Gama ecoGEO HP GEN3
TECHNICAL MANUAL
EN
MODELO:
CONTACTO DEL SAT:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Gama ecoGEO HP GEN3 and is the answer not in the manual?

Questions and answers

Related Manuals for ECOFOREST Gama ecoGEO HP GEN3

Summary of Contents for ECOFOREST Gama ecoGEO HP GEN3

  • Page 1 Gama ecoGEO HP GEN3 TECHNICAL MANUAL MODELO: CONTACTO DEL SAT:...

  • Page 3: Table Of Contents

    Contents General Information ................................5 1.1. Safety considerations ................................5 1.2. Disposal ....................................7 Heat pump installation ................................8 2.1. Transport and handling ................................8 2.2. Dimensions and connections ..............................8 2.3. Unpacking .................................... 10 2.4. Assembly and disassembly of the covers ..........................10 2.5.
  • Page 4 Technical manual ecoGEO HP 11. Symbols ....................................50...

  • Page 5: General Information

    Technical manual ecoGEO HP 1. General Information This manual contains the necessary information to install the heat pump. Read this manual carefully before installing the equipment. Keep this manual handy for future reference. This manual contains two different kinds of warnings that should be heeded. ▪...
  • Page 6 Technical manual ecoGEO HP Refrigerant The heat pump uses R410A refrigerant as operating fluid. This refrigerant is not harmful to the environment as it does not contain chlorine, and therefore does not contribute to the destruction of the ozone layer. Under normal operation of the heat pump the toxicity of the refrigerant is nil and there is no risk of explosion.

  • Page 7: Disposal

    DANGER! ▪ he heat pump must be supplied with an external switch that can shut off all the circuits. Ecoforest recommend installing one external automatic breaker in each external power supply (control, internal auxiliary equipment and drive).

  • Page 8: Heat Pump Installation

    Technical manual ecoGEO HP 2. Heat pump installation 2.1. Transport and handling The heat pump must be transported vertically and not exposed to adverse weather conditions. It can be lain carefully on its rear side to facilitate transportation to the installation site. ▪...
  • Page 9 Technical manual ecoGEO HP The overall dimensions and hydraulic connections of the ecoGEO HP 25-100 heat pump are described below. Figure 2.2. Overall dimensions and hydraulic connections of the ecoGEO HP 25-100 model (Amounts in mm). ecoGEO HP1 ecoGEO HP3 Heating supply / heat dissipation Heating / cooling supply Heating return / heat dissipation...

  • Page 10: Unpacking

    Technical manual ecoGEO HP 2.3. Unpacking To unpack the heat pump, remove the wooden box carefully, remove the pallet anchoring screws and perform a check to make sure the heat pump has not been damaged during transportation. Anchoring studs to the pallet Figure 2.3.
  • Page 11 Technical manual ecoGEO HP Figure 2.4. Disassembly of the covers of the ecoGEO HP models. ▪ During cover disassembly, take care to remove the control panel cable without damaging it. NOTE...

  • Page 12: Recommended Positioning

    Technical manual ecoGEO HP 2.5. Recommended positioning Choose a dry place where there is no risk of frost. Avoid installation against bedroom walls or walls of other rooms where noise emissions can be annoying. If possible, install the heat pump with the rear part pointed toward an exterior wall. Avoid installation near a corner, since this can amplify noise emission levels.

  • Page 13: Service Areas

    Technical manual ecoGEO HP 2.6. Service areas The minimum recommended distances to be left around the heat pump to facilitate installation, start-up and maintenance work are indicated below. Figure 2.6. Minimum recommended service areas around the heat pump (amounts in mm).

  • Page 14: Hydraulic Installation

    Technical manual ecoGEO HP 3. Hydraulic installation ▪ The installation schemes included from here on should be considered simply as a guide. ▪ The design of the hydraulic installation must be performed by qualified personnel and in accordance NOTE with applicable local regulations. ▪...

  • Page 15: Heating / Cooling Circuit

    Technical manual ecoGEO HP Figure 3.1. Brine circuit connection options. Installation instructions Follow the instructions below to wire the brine circuit. ▪ Install the necessary components to carry out the filling/discharge of the return pipe. ▪ Install a particulate filter in the return pipe with a mesh size no greater than 1 mm. It is recommended to install shut off valves immediately before and after the filter to make it easier to clean or replace.
  • Page 16 Technical manual ecoGEO HP FBus2 AI20 AI19 DI11 DI13 DI10 DI12 DI14 AI12 AI13 AI14 AI15 AI16 DO10 AI11 DO12 DO17 DO12 Figure 3.2. Wiring scheme directly to the heating / cooling system (ecoGEO HP3 models). Installation using buffer storage tanks If required by the application, the heat pump can also be connected to the heating / cooling system using a buffer separator tank.
  • Page 17 Technical manual ecoGEO HP FBus2 AI20 AI19 DI11 DI13 DI10 DI12 DI14 AI12 AI13 AI14 AI15 AI16 DO10 DO11 DO16 AI17 AI11 DO18 AI18 DO12 DO17 DO12 Figure 3.4. Wiring scheme using one buffer storage tanks (ecoGEO HP3 models). Outlet units These can manage as many as five different outlet temperatures.
  • Page 18 Technical manual ecoGEO HP FBus2 AI20 AI19 DI11 DI13 DI10 DI12 DI14 AI12 AI13 AI14 AI15 AI16 DO10 AI17 AI11 DO18 AI18 DO17 DO16 DO15 DO12 DO14 Figure 3.5. Wiring scheme using two buffer storage tanks with simultaneous production (ecoGEO HP1 models). Installation instructions Follow the instructions below to connect the heating / cooling circuit.

  • Page 19: Filling And Discharge Circuits

    Technical manual ecoGEO HP 4. Filling and discharge circuits ▪ uring filling work on the hydraulic circuits, take special care to prevent liquid from spilling on the DANGER! internal electrical heat pump components, which could cause personal injury due to electrocution and/or poor equipment operation.
  • Page 20 Technical manual ecoGEO HP Figure 4.1. Filling the brine circuit.

  • Page 21: Electrical System

    Technical manual ecoGEO HP 5. Electrical system ▪ efore performing any operation on the electrical panel, disconnect the power supply. DANGER! ▪ emember that the heat pump has multiple external power supply. ▪ coforest recommend installing one external automatic breaker in each external power supply (control, internal auxiliary equipment and drive).
  • Page 22 Technical manual ecoGEO HP Figure 5.2. General electrical connections scheme of the heat pump.
  • Page 23 Technical manual ecoGEO HP Analogue inputs (AIxx) These terminals are used to connect external temperature probes. Only passive NTC temperature probes can be connected, so cable connection polarity is not important. If necessary, use extension cables with a maximum length of 50 m and a minimum diameter of 0,75 mm .
  • Page 24 Technical manual ecoGEO HP 24Vac Figure 5.5. Example of digital input connections with 24Vac voltage. Analogue outputs (AOxx) These terminals send analogue 0-10Vdc regulation signals to modulate the control of outlet units with mixture, aerothermal brine units with variable speed fan, external auxiliary boilers, etc. On the other hand, these connectors have a 24Vac power supply terminal to supply the modulating valve motor.

  • Page 25: Heat Pump Power Supply

    5.2. Heat pump power supply Ecoforest ecoGEO HP heat pumps require two power supply points. One for the power supply of the control panel; this unit includes the power supply of the internal and external valves and also that of the regulation signals and the digital and analogue inputs. The other power supply is exclusively dedicated to the compressor.
  • Page 26 Technical manual ecoGEO HP Power supply of the control panel The control panel power supply is always single-phase; the following table shows the characteristics of the necessary electrical connection: Recommended cable section Type of power supply Type of protection Cut-off current 1/N/PE 230 V / 50-60 Hz Magnetic, thermal and differential protection 1 mm...

  • Page 27: External Protections

    Technical manual ecoGEO HP 5.3. External protections It is equipped with a connector that can be connected to various types of external mechanical protections, such as flow switches, pressure switches, thermostats, etc. The ESS connector is used to connect these protections. The external protection devices are powered from the heat pump connector. Figure 5.11.

  • Page 28: Simultaneous Production

    Technical manual ecoGEO HP Description Signal Type Connector Digital output Activation 230Vac / 8A maximum Source pump Analogue output Valve regulation 0 – 10Vdc Digital output Activation 230Vac / 8A maximum Production pump Analogue output Valve regulation 0 – 10Vdc DHW production Digital output Activation 230Vac / 8A maximum...

  • Page 29: External Auxiliary Equipment

    Technical manual ecoGEO HP ▪ Heat pump provides 24Vac connection from the electrical panel, remember that all the devices connected to the heat pump cannot exceed 48VA or 2A. Exceed these limits could cause poor heat pump NOTE operation and/or heat pump component breakdowns. 5.9.

  • Page 30: Inside Environment Control

    Technical manual ecoGEO HP Pool production Activates / deactivates pool production demand. If the signal is requested, pool production is governed by the pool configuration in the heat pump controller. SMART GRID Enables / disables the SG states of the heat pump. Depending on the value of the digital inputs, there are four SG operating statuses: SG1 [0 0] (Normal state): The heat pump is operating normally, as per its configuration.
  • Page 31 Technical manual ecoGEO HP thT bus terminals In addition to digital input control (interior thermostats) interior terminals with thT data bus communication can also be used. These terminals capture the inside temperature and humidity of the area associated with each outlet unit, DG1 – SG5, using a serial cable over a Modbus protocol.

  • Page 32: Remote Control By Bus

    ▪ For more information about BUS connections, please contact your distributor. NOTE 5.14. Energy meter The heat pump allows MODBUS communication with energy meters supplied by Ecoforest. Before installing the energy meter, carefully read its assembly instructions. Description Signal Connector...

  • Page 33: Start-Up

    120 Ohm heater between Rx+/Tx+ and Rx-/Tx- in the first and last terminal to prevent possible communication problems. ▪ To install the device supplied by Ecoforest, follow the steps in the manufacturer's installation manual included with the equipment. It is necessary to configure a 100 address on the measurement device for proper communication with your heat pump (See control applications manual).

  • Page 34: Technical Specifications

    Technical manual ecoGEO HP 7. Technical specifications 7.1. Component location Description Description Brineinlettemp. probe Production outlet Production outlet temp. probe Production return Productioninlettemp. probe Brine outlet Suctionpressuretransducer Brine return Dischargepressuretransducer Evaporator (direct cycle) Brinepressuretransducer Condenser (direct cycle) Productionpressuretransducer Compressor Dischargemini-pressureswitch Electronic expansionvalve Electrical panel Filter dryer...
  • Page 35 Technical manual ecoGEO HP ecoGEO HP1 12-40 / ecoGEO HP1 15-70 / ecoGEO HP1 25-100...
  • Page 36 Technical manual ecoGEO HP ecoGEO HP3 12-40 / ecoGEO HP3 15-70 / ecoGEO HP3 25-100...

  • Page 37: Powercircuit Diagram

    Technical manual ecoGEO HP 7.2. Powercircuit diagram Control power Drive Power Supply 400Vac supply 230Vac COIL Tx/Rx J9 FBus1 J11 BMS2 J14 pLAN Tx/Rx J29 FBus2 24 Vac pCOOEM+ Serial Adress Serial Adress 2 4 8 2 4 8 24Vac Transformer Max output 100VA ESS1 ESS2...

  • Page 38: Electrical Connection Tables

    Technical manual ecoGEO HP 7.3. Electrical connection tables DIGITAL OUTPUTS CONNECTIONS DESCRIPTION Connection terminal Controller terminal Type Signal Block I / DO1 pCOOEM+ / J16 / NO1 Activation 230Vac / 8A max Brine circulation pump Block I / DO2 pCOOEM+ / J17 / Out2 Activation 230Vac / 8A max Productioncirculation pump Block I / DO3...
  • Page 39 Technical manual ecoGEO HP ANALOGUE INPUTS CONNECTIONS DESCRIPTION Connection terminal Controller terminal Type Signal Block II / AI1 pCOOEM+ / J2 / U1 NTC 10K 25°C Compressor suction temperature Block II / AI2 pCOOEM+ / J2 / U2 Radiometer 0-5Vdc Compressor suction pressure Block II / AI3 pCOOEM+ / J2 / U3...
  • Page 40 Technical manual ecoGEO HP DIGITAL INPUTS CONNECTIONS DESCRIPTION Connection terminal Controller terminal Type Signal Block II / DI1 pCOOEM+ / J7 / DI1 Voltage free (0V) Electrical consumption control (EVU) Block II / DI2 pCOOEM+ / J7 / DI2 Voltage free (0V) WINTER / SUMMER selection Block II / DI3 pCOOEM+ / J7 / DI3...

  • Page 41: Load Losses

    Technical manual ecoGEO HP 7.4. Load losses ecoGEO HP1 12-40 kW ecoGEO HP3 12-40 kW Condenser Evaporator / Condenser Evaporator 2000 4000 6000 8000 10000 12000 2000 4000 6000 8000 10000 12000 Flow rate (l/h) Flow rate (l/h) ecoGEO HP1 15-70 kW ecoGEO HP3 15 70 kW Condenser Evaporator / Condenser...

  • Page 42: Operation Map

    Technical manual ecoGEO HP 8. Operation map ecoGEO HP1 12-40 kW / HP3 12-40 kW / HP1 15-70 kW / HP3 15-70 kW / HP1 25-100 kW / HP3 25-100 kW 7; 65 25; 65 35; 65 -18; 39 -20; 33 25;...

  • Page 43: Operation Curves

    Technical manual ecoGEO HP 9. Operation curves ecoGEO HP1 12-40 / HP3 12-40 Source temp -3/0 ºC Source temp -3/0 ºC Source temp 2/5 ºC Source temp 2/5 ºC Source temp 7/10 ºC Source temp 7/10 ºC Heating temp 30/35ºC 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 Compressor Speed (%) Source temp -3/0 ºC...
  • Page 44 Technical manual ecoGEO HP ecoGEO HP1 15-70 / HP3 15-70 Source temp -3/0 ºC Source temp -3/0 ºC Source temp 2/5 ºC Source temp 2/5 ºC Source temp 7/10 ºC Source temp 7/10 ºC Heating temp 30/35ºC 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 Compressor Speed (%) Source temp -3/0 ºC Source temp 2/5 ºC...
  • Page 45 Technical manual ecoGEO HP ecoGEO HP1 25-100 / HP3 25-100 Source temp -3/0 ºC Source temp -3/0 ºC Source temp 2/5 ºC Source temp 2/5 ºC Source temp 7/10 ºC Source temp 7/10 ºC Heating temp 30/35ºC 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 Compressor Speed (%) Source temp -3/0 ºC Source temp 2/5 ºC...

  • Page 46: Technical Data Table

    Technical manual ecoGEO HP 10. Technical data table ▪ In the technical data tables you will find a series of numbers in superscript format, the meaning of which is explained below: NOTE In compliance with EN 14511, this includes the consumption of the circulation pumps and the compressor driver.
  • Page 47 Technical manual ecoGEO HP Specification ecoGEO HP1 12-40 kW / HP3 12-40 kW Units HP1 12-40 HP3 12-40 Place of installation Indoors Type of brine system Geothermal ✓ Application Heating, DHW with external storage tank and pool ✓ Integrated active cooling ✓...
  • Page 48 Technical manual ecoGEO HP Specification ecoGEO HP1 15-70 kW / HP3 15-70 kW Units HP1 15-70 HP3 15-70 Place of installation Indoors Type of brine system Geothermal ✓ Application Heating, DHW with external storage tank and pool ✓ Integrated active cooling ✓...
  • Page 49 Technical manual ecoGEO HP Specification ecoGEO HP1 25-100 kW / HP3 25-100 kW Units HP1 25-100 HP3 25-100 Place of installation Indoors Typeof brine system Geothermal ✓ Application Heating, DHW with external storage tank and pool ✓ Integrated active cooling ✓...
  • Page 50 Technical manual ecoGEO HP 11. Symbols DHW circuit 3-way valve open/closed Pool 3-way thermostatic valve Heating system 3-way modulating valve 0-10Vdc Cooling system Check valve NTC temperature probe Cut-off valve Relay thermostat Safety valve Differential pressure valve Data bus communication terminal Circulator pump Particulate filter Direct outlet unit...
  • Page 52 ECOFOREST GEOTERMIA, S.L. Parque Empresarial Porto do Molle l Rúa das Pontes, 25 l 36350 – Nigrán – Pontevedra.- (Spain) Tel.: +34 986 262 184 http://www.ecoforest.es Technical manual ecoGEO HP Gen3 Version 10/2021 The manufacturer reserves the right to make any necessary changes to the contents of this manual without prior notice.
