Installation/Care/Use Manual
Hydroboost Bottle Filling Station and Cooler

IMPORTANT! INSTALLER PLEASE NOTE.

THE GROUNDING OF ELECTRICAL EQUIPMENT SUCH AS TELEPHONE, COMPUTERS, ETC. TO WATER LINES
IS A COMMON PROCEDURE. THIS GROUNDING MAY BE IN THE BUILDING OR MAY OCCUR AWAY FROM THE
BUILDING. THIS GROUNDING CAN CAUSE ELECTRICAL FEEDBACK INTO A FOUNTAIN, CREATING AN ELEC-
TROLYSIS WHICH CAUSES A METALLIC TASTE OR AN INCREASE IN THE METAL CONTENT OF THE WATER.
THIS CONDITION IS AVOIDABLE BY USING THE PROPER MATERIALS AS INDICATED. ANY DRAIN FITTINGS
PROVIDED BY THE INSTALLER SHOULD BE MADE OF PLASTIC TO ELECTRICALLY ISOLATE THE FOUNTAIN
FROM THE BUILDING PLUMBING SYSTEM. WE SUGGEST THAT THE BOTTLE FILLING STATION AND WATER
COOLER BE PROTECTED BY A GROUND FAULT CIRCUIT INTERRUPTER (GFCI).

INSTALLER

HTHB-HVRGRN-NF Bottle Fillers are among the easiest to install on the market
today. To insure you install these models easily and correctly, PLEASE READ
THESE SIMPLE INSTRUCTIONS BEFORE STARTING THE INSTALLATION.
CHECK YOUR INSTALLATION FOR COMPLIANCE WITH PLUMBING, ELECTRI-
CAL, AND OTHER APPLICABLE CODES. After installation, leave these instructions
with the Fountain for future reference.
HVRGRN8WSNF*1B HVRGRN8BLWSNF*1B
HTHB-HVRGRN-NF Factory Prep
Page 1

IMPORTANT

THIS IS AN INDOOR APPLICATION ONLY.
ALL SERVICE TO BE PERFORMED BY AN
AUTHORIZED SERVICE PERSON.
TOOLS REQUIRED
BUT NOT PROVIDED:
SAFETY GLASSES
GLOVES
ELECTRIC DRILL
3/4" WRENCH OR CRECENT WRENCH
5/16" NUT DRIVER
UTILITY KNIFE
TAPE MEASURE
PENCIL
CENTER PUNCH
1/2" SOCKET & RATCHET WRENCH
5/32" ALLEN WRENCH
98768C (Rev. A - 6/11)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HVRGRN8WSNF 1B Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Halsey Taylor HVRGRN8WSNF 1B Series

  • Page 1 HVRGRN8WSNF*1B HVRGRN8BLWSNF*1B Installation/Care/Use Manual HTHB-HVRGRN-NF Factory Prep Hydroboost Bottle Filling Station and Cooler IMPORTANT THIS IS AN INDOOR APPLICATION ONLY. ALL SERVICE TO BE PERFORMED BY AN AUTHORIZED SERVICE PERSON. TOOLS REQUIRED BUT NOT PROVIDED: SAFETY GLASSES GLOVES ELECTRIC DRILL 3/4”...
  • Page 2 HVRGRN8WSNF*1B HVRGRN8BLWSNF*1B Single Rough-In Fig. 1 98768C (Rev. A - 6/11) Page 2...
  • Page 3 HVRGRN8WSNF*1B HVRGRN8BLWSNF*1B Two -Level Rough-In Fig. 2 Page 3 98768C (Rev. A - 6/11)
  • Page 4 HVRGRN8WSNF*1B HVRGRN8BLWSNF*1B 7/16” BOLT HOLES FOR MOUNTING FASTENING UNIT TO WALL TOP COVER SCREWS UNIT CENTER LINE Fig. 3 Fig. 4 BOTTLE FILLER INSTALLATION Remove two (2) mounting screws with 5/32” allen wrench holding top cover to Bottle Filler (See FIG. 1. Remove top cover. Note do not discard mounting screws, they will be needed to reinstall top cover.
  • Page 5 HVRGRN8WSNF*1B HVRGRN8BLWSNF*1B BF6-BF7-BF8 PROGRAMS SETTING THE CONTROL BOARD VERIFY CONTROL BOARD SOFTWARE RESETTING BOTTLE COUNT 1) To verify the software program of the control board the 1) Depress the program button for approximately 2 seconds unit will need to be shut down and restarted. The chiller until the display changes then release.
  • Page 6 HVRGRN8WSNF*1B HVRGRN8BLWSNF*1B BF9 PROGRAM SETTING THE CONTROL BOARD VERIFY CONTROL BOARD SOFTWARE SETTING UNIT TYPE 1) To verify the software program of the control board the 1) Depress the program button for approximately 2 seconds unit will need to be shut down and restarted. The chiller until the display changes then release.
  • Page 7 HVRGRN8WSNF*1B HVRGRN8BLWSNF*1B Drain Cover Drain Mat Screws DRAIN MAT EXPLODED VIEW Fig. 7 DRAIN MAT ASSEMBLY AND CARE 1) Place Drain Cover on mat and install the four screws as shown in Fig. 8. 2) It is recommended that the cover be removed and the drain cover be cleaned weekly.
