ecoSMART e-source
USER, INSTALLER AND TECHNICAL SERVICE MANUAL
EN
MODEL:
SERVICE CONTACT:

Advertisement

Table of Contents
loading

Related Manuals for ECOFOREST ecoSMART e-source

Summary of Contents for ECOFOREST ecoSMART e-source

  • Page 1 USER, INSTALLER AND TECHNICAL SERVICE MANUAL MODEL: SERVICE CONTACT:...

  • Page 3: Table Of Contents

    Contents General information ................................5 1.1. Safety considerations ................................5 1.2. Maintenance ................................... 6 General description ................................. 7 Installation ....................................7 3.1. Transport and handling ................................7 3.2. Dimensions ..................................... 7 3.3.
  • Page 4 7.6. Final inspection and commissioning ............................. 30 Identifying and solving problems ............................31 8.1. Alarm list ....................................31 Technical specifications ................................. 32 9.1. Technical data table ................................32 9.2. Circuit diagram ..................................33 9.3.

  • Page 5: General Information

    1. General information Thank you for purchasing an ecoSMART e-source source manager with your ecoGEO HP heat pump. This manual contains information about installing, commissioning and troubleshooting the device. There is also useful information for the end user, such how to navigate and adjust parameters via the control panel.

  • Page 6: Maintenance

     The power supply to the unit must have an external switch that can shut off all the circuits. Ecoforest recommends installing an automatic external switch for each of the electrical power sources (power DANGER! supply of the e-source manager and power supply of devices controlled by its DO digital outputs).

  • Page 7: General Description

    2. General description The ecoSMART source manager is an electronic controller designed to manage several brine energy sources, such as geothermal circuits or antifreeze/air aerothermal units. It can work with a single ecoGEO HP heat pump or with a cascade of several ecoGEO HP heat pumps controlled by an ecoSMART supervisor module.

  • Page 8: Fitting And Removing The Cover

    3.4. Fitting and removing the cover A 4 mm Allen wrench is required to assemble and disassemble the cover. Remove the front cover by loosening the four screws and pulling it. Figure 3.2. Removing the front cover of the e-source manager.

  • Page 9: Service Areas

     The power supply to the unit must have an external switch that can shut off all the circuits. Ecoforest recommends installing an automatic external switch for each of the electrical power DANGER! sources (power supply of the e-source manager and power supply of devices controlled by its DO digital outputs).

  • Page 10: General Instructions

    4.1. General instructions The locations of the main electrical panel components are shown below. Digital outputs Main supply 1/N/PE DOxx 230Vac 50-60 Hz Control Power Supply 230V DO10 DO11 DO12 DO13 L1 L2/N PE Transformer fuse 230Vac 0.5A...
  • Page 11 Figure 4.2. General electrical connection scheme 1.
  • Page 12 Figure 4.3. General electrical connection scheme 2.
  • Page 13  The schemes in figures 4.2 and 4.3 are provided only to indicate the electrical connections. The hydraulic design of the brine system should be carried out by a specialist. Its use in full or in part, as NOTE well as any reproduction or transfer to third parties, is the responsibility of the installation company.
  • Page 14 Control Power Supply 230V DO10 DO11 DO12 DO13 L1 L2/N PE pLAN BMS2 FBus AI10 AI11 AI12 DI7 DI8 24 Vac Figure 4.5. Example of voltage-free digital input connections.  24Vac external equipment can be connected directly from the e-source manager, and connected equipment as a whole must not exceed 36VA or 1.5A.

  • Page 15: Power Supply

    Digital outputs to relay (DOxx) The relay terminal block provides digital outputs to control external equipment, such as circulator pumps, fans or open/closed valves. Each relay should be powered externally with the operating voltage of the component to be controlled. Power is supplied to each relay separately, so different operating voltages can be used in each.

  • Page 16: Brine Collector Inlet And Outlet Temperature Probes

    Type of power supply Type of protection/ Cut-off current Recommended cable section 1/N/PE 230 V / 50-60 Hz Magnetic, thermal and differential / 1A 1.5 mm Table 4.1. Characteristics of the e-source manager power supply.

  • Page 17: Source Control

    4.5. Source control It is possible to control four independent sources. The electrical connections for controlling each source are as follows. Source 1: Geothermal Aerothermal Signal Type Connector Source alarm signal input...

  • Page 18: Bus Communication

    Figure 4.12. Example pLAN bus communication cable connection for installations with a cascade of heat pumps. Some other Ecoforest devices also communicate with each other via their pLAN ports. If you want to use the e-source manager in an installation that has several Ecoforest controllers (e.g. a cascade of several ecoGEO HP heat pumps with an ecoSMART Supervisor module), this will form part of the pLAN network together with the other controllers.

  • Page 19: Control Panel

    5.1. Control panel The e-source control panel has a screen with 6 buttons, like the one shown in the illustration below. The buttons are used to move through the various user menus and to adjust the parameters.

  • Page 20: Operating Modes

    Main brine pump activated Geothermal source activated (source 1) Aerothermal source activated (source 2) Wait. The unit is initialising STAND The unit is on and awaiting the activated command 5.4. Operating modes This field shows icons that indicate the current operating mode of the e-source.

  • Page 21: Parameter Adjustment

    XXXXXX XXXXXX XXXXXX Figure 5.3. Browsing through the list of user menus. 5.7. Parameter adjustment Take the following steps to change a parameter: Search for the screen containing the parameter that needs adjusting (see Section 0).

  • Page 22: Clock Menu

    5.8. CLOCK Menu Date/Time This is used to adjust the day of the week, date (DD/MM/YY) and time (HH:MM 24-hour format) of the controller. Daily saving time The settings of automatic time change between seasons (autumn-winter / spring-summer) can be adjusted.

  • Page 23: Alarms Menu

    5.10. ALARMS Menu Press for quick access to the information menu from the main screen. Active alarms These screens display the alarms that are or have been active. The button lights up and remains on if there is an active alarm locking the system.

  • Page 24: Language Selection

    6.1. Language selection Language Used to select the language of the heat pump controller. Language 4. Used to enable the language selection screen that appears on launching the controller. 5. Used to adjust the display time of the language selection screen on launching the controller.

  • Page 25: Configuration Of Each Source

    Switching off order or priority Maximum priority Source 1 ↑ Source 2 ↓ Source 3 Minimum priority Source 4 Table 6.1. Order of priority for switching off sources. For example, if sources 1, 3 and 4 are available, the system will start up with source 1. Then, if necessary, it will start source 3 and if it detects that one more is necessary, it will start source 4.

  • Page 26: Protection Configuration

    Defrosting of source 1, 2, 3 and 4 Only for sources configured as aerothermal. 1. Used to enable the defrost program of the aerothermal collector. 2. Used to configure the nominal DT in the conditions in which there is no frost. DT is the difference between the outdoor air temperature and the temperature of the glycol at the outlet of the source.

  • Page 27: Manual Activation Of Components

    Geothermal or aerothermal source 1, 2, 3 and 4 1. Shows the regulation % of the source: C. GEOTHERMAL: Shows the pump speed in %. D. AEROTHERMAL: Shows the fan speed in %.

  • Page 28: Configuration And Commissioning

    HP Supervisor Figure 7.1. Example information screens showing the ecoSMART e-source, ecoGEO HP heat pump and ecoSMART Supervisor software version. Check that there is no configuration in the e-source electronic control. If there are any configuration parameters or if you are not sure, delete the whole configuration using the tool in “installer menu →...

  • Page 29: Enabling The E-Source In The Heat Pump Or Cascade Of Heat Pumps

    To configure these addresses in the control panel, access the “DISPLAY ADDRESS SETTING” menu by simultaneously pressing and holding the three buttons on the right of the control panel [↑+ *←┘+ *↓+.

  • Page 30: Plan Communication Cable Connection

    7.4. pLAN communication cable connection Connect the pLAN communication cable to the e-source manager. 7.5. Source manager configuration Configure the source manager in accordance with sections 5 and 6. 7.6. Final inspection and commissioning ...

  • Page 31: Identifying And Solving Problems

    Check for any unusual noises in other parts of the installation. 8. Identifying and solving problems 8.1. Alarm list There are a number of reasons why the e-source manager activates an alarm to protect the system from possible damage or to alert the user to a malfunction.

  • Page 32: Technical Specifications

    Temperature probe Alarm due to broken or disconnected temperature probe. Depending on the probe causing the alarm, this may lock the system. 9. Technical specifications 9.1. Technical data table Table 9.1 shows the main technical specifications of the e-source manager.

  • Page 33: Circuit Diagram

    9.2. Circuit diagram POWER SUPPLY COIL J10 FBUS1 J11 BMS2 J14 pLAN 24Vac Transformer Max output 63VA pCOOEM+ 24 Vac FBus BMS2 pLAN AI10 AI11 AI12...

  • Page 34: Table Of Electrical Connections

    9.3. Table of electrical connections DIGITAL OUTPUTS CONNECTIONS DESCRIPTION Connection Controller terminal Type Signal terminal Block I / DO1 pCOOEM+ / J16 / NO1 Activation 250Vac / 8A max Main brine pump control...

  • Page 35: Symbols

    ANALOGUE OUTPUTS CONNECTIONS DESCRIPTION Connection terminal Controller terminal Type Signal Block II / AO1 pCOOEM+ / J6 / Y1 0-10Vdc Main brine pump regulation Block II / AO2 pCOOEM+ / J6 / Y2...

  • Page 36: Warranty And Technical Service

    11.1. Manufacturer's warranty ECOFOREST is liable for lack of conformity of the product or its spare parts, in compliance with the current regulations of the country where the product is purchased. The warranty is only valid in the country where the product is purchased.
  • Page 38 ECOFOREST GEOTERMIA, S.L. Parque Empresarial Porto do Molle / Rúa das Pontes, 25 36350 – Nigrán – Pontevedra – Spain Tel.: +34 986 262 184 http://www.ecoforest.es The manufacturer reserves the right to make any necessary changes to the contents of this manual without prior notice.
