HVRGRN8WS*1C HVRGRN8WSNF*1C Owners Manual MANUAL DEL PROPIETARIO HALSEY TAYLOR MANUEL DE L'UTILISATION HALSEY TAYLOR Hydroboost Bottle Filling Station and Cooler ® Estación de llenado de botella Hydroboost y enfriador ® Station de remplissage de bouteille Hydroboost et refroidisseur ® Patent zurn-elkay.com/patents WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov...
Page 2
HVRGRN8WS*1C HVRGRN8WSNF*1C Note: Danger! Electric shock hazard. Disconnect power before servicing unit. Nota: peligro! Peligro de descarga eléctrica. Desconecte antes de reparar la unidad. Remarque : Danger ! Risque d'électrocution. Débrancher avant de réparer l'appareil. Pictured is unit only without bottle filler. Uses HFC-134A refrigerant Usa refrigerante HFC-134A Utilise du fluide frigorigéne HFC-134A...
Page 4
HVRGRN8WS*1C HVRGRN8WSNF*1C IMPORTANT IMPORTANTE MPORTANT ALL SERVICE TO BE PERFORMED BY AN TODO EL SERVICIO DEBERÁ SER EFECTUADO POR TOUT ENTRETIEN DOIT ÊTRE EFFECTUÉ PAR AUTHORIZED SERVICE PERSON UNA PERSONA DE SERVICIO AUTORIZADA UN REPRÉSENTANT AUTORISÉ HANGER BRACKETS & TRAP INSTALACIÓN DE FIJADOR DE INSTALLATION DU SIPHON ET DU INSTALLATION...
Page 5
HVRGRN8WS*1C HVRGRN8WSNF*1C PUSH BUTTON MECHANISM MECANISMO DE BARRA DE EMPUJE MÉCANISME DU BOUTON-POUSSOIR Fig. 5 Fig. 6 Page 5 1000001739 (Rev. P - 03/23)
Page 6
HVRGRN8WS*1C HVRGRN8WSNF*1C 7/16” BOLT HOLES FOR MOUNTING FASTENING UNIT TO WALL SCREWS UNIT CENTER LINE TOP COVER Fig. 8 Fig. 7 Fig. 9 Fig. 10 BRACKET & SCREWS Bottle Filler Installation Instructions 1) Remove two (2) mounting screws with 5/32” Allen wrench holding top cover to Bottle Filler (See Fig. 8). Remove top cover. Note do not discard mounting screws, they will be needed to reinstall top cover.
Page 7
HVRGRN8WS*1C HVRGRN8WSNF*1C BF11 - BF12 PROGRAM SETTING THE CONTROL BOARD VERIFY CONTROL BOARD SOFTWARE Continued from below: 1) To verify the software program of the control board the unit will 2) When the display changes to “SETTINGS”, depress the button again. need to be shut down and restarted.
HVRGRN8WS*1C HVRGRN8WSNF*1C OVERLOAD BOTTLE FILLING COLD CONTROL UNIT (WATER) COMPRESSOR WALL MOUNTING PLATE RELAY Fig. 12 115V Wiring Diagram Diagrama de cableado de 115 voltios Schéma de câblage de 115 volts FIVE PIN CONNECTOR FOUR PIN MAIN BOARD CONNECTOR PIGGY BACK TERMINAL ON POWER CORD WHITE Fig.
Page 9
HVRGRN8WS*1C HVRGRN8WSNF*1C PARTS LIST/ LISTA DE PIEZAS/ LISTE DES PIÈCES ITEM PART NO DESCRIPTION DESCRIPCIÓN DESCRIPTION 22897C Panel - Bottom Dispenser Panel - Dispensador Inferior Panneau - Distributeur Inférieur 1000001906 Kit - Push Button Assy/Button/Sleeve/ Kit - botón montaje/botón/manga/tuercas/ Kit - bouton poussoir Cpl/bouton/manchon/noix/ Nuts/Spacer separador entretoise...
