCESSORIES Remove the oven and all materials from the carton and oven cavity. Your oven comes with the following accessories: Glass tray x 1 - Turntable ring assembly x 1 - Instruction Manual x 1 1. Door Safety Lock System 2.

  • Page 11: Countertop Installation

    COUNTERTOP INSTALLATION Remove all packing material and accessories. Examine the oven for any damage such as dents or broken door. Do not install if oven is damaged. Cabinet: Remove any protective film found on the microwave oven cabinet surface. Do not remove the light brown Mica cover that is attached to the oven cavity to protect the magnetron. Installation 1.Select a level surface that provides enough open space for the intake and/or outlet vents.

  • Page 12: The Control Panel

    The control panel DISPLAY Cooking time, power, indicators and clock time are displayed. AUTO COOK MENUS Instant settings for cooking popular foods. NUMBER PADS (0-9) Use to adjust power level, set the time or food weight. CLOCK Use to set the clock time. POWER LEVEL Use to select the microwave power level.

  • Page 13: Operating Instructions

    OPERATING INSTRUCTIONS When the oven is first plugged in, a beep will sound and the display will show”1:01”. • During the cooking setup process, the oven will return to standby mode after a period of 25 seconds. • During cooking, press the STOP/CANCEL pad once, the program will pause, then press the START pad •...

  • Page 14: Microwave Cooking

    Time Defrost In standby mode, press the TIME DEFROST pad once. • Use the number pads to enter the required defrosting time. The longest time is 99 minutes 99 seconds. • Press the START pad to confirm. • NOTE: Whilst the defrosting program is in progress, the system will pause and emit a sound to remind the user to turn the food over, press the START pad to resume defrosting.

  • Page 15: Auto Cook Menus

    Auto cook menus The quick cook settings allow for cooking or reheating of food automatically without entering the power level or time. For smaller portions, simply press the applicable pad and start. For larger portions, push the pad twice. Popcorn Press the POPCORN pad once.

  • Page 16: Microwave Cooking Guide

    MICROWAVE COOKING GUIDE 1. Place the food in a microwave approved cooking utensil and place it centrally on the glass tray. Placing a heavy load on the perimeter of the glass tray could cause the glass tray to dislodge from the rotating base.

  • Page 17: Cleaning And Care

    4) The oven should not be adjusted or repaired by anyone except a properly trained service technician. If it becomes necessary to replace the oven lamp, consult a Defy Service Centre to have it replaced. Replacement lamps are not covered by the warranty. The oven should be cleaned regularly and any food deposits removed.

  • Page 18: General Guidelines

    GENERAL GUIDELINES As microwave cooking differs from traditional cooking, the following guidelines should be considered whenever you use your microwave oven If the food is undercooked. Check if: • You have selected the correct power level. • The selected time is sufficient. Selected times depend on initial temperature, weight and density of the food etc.

  • Page 19: Microwave Recipes

    MICROWAVE RECIPES Apricot Chicken Cooking Time: 22 minutes Serves: 4 people. Ingredients: Chicken breast fillets, quartered. 750 grams Can apricot halves, drained (set juice aside). 410 grams Large onion, chopped.1 large Garlic, Crushed. 1 clove(s) Butter or Margarine. 30 grams (1 tbs) mild curry powder.15 ml Cake Flour.
  • Page 20 MICROWAVE RECIPES Easy Whole wheat Loaf Cooking Time: 17 minutes. An easy step by step method of making your own bread. Helpful Hints: Sunflower seeds may turn green if used untoasted. To toast, place in flat glass container, microwave on 100% (High) power, 10 minutes per 125ml of seeds or until brown, stirring frequently.

  • Page 21: Frequently Asked Questions

    FREQUENTLY ASKED QUESTIONS Q : I accidentally ran my microwave oven without any food in it. Is it damaged? A : Running the oven empty for a short time will not damage the oven. However, it is not recommended. Q : Can the oven be used with the tray or tray rack removed? A : No.

  • Page 22: Customer Care

    If you have followed the instructions and still have a problem or have any service or spares queries, please contact the customer care line by sending an email to service@defy.co.za or by calling 0861 00 3339. They will be able to advise you on any aspect of the appliance.

  • Page 23: Warranty

    WARRANTY 1 This certificate is issued by DEFY APPLIANCES (PTY) LIMITED manufacturers of Defy and Ocean products, hereinafter the Company, to the original purchaser only, of the appliance described on the certificate and shall constitute the only warranty given in respect of this appliance.
  • Page 24 PAGE 24 OF 24...
